42 BRAKE SYSTEM
001 24-V ELECTRICAL SYSTEM USED WITH 1500-W GENERATOR AND CUT-OFF RELAY

Mercedes N007981004233 -

LK 1313 352.011

42 BRAKE SYSTEM - 001 24-V ELECTRICAL SYSTEM USED WITH 1500-W GENERATOR AND CUT-OFF RELAY

Поз.
Артикул
Описание
1
A3225050601
RADIATOR SHUTTER
1
A3225050901
RADIATOR SHUTTER , 322 FROM CHASSIS 060545
1
A3225050901
RADIATOR SHUTTER , 322 FROM CHASSIS 060545
1
A3215050201
RADIATOR SHUTTER , 322 UP TO CHASSIS 060544
1
A3215050301
RADIATOR SHUTTER , 322 UP TO CHASSIS 060544
1
A3225051101
RADIATOR SHUTTER , 322 FROM CHASSIS 060545
5
A0005053301
RADIATOR SHUTTER
5
A0005053101
RADIATOR SHUTTER , 322 UP TO CHASSIS 060544
5
A0005053701
RADIATOR SHUTTER , 322 FROM CHASSIS 060545
5
A0005053701
RADIATOR SHUTTER , 322 FROM CHASSIS 060545
9
A0009880175
WIRE CABLE RADIATOR SHUTTER CABLE 1000 MM
9
A0009880975
WIRE CABLE RADIATOR SHUTTER CABLE 1200 MM
11
A3225050210
CABLE PULL
11
A3225050310
CABLE PULL , 322 FROM CHASSIS 060545
11
A3225050410
CABLE PULL , 322 FROM CHASSIS 060545
15
A0005052221
GUIDE
15
A0005052321
GUIDE , 322 FROM CHASSIS 060545
15
A0005052421
GUIDE , 322 FROM CHASSIS 060545
19
A0005051309
CHAIN , 322 FROM CHASSIS 060545
19
A0005051309
CHAIN , 322 FROM CHASSIS 060545
21
A0005050127
FERRULE
22
N007971004109
SHEET METAL SCREW MOUNTING RAIL TO RADIATOR
23
N912004005101
LOCK WASHER LINE MOUNTING
25
A3225050140
BRACKET
27
N007971004223
SHEET METAL SCREW BUZZER TO CAB,4 374617
28
N912004005101
LOCK WASHER LINE MOUNTING
29
A3229970140
SEAL RING AT FIRE WALL
31
A3229900140
WASHER AT FIRE WALL
33
A3129970481
GROMMET GROUND CABLE
999
N912004008102
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
N304032008006
NUT
999
N304017008034
SCREW BRACKET TO CROSS CONNECTION STRUT
999
N007981004233
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
N007516005107
TAPPING SCREW RELAY
999
N000933008153
SCREW , Replaced By: N304017008034
999
N000933008145
SCREW CLAMP TO BRACKET AND TO PIPE
999
N000000000460
SHEET METAL SCREW BRACKET TO FLOOR PLATE
