Поз.
Артикул
Описание
199
HOUSING ,175047252761, Replaced By: A0002646302, +001A0002646310
199
HOUSING ADDITIONAL GEAR CLUSTER,252762
202
DOWEL PIN
204
SCREW , Replaced By: N000912010238
204
SCREW AXLE HOUSING TO REAR SUBFRAME,FRONT
206
LOCK WASHER AIR CLEANER TO BRACKET
207
SCREW BRACKET TO FRAME SIDE MEMBER
210
SPRING WASHER STEERING COLUMN BRACKET TO CAB
217
COVER , Replaced By: A0009977535
217
PLUG , Replaced By: A3529970032
217
SCREW PLUG BELL HOUSING
219
PLUG , Replaced By: A0009973435
219
PLUG , Replaced By: A0009977535
219
PLUG , Replaced By: A3529970032
219
SCREW PLUG BELL HOUSING
225
SCREW PLUG OIL FILLING, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
227
SCREW PLUG OIL DRAIN, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
230
EXPANSION PLUG P.T.O. HOUSING
234
SPACER WASHER , Replaced By: A0042644752
234
SPACER WASHER CONVERTER TO DRIVE SHAFT 2.60 MM
240
PIN , Replaced By: A0002641174
240
PIN , FROM TRANSMISSION 279826-313051 DELIVER ADDITIONALLY:AS REQUIRED 1 X 000 264 20 10 - 50 10,1 X 002 264 59 52 - 68 52, 1 X 003 264 28 52 - 48 52313052
242
SEAL RING FLANGE TO TRANSMISSION CASE COVER
244
COVER ,279826-313051
249
GASKET , Replaced By: A0002648480
249
GASKET ASBESTOS-FREE
253
SCREW PLUG TOP AND BOTTOM
257
SCREW BELL HOUSING TO TRANSMISSION M 18 X 195
259
SPRING WASHER BELL HOUSING WITH TRANSMISSION TO INTERMEDIATE FLANGE
263
PIN , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002683974
263
PIN SHIFT CASE,BOTTOM
267
SPRING ,279826
269
SEAL RING VALVE TO VALVE,K 025179
331
SCREW PLUG , Replaced By: A4429970030
331
SCREW PLUG SHIFTING SHAFT DETENT
335
COVER , Replaced By: A0002640710
335
COVER HOUSING,BOTTOM
337
NEEDLE BEARING , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002682150
337
NEEDLE BEARING , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002682150
475
SHAFT ,279826-324103, Replaced By: A0002604638, +002A0002640749
475
SHAFT , Replaced By: A0002604938
475
SHAFT GEARSHIFT MECHANISM,324104
477
SLIDE SHIFTING SHAFT,324104
480
SEAL RING SHIFTING SHAFT
485
BOOT SHIFTING SHAFT
490
BUSHING SHIFT LEVER TO SHAFT,279826
495
SHIFT LEVER GEAR CLUSTER SHIFT,279826
500
SCREW VALVE TO BRACKET
502
SPRING WASHER , Replaced By: N000137008212
502
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
504
NUT
506
SCREW , Replaced By: N304017008016
506
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
510
BRACKET SHIFTING CYLINDER TO SHIFT LEVER
512
WASHER , Replaced By: N000125015019
512
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
515
PIN SHIFTING CYLINDER, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
517
WASHER
525
SHIFTING CYLINDER , Replaced By: A0002603563
525
SHIFTING CYLINDER , Replaced By: A0002603563
525
SHIFTING CYLINDER , Replaced By: A0002603563
525
SHIFTING CYLINDER , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0002604763
525
SHIFTING CYLINDER PLANETARY GEAR CLUSTER TO TRANSMISSION WESTINGHOUSE
525
SHIFTING CYLINDER PLANETARY GEAR CLUSTER TO TRANSMISSION HUNGER
535
REPAIR KIT SHIFTING CYLINDER HUNGER,279826
540
GOVERNOR. THROTTLE NOZZLE , Replaced By: A0002641271
540
SCREW (THROTTLE SCREW)
542
SEAL RING LINE CONNECTION
620
FITTING , Replaced By: A0039979072
620
FITTING , Replaced By: A0029906071
620
TS DOUBLE FITTING SOLENOID VALVE
622
SEAL RING LINE CONNECTION
999
SPACER WASHER AS REQUIRED 1.40 MM
999
RING HALF ,047092, Replaced By: A0002643829, +001A0002620373
999
SPACER WASHER , Replaced By: A3362641052
999
RING HALF ,047092, Replaced By: A0002644529, +001A0002620373
999
SPACER WASHER AS REQUIRED 1.00 MM
999
OIL BAFFLE , FIRST EXHAUST STOCK OF OLD PARTS UP TO TRANSMISSION 047092, Replaced By: A0002640164
999
RING HALF ,047092, Replaced By: A0002644629, +001A0002620373
999
FOLLOWER , Replaced By: A0002640746
999
SPACER WASHER AS REQUIRED 0.80 MM
999
RING HALF ,047092, Replaced By: A0002644729, +001A0002620373
999
RING HALF ,047092, Replaced By: A0002644829, +001A0002620373
999
RING HALF ,047092, Replaced By: A0002644929, +001A0002620373
999
RING HALF ,047092, Replaced By: A0002645029, +001A0002620373
999
RING HALF ,047092, Replaced By: A0002645229, +001A0002620373
999
RING HALF ,047092, Replaced By: A0002645429, +001A0002620373
999
SPACER WASHER AS REQUIRED 1.20 MM
999
RING HALF ,047092, Replaced By: A0002645629, +001A0002620373
999
SPACER WASHER AS REQUIRED 1.80 MM
999
SPACER WASHER AS REQUIRED 2.00 MM
999
SPACER WASHER AS REQUIRED 2.20 MM
999
SHIFTING FORK , Replaced By: A0002652402
999
SHIFT LEVER , Replaced By: A3362602339
999
SLIDE , Replaced By: A0002680149
999
SHIFTING ROD , UP TO CHASSIS 992001
999
HANDLE (GEARSHIFT LEVER KNOB)
999
BRACKET , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3872950440
999
PRESSURE PLATE CLUTCH BRAKE
999
BRAKE DISC
999
BRAKE LINING
999
LEVER LEFT
999
FRICTION PIECE
999
SPACER TUBE GUIDE TO BELL HOUSING
999
LEVER RIGHT
999
SYNCHRONIZER BODY , Replaced By: A0002600045
999
HANDLE , Replaced By: A3372600040
999
LEVER
999
BEARING BRACKET , Replaced By: A3432601994
999
P.T.O. , Replaced By: A3432600305, +004A0002610070
999
TRANSMISSION , FOR COMPONENT PARTS,SEE SPARE PARTS LIST, Replaced By: A3432606103
999
TRANSMISSION
999
TRANSMISSION *** AK 6-90
999
TRANSMISSION , Replaced By: A3432606803
999
TRANSMISSION ADDITIONAL CLUSTER GEARBOX GV90
999
TRANSMISSION ADDITIONAL CLUSTER GEARBOX GV90
999
TRANSMISSION , Replaced By: A3422607403
999
TRANSMISSION S 5-90 OVERDRIVE WITH GV 90,1ST SPEED RATIO1:7,03
999
TRANSMISSION S 5-90 OVERDRIVE WITH GV 90,1ST SPEED RATIO1:7,03
999
SPACER WASHER AS REQUIRED 0.30 MM
999
BUSHING 5TH SPEED GEAR
999
SLIDING COLLAR 5TH AND 6TH SPEED, WITH AK 6-90 UP TO TRANSMISSION 068147,WITH AK 6-80 UP TO TRANSMISSION 279573
999
SYNCHRONIZER HUB 5TH AND 6TH SPEED
999
SYNCHRONIZER HUB 3RD AND 4TH SPEED
999
SHIFT LEVER
999
BEARING BRACKET
999
SPRING
999
SPACER WASHER SLIDING BLOCK TO SHIFT LEVER
999
SHIFTING FORK 5TH AND 6TH SPEED
999
FOLLOWER REVERSE SPEED
999
SHAFT
999
SHIFTING ROD
999
SHIFTING ROD
999
SHIFTING ROD
999
SHIFTING ROD
999
SPRING
999
HOUSING CLUTCH
999
LEVER CLUTCH ACTUATION
999
TRANSMISSION , Replaced By: A3462604301
999
TRANSMISSION , Replaced By: A3462604601
999
TRANSMISSION
999
TRANSMISSION S 6-90 HILL GEAR WITH GV 90,1ST SPEED RATIO1:9,01,6TH SPEED RATIO1:2,65
999
TRANSMISSION , Replaced By: A3462604901
999
TRANSMISSION ADDITIONAL CLUSTER GEARBOX GV90
999
TRANSMISSION ADDITIONAL CLUSTER GEARBOX GV90, /4 - /6 FROM TO IDENT NO. 992002
999
TRANSMISSION S 6-90 HILLGEAR,WITH GV 90 1ST SPEED RATIO 1/9,01 6TH SPEED RATIO 1:1,0
999
SHIFT LEVER LATERAL P.T.O.
999
TRANSMISSION , Replaced By: A3462601900
999
SHIFTING ROD , FROM CHASSIS 992002
999
ELECTRIC CABLE FROM CONNECTION POINT TO ADDITIONAL GEARBOX VALVE
999
REST LEAF SPRING TO CAB, ON L/LA 2624 UP TO CHASSIS 969301,ON L/LA 1624 AND L/LA 1924 UP TO CHASSIS 4 324130,ALSO INSTALLED ON 500001-536071
999
BRACKET LEFT
999
BRACKET RIGHT,4 195521
999
PLUG SOCKET , Replaced By: A3805402181
999
PLUG SOCKET REPAIR VERSION, NOT FOR DANGER CATEGORY VEHICLES M 24X1
999
SCREW
999
SCREWM 5X20
999
COTTER PINROCKINGER TYP 260 G140
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
SCREW , Replaced By: N304017006012
999
SCREW , Replaced By: N000933010192
999
SCREW OIL LINE TO CRANKCASE
999
SCREW EXHAUST PIPE TO BRACKET
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
NUT BALL PIVOT TO LEVER
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
NUT , Replaced By: N308675014000
999
STUD BOLT ADDITIONAL GEARBOX TO TRANSMISSION CASE M 10X30
999
STUD BOLT BEARING COVER TO TRANSMISSION CASE, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
999
FITTED WASHER AS REQUIRED 18X25X1.0 MM
999
FITTED WASHER AS REQUIRED 1.20 MM
999
FITTED WASHER AS REQUIRED 1.4 MM
999
WASHER , Replaced By: N007349010007
999
WASHER STRUT TO CROSS MEMBER
999
INSULATING HOSE BLACK 12 X 0,8 MM
999
CLAMP TO CONNECT THE FUEL LINES
999
BALL STUD. BALL PIVOT PULL ROD TO BRACKET
999
CLAMP , Replaced By: A1279950020
999
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
999
NUT , Replaced By: N304032005005
999
NUT IN CASE OF SUBSEQUENT INSTALLATION
999
NUT , Replaced By: N308675014002
999
NUT RELEASE BEARING LUBRICATION
999
LOCK WASHER BRACKET TO STEERING COLUMN END
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
HANDLE
999
LOCK DRIVE SHAFT,047092
999
CLAMP , Replaced By: A0005460875
999
LOCK
999
WASHER
999
SPACER TUBE
999
WASHER
999
CONNECTOR SHIFT LEVER TO LEVER
999
SHIFT LEVER , UP TO CHASSIS:10/20 946631,50/60 936064, Replaced By: A3352603039, +001A0015452411, +001A0005450730, +001A0005450830, +001A0005453837, +001A0029906251
999
BOOT SHIFT LEVER
999
SHIFT LEVER FOR HILL GEAR AND FRONT AXLE DRIVE
