Поз.
Артикул
Описание
49
GROUND CABLE FROM ALTERNATOR TO FRAME SIDE MEMBER, UP TO IDENT NO. 727921 EXCEPT FOR,500001-599999,FROM IDENT NO. SEE ENGINE MICROFICHE
51
GROUND STRAP , 10,20 UP TO IDENT NO.7333026 EXCEPT FOR 500001-599999, Replaced By: A3525400041
51
GROUND STRAP FROM STARTING MOTOR TO SIDE MEMBER,5 193595
54
REGULATOR AND CUT-OUT , Replaced By: A3455477002
54
REGULATOR AND CUT-OUT , Replaced By: A0021547406
54
REGULATOR AND CUT-OUT ,4 477130
56
SCREW BRACKET TO COVERING
56
SCREW , Replaced By: N000000001145
57
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
58
NUT BALL PIVOT TO LEVER
61
HORN , Replaced By: A0035423220
61
HORN , Replaced By: A0035423220
64
CLAMP CABLE HARNESS MOUNTING,4 494992
64
CLAMP , Replaced By: A0005460875
65
SCREW BRACKET TO SIDE MEMBER
65
SCREW , Replaced By: N304017010002
66
WASHER RADIATOR TO RUBBER MOUNTING
66
WASHER , Replaced By: N000125010532
67
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
68
NUT BRACKET TO SUPPORT AND TO END PIECE
68
NUT BATTERY CABLE
80
SENDER UNIT HAZARD WARNING LIGHT, UP TO IDENT NO. 655197 EXCEPT FOR 500001-599999
84
SENDER UNIT , Replaced By: A0025447732
84
SENDER UNIT , FIRST EXHAUST STOCK OF OLD PARTS UP TO CHASSIS 4 465288, Replaced By: A0025447732
84
SENDER UNIT ELECTRONIC 12 V
87
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
87
SHEET METAL SCREW BRACKET TO FLOOR PLATE
140
SWITCH , Replaced By: A0005455909
140
SWITCH , Replaced By: A0005455909
140
SWITCH DUMPER VALVE
144
CABLE HARNESS CAB MAIN CABLE HARNESS,5 107261
144
CABLE HARNESS CAB MAIN CABLE HARNESS,4 4780025 005483
144
CABLE HARNESS CAB MAIN CABLE HARNESS,4 4780025 005483
144
CABLE HARNESS CAB MAIN CABLE HARNESS,5 107261
144
CABLE HARNESS CAB MAIN CABLE HARNESS,5 0054845 107260
144
CABLE HARNESS , Replaced By: A3525409705
144
CABLE HARNESS CAB MAIN CABLE HARNESS, UP TO IDENT NO. 655197 EXCEPT FOR 500001-599999
144
CABLE HARNESS CAB MAIN CABLE HARNESS, FROM IDENT NO. 655198 ALSO INSTALLED ON 500001-5999994 478001
144
CABLE HARNESS , Replaced By: A3525409805
144
CABLE HARNESS CAB MAIN CABLE HARNESS,5 0054845 107260
144
CABLE HARNESS CAB MAIN CABLE HARNESS, FROM IDENT NO. 655198 ALSO INSTALLED ON 500001-5999994 478001
147
PIN BUSHING HOUSING 3-POLE,4 483482
149
PIN BUSHING HOUSING , UP TO IDENT NO. 655197 EXCEPT FOR 500001-599999
151
PLUG HAZARD WARNING LIGHT SWITCH, FROM IDENT NO. 655198 ALSO INSTALLED ON 500001-5999995 107260
154
PIN BUSHING HOUSING. PLUG HOUSING FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH
157
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
157
PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 2.5 MM2
158
PIN BUSHING HOUSING UNIPOLAR
159
PIN BUSHING HOUSING BIPOLAR
160
PIN BUSHING HOUSING 3-POLE
161
PIN BUSHING HOUSING 4-POLE
162
PIN BUSHING HOUSING 4-POLE
164
PIN BUSHING HOUSING 6-POLE
166
PIN BUSHING HOUSING 8-POLE
168
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
168
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
174
PIN BUSHING , Replaced By: A0075457426
174
PIN BUSHING OFFSET 4 MM2
175
BOOT PIN BUSHING
176
CABLE SHOE
177
LOOM TIE LINE MOUNTING 280 MM
180
FUSE BOX TERMINALS 1-2,3-4,5-6,AND 8-12 BRIDGED OVER, FROM IDENT NO. 655198 ALSO INSTALLED ON 500001-599999
181
COMBINATION BOLT CABLE TO FUSE BOX
182
FUSE , Replaced By: N072581008101
182
FUSEA8
184
CAP FUSE BOX, FROM IDENT NO. 655198 ALSO INSTALLED ON 500001-599999
194
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
195
SCREW BRACKET TO TAIL LAMP BRACKET
196
SPRING WASHER CLAMP MOUNTING,4 478001
197
WASHER , Replaced By: N009021005205
197
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
213
CLAMP , Replaced By: A3449957120
214
CLAMP MAIN CABLE HARNESS TO LEFT SIDE PART
215
CLAMP , Replaced By: A3449957120
221
CLAMP , Replaced By: A3449957120
221
CLAMP , Replaced By: A3449957120
223
CLAMP HOSE TO FLANGE AND TO VALVE
229
CLIP
231
CLAMP BRAKE HOSE BRACKET
231
CLAMP BRAKE HOSE BRACKET
237
PIN BUSHING HOUSING BIPOLAR
239
PIN BUSHING , Replaced By: A0075458226
239
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
241
PLUG SOCKET REPAIR VERSION, NOT FOR DANGER CATEGORY VEHICLES M 24X1
241
PLUG SOCKET , Replaced By: A3805400181
241
PLUG SOCKET , Replaced By: A3805402181
275
CABLE GUIDE , FROM IDENT NO. 655198 ALSO INSTALLED ON 500001-599999
280
LOOM TIE , Replaced By: A0019974390
280
LOOM TIE TO MOUNT PLASTIC PIPING
999
POTENTIOMETER FOR INSTRUMENT LIGHTING, UP TO IDENT NO. 655197 EXCEPT FOR 500001-599999
999
KNOB , Replaced By: A3095420189
999
POTENTIOMETER BLOWER
999
COUPLER
999
DIAGRAM PAPER SET100 PIECES
999
LAMP SOCKET
999
LAMP SOCKETHELLA, 884653
999
LAMP SOCKETR & S,4 300928
999
LAMP SOCKETHELLA,4 300928
999
GASKET , Replaced By: A0005448480
999
GASKET , Replaced By: A0005448480
999
GASKETHELLA,4 300928
999
NUT SWITCH TO APPARATUS PLATE
999
BUTTON ABS AND ASR
999
BUTTON
999
COVER. CAP FUSE BOX, UP TO IDENT NO. 655197 EXCEPT FOR 500001-599999
999
CAP WINDSHIELD WIPER,"SLOW-FAST"
999
BOOT PIN BUSHING
999
CAP HOT AIR BLOWER, FROM IDENT NO. 655198 ALSO INSTALLED ON 500001-5999994 348295
999
CAP CAB LAMP, FROM IDENT NO. 655198 ALSO INSTALLED ON 500001-599999
999
BRAKE LIGHT SWITCH. SWITCH , Replaced By: A0005456109
999
SOCKET RANGE SELECTOR,AUTOMATIC TRANSMISSION
999
BUTTON HAZARD WARNING LIGHT SWITCH,5 220080
999
PLUG SOCKET , Replaced By: A0015458526
999
PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 4-6 MM2
999
PLUG SOCKET , Replaced By: A0015458526
999
PIN BUSHING , Replaced By: A0005453726
999
PIN BUSHING WITH DETENT,LESS CATCH FOR HOUSING 6 MM2,5 097182
999
SWITCH , Replaced By: A0015450809
999
COVERING WITH GASKET
999
OIL TANK , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0005500280
999
OIL TANK REPAIR KIT TO 000 550 06 04
999
CAPSULE BORER , Replaced By: A0005501104, +001A0005550010
999
PUMP , Replaced By: A0005501083
999
VALVE REPAIR KIT TO 000 550 00 83
999
PUMP , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 162440, Replaced By: A0005502383
999
PUMP PRIMING FUEL
999
CAPSULE , ON SPECIAL REQUEST
999
PRIMER CAPSULE , 620000, Replaced By: A0005500180
999
CONNECTOR , 620000
999
PIPE , 620000
999
GASKET , 620000, Replaced By: A0005500180
999
SPRING , 620000
999
CAPSULE BORER , 620000
999
STRAINER , 620000
999
CONNECTORTO 000 550 07 04
999
NOZZLE , UP TO IDENT NO. 620000 EXCEPT FOR 500001-599999, Replaced By: A0005500180
999
HANDLE , Replaced By: A0005550440
999
NUT
999
HANDLE
999
SEAL CONE REPAIR KIT
999
RING DRAIN VALVE TO 000 432 08 07, NOT USED
999
BALL , UP TO CHASSIS 620000 EXCEPT FOR, 500001-599999
999
CLIP
999
SCREW , 620000
999
NUT PRESSURE SWITCH SCREW-CONNECTION M 24X1,5 129167
999
SCREW , 620000, Replaced By: A0005500180
999
NUT , Replaced By: A0009949454
999
SCREW , 620000
999
SEAL CONE , Replaced By: A0009949454
999
WASHER PRESSURE SWITCH SCREW-CONNECTION TO M 24X1,5 129167
999
SEAL CONE , Replaced By: A0005550618
999
NUT REPAIR KIT
999
DOWEL PIN , 620000
999
SPRING , 620000
999
SNAP RING , 620000
999
LOCK MAIN CABLE HARNESS TO LEFT SIDE PART
999
SHACKLE , Replaced By: A0019978390
999
EXPANSION PLUG PUSH BUTTON SWITCH, FROM IDENT NO. 674502 ALSO INSTALLED ON 500001-599999
999
GROMMET ,D 314239
999
GROMMET
999
INSTRUMENT CLUSTER , UP TO IDENT NO. 655197 EXCEPT FOR 500001-599999
999
INSTRUMENT CLUSTER , Replaced By: A0015407347
999
HORN , Replaced By: A0025426420
999
FLEXIBLE SHAFT , FIRST EXHAUST STOCK OF OLD PARTS UP TO CHASSIS 5 296454, Replaced By: A0045420507
999
SENDER UNIT , Replaced By: A0015447532
999
SENDER UNIT HAZARD WARNING LIGHT, UP TO IDENT NO. 655197 EXCEPT FOR 500001-599999
999
SENDER UNIT , Replaced By: A0025447332
999
SENDER UNIT12 V, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 465288
999
SWITCH , TO BE ADAPTED DURING ASSEMBLY
999
RESISTOR CHARGE CONTROL,4 477131
999
ROUND PIN BUSHING REAR "ENR" SOLENOID VALVE BRANCH-OFF 0.75-2.5MM2
999
PLUG HOUSING 6-POLE
999
PLUG HOUSING 8-POLE
999
PLUG SOCKET HAND LAMP
999
WASHER MASKED BLINKER-STOP-LICENSE-PLATE LAMP
999
SCREW CONNECTION
999
GROMMET
999
LOOM TIE LINE MOUNTING
999
HORN , Replaced By: A0025426420
999
TEMPERATURE GAUGE , UP TO IDENT NO. 655197 EXCEPT FOR 500001-599999
999
HORN , Replaced By: A0035423220
999
HORN , Replaced By: A6315420120
999
TEMPERATURE GAUGE , Replaced By: A0025426005
999
TEMPERATURE GAUGE , Replaced By: A0025426005
999
SENDER UNIT COOLING WATER TEMPERATURE
999
SENDER UNIT , Replaced By: A0025447332
999
SENDER UNIT HAZARD WARNING LIGHT, 8468155 107260
999
SENDER UNIT BLINKER SYSTEM,B 850492
999
PIN BUSHING HOUSING UNIPOLAR
999
FLAT PIN BUSHING , Replaced By: A0035455326
999
SWITCH,AUTOMATIC HAZARD WARNING LIGHT,5 107260
999
SPRING , Replaced By: A0005500955
999
SEAL RING , UP TO IDENT NO. 620000 EXCEPT FOR 500001-599999
999
HORN
999
HORN , Replaced By: A6315420120
999
SENDER UNIT BLINKER SYSTEM,B 850492
999
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 4-6 MM2
999
FLEXIBLE SHAFT4100 MM
999
PIN BUSHING HOUSING 3-POLE
999
HAZARD WARNG.LIGHT SWITCH. SWITCH,AUTOMATIC
