Поз.
Артикул
Описание
10
PROPELLER SHAFT FROM TRANSMISSION TO INTERMEDIATE BEARING 1317 MM, THE SPECIFIED LENGTH DIMENSION "L" IST THE DISTANCE BETWEEN FLANGE OUTER FACE SHAFT END
10
PROPELLER SHAFT FROM TRANSMISSION TO PROPELLER SHAFT BEARING 1361 MM
20
GREASE NIPPLE PROTECTIVE TUBE
21
PROTECTIVE CAP
22
DRIVE FLANGE
24
26
GREASE NIPPLE
26
GREASE NIPPLE
34
LOCK2.025 MM
34
LOCK2.050 MM
34
LOCK2.000 MM
34
LOCK2.075 MM
34
LOCK RING52X2 MM
34
LOCK2.100 MM
40
HOUSING INTERMEDIATE BEARING NO.1
45
BEARING RING INTERMEDIATE BEARING NO.1
50
BALL BEARING INTERMEDIATE BEARING NO.1
55
RUBBER MOUNTING INTERMEDIATE BEARING NO.1
60
CENTERING FLANGE INTERMEDIATE BEARING NO.1
65
NUT FOLLOWER FLANGE TO PROPELLER SHAFT TO 384 410 70 30
65
NUT COUPLING FLANGE TO DRIVE SHAFT,5 298189
75
85
90
SCREW CONSOLE TO BRACKET M 12X1.5X25,20 L
92
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
94
DISK , Replaced By: A1232420366
100
REINFORCEMENT
105
SCREW VIBRATION ABSORBER TO FRAME M 12X1.5X55
105
SCREW BRACKET TO FRAME M 12X35
105
SCREW LEFT AND RIGHT CONSOLES TO FRAME M 12X1.5X50
105
SCREW AIR RESERVOIR CONSOLE TO SIDE MEMBER
113
NUT ALTERNATOR TO SUPPORT
130
PROPELLER SHAFT INTERMEDIATE BEARING TO REAR AXLE 1354 MM, THE SPECIFIED LENGTH DIMENSION IS THE DISTANCE BETWEEN BOTH OUTER FLANGE FACES WHEN FULLY TELESCOPED
140
GASKET
141
GASKET
143
SEAL HOLDER
144
GREASE NIPPLE INTERMEDIATE LEVER
146
DRIVE FLANGE
148
150
GREASE NIPPLE
150
GREASE NIPPLE
151
LOCK2.025 MM
151
LOCK2.050 MM
151
LOCK2.000 MM
151
LOCK2.075 MM
151
LOCK RING52X2 MM
151
LOCK2.100 MM
160
SCREW PROPELLER SHAFT TO TELMA BRAKE
162
LOCK WASHER SUPPORT TO SIDE MEMBER
164
NUT SPRING BOLT
175
BRACKET PROPELLER SHAFT RETAINING STRAP
175
REBOUND STRAP , Replaced By: A3504100040
176
MOUNTING PLATE BRACKET
177
SCREW COLD START SYSTEM TO BRACKET
178
LOCK WASHER , Replaced By: N912004010102
999
999
UNIVERSAL JOINT
999
LOCK2.000 MM
999
INTERMEDIATE BEARING REPAIR KIT
