Поз.
Артикул
Описание
5
BRAKE CYLINDER WITH FORDING ABILITY 30"WABCO
8
SEAL RINGWABCO TO 002 420 27 24
11
CUPWABCO
14
DIAPHRAGMWABCO
17
FITTINGWABCO
20
NUT COMBINATION CYLINDER TO BEARING BRACKET
20
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
23
PIN , Replaced By: A3619910005
23
PIN COMBINATION CYLINDER TO SLACK ADJUSTER
26
WASHER COMBINATION CYLINDER TO SLACK ADJUSTER
29
COTTER PIN STRAP TO SUPPORT
