Поз.
Артикул
Описание
5
TRANSMISSION CASE
5
TRANSMISSION CASE , Replaced By: A0022610101
8
SCREW PLUG OIL FILLING, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
11
SCREW PLUG OIL DRAIN, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
14
EXPANSION PLUG , Replaced By: A4039970620
17
FILLER CAP , 350.004,013 UP TO CHASSIS 12 357727,FROM CHASSIS SEE SPARE PARTS LIST 718
17
COVER , Replaced By: A0009977535
20
PLUG , Replaced By: A0009973435
20
PLUG , Replaced By: A0009973601
20
PLUG , 350.004,013 UP TO CHASSIS 12 357727,FROM CHASSIS SEE SPARE PARTS LIST 718
20
PLUG , Replaced By: A3529970032
23
GASKET CASE COVER,076139
23
GASKET , Replaced By: A0002614880
26
TRANSMISSION CASE COVER FRONT,076139
29
SCREW BRACKET TO SIDE MEMBER M10X30
29
SCREW , Replaced By: N304017010040
32
SEAL RING INTERMEDIATE GEAR
35
SPACER WASHER AS REQUIRED 2.25 MM
35
SPACER WASHER AS REQUIRED 3.35 MM
35
SPACER WASHER AS REQUIRED 2.05 MM
35
SPACER WASHER , Replaced By: A0002635152
35
SPACER WASHER , Replaced By: A0002634652
35
SPACER WASHER AS REQUIRED 2.85 MM
35
SPACER WASHER AS REQUIRED 3.15 MM
35
SPACER WASHER , Replaced By: A0002634252
35
SPACER WASHER AS REQUIRED 1.95 MM
35
SPACER WASHER AS REQUIRED 3.00 MM
35
SPACER WASHER AS REQUIRED 2.50 MM
35
SPACER WASHER AS REQUIRED 2.40 MM
35
SPACER WASHER , Replaced By: A0002631752
35
SPACER WASHER AS REQUIRED 2.00 MM
35
SPACER WASHER AS REQUIRED 2.10 MM
35
SPACER WASHER AS REQUIRED 2.70 MM
35
SPACER WASHER AS REQUIRED 2.65 MM
35
SPACER WASHER AS REQUIRED 3.55 MM
35
SPACER WASHER AS REQUIRED 3.20 MM
35
SPACER WASHER AS REQUIRED 2.20 MM
35
SPACER WASHER AS REQUIRED 2.35 MM
35
SPACER WASHER AS REQUIRED 2.55 MM
35
SPACER WASHER AS REQUIRED 1.65 MM
35
SPACER WASHER AS REQUIRED 3.60 MM
35
SPACER WASHER AS REQUIRED 2.15 MM
35
SPACER WASHER , Replaced By: A0002634252
35
SPACER WASHER AS REQUIRED 3.25 MM
35
SPACER WASHER AS REQUIRED 2.95 MM
35
SPACER WASHER , Replaced By: A0002632152
35
SPACER WASHER , Replaced By: A0002634252
35
SPACER WASHER AS REQUIRED 2.80 MM
35
SPACER WASHER AS REQUIRED 1.90 MM
35
SPACER WASHER AS REQUIRED 2.30 MM
35
SPACER WASHER AS REQUIRED 3.45 MM
35
SPACER WASHER , Replaced By: A0002634652, +001A0002635152
35
SPACER WASHER AS REQUIRED 1.85 MM
38
GASKET , ONLY FOR TRANSMISSION HAVING SWIVEL-MOUNTED CYLINDER
38
GASKET
38
GASKET , Replaced By: A0002621280
41
COVERING DRIVE SHAFT,FRONT
44
SEAL RING FRONT DRIVE SHAFT
47
SCREW , Replaced By: N304017010040
50
SPRING WASHERTO 000 268 46 01
53
SPACER WASHER AS REQUIRED 0.30 MM
53
SPACER WASHER AS REQUIRED 0.20 MM
56
GASKET , 350.004,013 UP TO CHASSIS 12 357727,FROM CHASSIS SEE SPARE PARTS LIST 718
56
GASKET , Replaced By: A0002648880
56
GASKET REAR
56
GASKET , Replaced By: A0012646180
56
GASKET , Replaced By: A0012646380
56
GASKET , Replaced By: A0012647380
59
TRANSMISSION CASE COVER SPEEDOMETER DRIVE COVER
59
TRANSMISSION CASE COVER REAR
62
SEAL RING INSIDE
62
SEAL RING , Replaced By: A0089973347
65
SEAL RING , Replaced By: A0069978847
68
EXPANSION PLUG SPEEDOMETER DRIVE
71
SPACER WASHER AS REQUIRED 1.40 MM
71
SPACER WASHER AS REQUIRED 1.70 MM
71
SPACER WASHER AS REQUIRED 1.20 MM
71
SPACER WASHER AS REQUIRED 1.00 MM
71
SPACER WASHER AS REQUIRED 1.30 MM
71
SPACER WASHER AS REQUIRED 1.60 MM
71
SPACER WASHER AS REQUIRED 1.10 MM
71
SPACER WASHER AS REQUIRED 1.50 MM
74
SCREW BRACKET TO SIDE MEMBER
74
SCREW , Replaced By: N304017010002
77
SPRING WASHERTO 000 268 46 01
80
GASKET
83
TRANSMISSION CASE COVER CASE,REAR
83
COVER , Replaced By: A0002612620
86
SCREW METAL SPRING BELLOWS TO WEB
89
SPRING WASHER CAB FLOOR
92
CONNECTOR AS REQUIRED 88.50 MM,TO 366 264 00 32
95
SEAL RING , Replaced By: A0069970245
98
SEAL RING
98
SEAL RING , 350.004,013 UP TO CHASSIS 12 357727,FROM CHASSIS SEE SPARE PARTS LIST 718
101
PIN , 350.004,013 UP TO CHASSIS 12 357727,FROM CHASSIS SEE SPARE PARTS LIST 718
101
PIN , Replaced By: N000007005228
104
THREADED PIN , Replaced By: A0009970319
104
LOCK CONNECTOR
104
SCREW , Replaced By: A0009970419, +001A0039901051
104
SEAL RING , 350.004,013 UP TO CHASSIS 12 357727,FROM CHASSIS SEE SPARE PARTS LIST 718
104
THREADED PIN SPEEDOMETER
107
HEX. NUT. NUT SHIFT LEVER KNOB
