Поз.
Артикул
Описание
606
TANK
609
FILTER ELEMENT ,D 441028D 523393
612
FITTING , 993034
615
SEAL RINGTO 000 466 38 02
618
BRACKETTO 345 466 70 02
621
CONNECTOR ,12068001, 344.030,031,032,03312009118, 345.001,002,003,300
621
CONNECTOR ,12068001, 344.030,031,032,03312009118, 345.001,002,003,300
624
NUT
627
CENTERING RINGTO 000 466 38 02
630
WASHER , Replaced By: A9402680552
633
SPACER TUBETO 000 466 38 02
636
PIPETO 000 466 38 02
639
COVERTO 000 466 38 02
642
SEAL RINGTO 000 466 38 02
645
FILTER SUPPORT
648
RUBBER SLEEVETO 000 466 38 02
651
STRUT
651
REINFORCEMENT , Replaced By: A0004660095
654
BRACKET
657
SCREW BRACKET TO SIDE MEMBER
660
LOCK WASHER , Replaced By: N912004010102
663
NUT BRACKET TO SIDE MEMBER,XB209706
665
SCREW BRACKET TO RETARDER
668
LOCK WASHER , Replaced By: N912004010102
671
NUT BRACKET TO SIDE MEMBER,XB209706
675
LINE FROM STEERING TO OIL TANK
677
UNION NUT LINE CONNECTION
678
GLAND LINE CONNECTION
680
HOSE FROM STEERING TO OIL TANK
685
CLAMP AIR COMPRESSOR
685
CLAMP HOSE TO HEATING PIPE
685
LOOM TIE. CLAMP HOSE TO FLANGE AND TO VALVE
685
LOOM TIE HOSE TO HEATING PIPE
685
LOOM TIE , Replaced By: N916017020000
695
SCREW-IN FITTING RETURN LINE TO STEERING
698
SEAL RING ON OIL PUMP HOUSING
720
LINE FROM POWER STEERING PUMP TO STEERING
725
UNION NUT LINE CONNECTION, Replaced By: N000000006239
730
GLAND , Replaced By: A0019901967
738
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
738
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
738
HOSE , Replaced By: A0019972652
742
LINE FROM POWER STEERING PUMP TO STEERING
744
UNION NUT LINE CONNECTION, Replaced By: N000000006239
746
GLAND , Replaced By: A0019901967
750
SCREW-IN FITTING OIL LINE CONNECTION
754
SEAL RING TO MOUNT FUEL LINES 16X22 - TO A 688 470 00 90
758
LINE FROM OIL TANK TO HOSE
760
GLAND , Replaced By: A0019901267
762
UNION NUT LINE CONNECTION, Replaced By: N000000006243
764
LINE FROM OIL TANK TO PUMP
766
GLAND , Replaced By: A0019901267
768
UNION NUT LINE CONNECTION, Replaced By: N000000006243
770
HOSE , Replaced By: A3849977482
770
HOSE , Replaced By: A3859971582
770
HOSE , Replaced By: A3609970982
792
CLAMP ,B 862667
792
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK
792
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
792
LOOM TIE , Replaced By: N916017025000
799
BRACKET DELIVERY AND SUCTION LINES TO RADIATOR CONSOLE,684470
802
BRACKET
802
BRACKET DELIVERY LINE TO FRAME,684471HB746809
805
CLAMP DELIVERY AND SUCTION LINES TO RADIATOR CONSOLE
805
CLAMP LINES TO BRACKET
805
CLAMP , Replaced By: N916016012201
806
SCREW RETURN AND SUCTION LINES TO FRAME, FRONT M 12X40
806
SCREW BEARING BRACKET TO SIDE MEMBER
807
WASHER SUPPORT TO FRAME,D 127794
808
NUT STRAP TO SUPPORT,5 149419
809
LOCK WASHER FITTING TO BRACKET
810
CLAMP DELIVERY AND SUCTION LINES TO FRAME
810
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
810
CLAMP , Replaced By: N916016022202
815
SCREW LINES TO BRACKET
815
SCREW LINES TO BRACKET
820
SCREW PLUG SOCKET TO FRAME
825
LOCK WASHER RAIL TO BATTERY SUPPORT
830
WASHER TRAILER PLUG SOCKET TO BRACKET
830
WASHER TRAILER PLUG SOCKET TO BRACKET
835
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
835
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
835
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
839
NUT , Replaced By: N304032008006
841
LOCK WASHER RAIL TO BATTERY SUPPORT
999
BOOT , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0003301185
999
PIN AS REQUIRED 6.04MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
PIN AS REQUIRED 6.05 MM, UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
PIN AS REQUIRED 6.06 MM
999
VALVE
999
SCREW COLLAR STEERING NUT BEARING, 738939 WAS PART OF SA'S 19075 AND 31193 UP TO CHASSIS 738938
999
STEERING NUT
999
BALL CAGE
999
PIN STEERING NUT BEARING, 738939 WAS PART OF SA'S 19075 AND 31193 UP TO CHASSIS 738938
999
PISTON , 738939 WAS PART OF SA'S 19075 AND 31193 UP TO CHASSIS 738938
999
LOCK
999
LOCK , UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
SCREW
999
BALL RACE
999
PISTON
999
BUSHING
999
HOUSING
999
FILTER , Replaced By: A0004660604
999
REPAIR KIT
999
NEEDLE BEARING
999
INNER RING38.00 MM
999
INNER RING38.015 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SCREW BREATHER, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
NUT , Replaced By: A0009901562
999
NUT
999
SPACER WASHER AS REQUIRED 2.95 MM
999
SPACER WASHER AS REQUIRED 3.05 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.10 MM
999
SPACER WASHER AS REQUIRED 3.15 MM
999
SPACER WASHER AS REQUIRED 3.20 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.25 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.30 MM
999
SPACER WASHER AS REQUIRED 3.35 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.40 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
FILTER CARRIERTO 000 466 38 02
999
NEEDLE BEARING
999
NEEDLE BEARING
999
NEEDLE BEARING
999
NEEDLE BEARING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
BALL AS REQUIRED 8.990 MM
999
BALL AS REQUIRED 8.991 MM
999
BALL AS REQUIRED 8.992 MM
999
BALL AS REQUIRED 8.993 MM
999
BALL AS REQUIRED 8.994 MM
999
BALL AS REQUIRED 8.995 MM
999
BALL AS REQUIRED 8.996 MM
999
BALL AS REQUIRED 8.997 MM
999
BALL AS REQUIRED 8.998 MM
999
BALL AS REQUIRED 8.999 MM
999
BALL AS REQUIRED 9.000 MM
999
BALL AS REQUIRED 9.001 MM
999
BALL AS REQUIRED 9.002 MM
999
BALL AS REQUIRED 9.003 MM
999
BALL AS REQUIRED 9.004 MM
999
BALL AS REQUIRED 9.005 MM
999
BALL AS REQUIRED 9.006 MM
999
BALL AS REQUIRED 9.007 MM
999
BALL AS REQUIRED 9.008 MM
999
BALL AS REQUIRED 9.009 MM
999
BALL AS REQUIRED 9.010 MM
999
BALL AS REQUIRED 9.011 MM
999
SPACER WASHER AS REQUIRED 2.97 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 2.99 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.02 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.03 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.06 MM
999
SPACER WASHER AS REQUIRED 3.07 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.09 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.11 MM
999
SPACER WASHER AS REQUIRED 3.13 MM
999
SPACER WASHER AS REQUIRED 3.14 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.16 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.19 MM
999
SPACER WASHER AS REQUIRED 3.21 MM
999
SPACER WASHER AS REQUIRED 3.23 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.24 MM
999
SPACER WASHER AS REQUIRED 3.26 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.27 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.29 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.31 MM
999
SPACER WASHER AS REQUIRED 3.32 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.37 MM, UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.38 MM
999
BALL AS REQUIRED 9.012 MM
999
BALL AS REQUIRED 9.013 MM
999
BALL AS REQUIRED 9.014 MM
999
BALL AS REQUIRED 9.015 MM
999
SPACER WASHER AS REQUIRED 2.950 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 2.975 MM
999
SPACER WASHER AS REQUIRED 3.000 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.025 MM
999
SPACER WASHER AS REQUIRED 3.050 MM
999
SPACER WASHER AS REQUIRED 3.075 MM
999
SPACER WASHER AS REQUIRED 3.100 MM
999
SPACER WASHER AS REQUIRED 3.125 MM
999
SPACER WASHER AS REQUIRED 3.150 MM
999
SPACER WASHER AS REQUIRED 3.175 MM, UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.200 MM
999
SPACER WASHER AS REQUIRED 3.225 MM, UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.250 MM, UP TO CHASSIS 414221 FROM CHASSIS 414222 SEE SPARE PARTS 766.1
999
SPACER WASHER AS REQUIRED 3.275 MM
999
NEEDLE BEARING
999
LOCK
999
SEAL RING , Replaced By: A0169978948
999
SEAL RING
999
SEAL RING , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SCREW , Replaced By: A3169900114
999
STEERING WHEEL , Replaced By: A3454607003
999
STEERING WHEEL , Replaced By: A3454607003
999
DRAG LINK ,367215
999
DRAG LINK ,367215
999
STEERING SHAFT , Replaced By: A3504620101, +002A3164600057, +004A3169900114, +004N913004008005
999
PITMAN ARM ,367215
999
LINE FROM STEERING TO OIL TANK
999
UNIVERSAL JOINT , UP TO IDENT NO. 709912 EXCEPT FOR 500001-599999
