Поз.
Артикул
Описание
11
GASKET CASE,REAR
11
GASKET
11
GASKET , Replaced By: A0002642980
15
HOUSING , Replaced By: A0002641328
15
HOUSING
19
BUSHING LATERAL P.T.O
23
SEAL RING P.T.O. SHIFT LEVER
27
STUD SHIFT CASE TO TRANSMISSION
27
STUD P.T.O. CASE TO TRANSMISSION CASE 107 MM,TO N 70/1C
27
STUD P.T.O. CASE TO TRANSMISSION CASE 80 MM
27
STUD P.T.O. CASE TO TRANSMISSION CASE 73 MM,TO N 70/1C
27
STUD
31
WASHER , Replaced By: N000433013010
31
WASHER
31
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
31
WASHER COVER TO P.T.O. CASE
35
LOCK WASHER OIL PUMP TO TRANSMISSION CASE
35
LOCK WASHER , Replaced By: N912006012000
39
NUT
39
NUT COVER TO FLANGE
45
SPRING
49
BALL
51
SLIDING COLLAR P.T.O.
51
SLIDING COLLAR , Replaced By: A0002641423
51
SLIDING COLLAR , Replaced By: A0002641423
51
SLIDING COLLAR
55
SHIFT LEVER
59
SLIDE P.T.O. SHIFT LEVER
87
SHIFT LEVER P.T.O. CONTROL
87
SHIFT LEVER N 70/1 C P.T.O.
87
SHIFT LEVER
87
SHIFT LEVER P.T.O. TO N 70/2C
89
SCREW SUPPORT TO FENDER
89
SCREW , Replaced By: N304017008018
91
NUT , Replaced By: N913004008001
91
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
96
SHIFTING CYLINDER PNEUMATIC SHIFT MECHANISM USED FOR LATERAL P.T.O. TO N 70/1C
96
SHIFTING CYLINDER P.T.O. CONTROL
96
SHIFTING CYLINDER , Replaced By: A0002606263
96
SHIFTING CYLINDER , Replaced By: A0002603263, +001A0045227817
96
SHIFTING CYLINDER , Replaced By: A0002606663
96
SHIFTING CYLINDER , Replaced By: A0002606563
96
SHIFTING CYLINDER , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 836824, Replaced By: A0002605063
96
SHIFTING CYLINDER , Replaced By: A0002606763
96
SHIFTING CYLINDER , Replaced By: A0002608963
96
SHIFTING CYLINDER , Replaced By: A0002606663
96
SHIFTING CYLINDER PNEUMATIC SHIFTING CYLINDER
105
SEAL RING
107
SPRING
109
SPRING
111
STOP RING
114
SNAP RING
116
BOOT
116
BOOT , Replaced By: A0002640696
118
NUT , Replaced By: N304035010001
118
NUT
121
YOKE
121
YOKE , Replaced By: A0009962801
123
PIN , Replaced By: N918001008002
123
PINM 8 X 16
126
WASHER
127
STRAINER
131
PIN PULL ROD TO SHIFT LEVER
135
WASHER EXHAUST MUFFLER TO STRAP
135
WASHER , Replaced By: N000125008443
137
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
137
COTTER PIN LEVER TO ROD
137
COTTER PIN PULL ROD TO LEVER
139
SEAL RING OIL DISTRIBUTOR BLOCK
143
SCREW PLUG
144
SWITCH
144
SENDER UNIT , Replaced By: A0105421217, +002A0045453926
144
SENDER UNIT , Replaced By: A0025452014
146
REPAIR KIT PNEUMATIC SHIFTING CYLINDER TO 000 260 66 63
147
BRACKET SHIFTING CYLINDER TO TRANSMISSION CASE TO N 70/1B
147
BRACKET SHIFTING CYLINDER TO N 70/1C
147
BRACKET SHIFTING CYLINDER TO N 70/1C
147
BRACKET SHIFTING CYLINDER TO TRANSMISSION CASE TO N 70/1B
147
BRACKET SHIFTING CYLINDER TO TRANSMISSION CASE TO N 70/1B
147
BRACKET SHIFTING CYLINDER TO N 70/1C
147
BRACKET SHIFTING CYLINDER
147
BRACKET PNEUMATIC SHIFTING CYLINDER TO N 70/2C
155
SCREW STRAP TO BRACKET
155
SCREW END PIECE TO EXHAUST PIPE M 10X25
159
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
163
CONNECTG.PARTS,DELY.RANGE P.T.O.
163
CONNECTG.PARTS,DELY.RANGE P.T.O.
163
CONNECTG.PARTS,DELY.RANGE P.T.O.
163
CONNECTG.PARTS,DELY.RANGE P.T.O.
163
CONNECTG.PARTS,DELY.RANGE P.T.O.
163
CONNECTG.PARTS,DELY.RANGE P.T.O.
163
CONNECTG.PARTS,DELY.RANGE P.T.O.
163
CONNECTG.PARTS,DELY.RANGE , Replaced By: A0002606305, +001A0002640357
163
CONNECTG.PARTS,DELY.RANGE , Replaced By: A0002609405
171
SLIDING COLLAR
175
LOCKING CAP CONNECTING PARTS
175
LOCKING CAP COVERING,019226
179
LOCK RING DRIVE GEAR
179
LOCK RING AS REQUIRED 3.00 MM,019226
179
LOCK RING SHAFT TO TRANSMISSION CASE
179
LOCK RING AS REQUIRED 45X2.5 MM
179
LOCK AS REQUIRED 2.00 MM
179
LOCK RING AS REQUIRED 2.00 MM,019226
183
GROOVED BALL BEARING (INTERMEDIATE SPINDLE)
183
GROOVED BALL BEARING CONNECTING PARTS
189
BUSHING SHAFT TO TRANSMISSION CASE
189
BUSHING INTERMEDIATE SHAFT
189
BUSHING , Replaced By: A0002645850
189
BUSHING , Replaced By: A0002645650
999
INTERMEDIATE SHAFT
999
INTERMEDIATE SHAFT , Replaced By: A0002603705
999
INTERMEDIATE SHAFT
999
PISTON SHIFTING CYLINDER
999
INTERMEDIATE SHAFT
999
PISTON SHIFTING CYLINDER
999
SHIFTING CYLINDER
999
SLIDING COLLAR
999
SHAFT , NO LONGER AVAILABLE, ORDER RANGE OF DELIVERY
