Поз.
Артикул
Описание
191
SWITCH RANGE SELECTOR
191
SWITCH , Replaced By: A3075400745
194
SHELL RANGE SELECTOR
197
SEAL RING RANGE SELECTOR SWITCH
200
SWITCH RANGE SELECTOR
203
SHAFT RANGE SELECTOR
206
BRACKET ELECTRIC CABLES
209
CABLE HARNESS RANGE SELECTOR
212
PLUG HOUSING 4-POLE
215
PLUG HOUSING 8-POLE
218
SCREWR & S, M 4X8
218
SCREW , Replaced By: N000000001933
218
SCREW FUSE BOX TO SIDE MEMBER,5 097182
221
MOTOR RANGE SELECTOR 24 V
221
MOTOR , Replaced By: A0012350995
224
SCREW , Replaced By: A0009847929
224
SCREW , Replaced By: N304017006020
224
SCREW , Replaced By: N304017006016
224
SCREWROCKINGER,TYP 59 U150
224
SCREW LICENSE PLATE TO BRACKET
224
SCREW PUMP TO BRACKET
227
SPRING WASHER LICENSE PLATE TO BRACKET
230
WASHER , Replaced By: A0009940510
230
WASHER
230
LOCK. WASHER ELECTRIC MOTOR TO BRACKET
233
CONICAL SPRING WASHER COVERING
236
GASKET , Replaced By: A3055450280
236
GASKET RANGE SELECTOR SWITCH
239
CAP RANGE SELECTOR SWITCH
242
SCREW , Replaced By: N304017006012
242
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
245
SPRING WASHER LICENSE PLATE TO BRACKET
248
LEVER RANGE SELECTOR
251
BALL PIVOT , Replaced By: A3129910120
251
BALL PIVOT LEVER
254
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
257
SPRING WASHER LICENSE PLATE TO BRACKET
260
SCREW PLUG MEASURING CONNECTION
263
SEAL RING SCREW PLUG
266
GROMMET GEAR SELECTOR HOUSING VENT
269
SCREW REAR AXLE REGULATING SOLENOID VALVE
272
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
272
SPRING WASHER , Replaced By: N000137008212
275
ROD RANGE SELECTOR
278
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
281
NUT BALL PIVOT TO LEVER
284
NUT L.H. THREAD
287
BALL SOCKET L.H. THREAD
290
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
293
ROD MODULATION PRESSURE CONTROL, UP TO TRANSMISSION 014716 DELIVER ADDITIONALLY:1X 301 301 00 97,1X 001 997 83 90
296
WIRE CABLE MODULATION PRESSURE CONTROL,013590
299
ARTICULATION PIECE
302
BOOT I.D., 8/13 MM
305
GROMMET
308
SCREW COVER PLATE TO BRACKET
311
SPRING WASHER LICENSE PLATE TO BRACKET
314
NUT BALL PIVOT TO LEVER
317
JOINT
317
JOINT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3073000029
320
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
323
SEAL RING MODULATION PRESSURE CONTROL
326
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
329
NUT BALL PIVOT TO LEVER
332
BRACKET
335
TURNBUCKLE TURNBUCKLE
338
SCREW , Replaced By: N304017008021
338
SCREW BRACKET TO FRAME SIDE MEMBER
338
SCREW PIPE CLAMP
341
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
341
SPRING WASHER , Replaced By: N000137008212
341
SPRING WASHER CAB FLOOR
341
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
344
WASHER EXHAUST MUFFLER TO STRAP
344
WASHER , Replaced By: N000125008443
344
WASHER
