Поз.
Артикул
Описание
260
OIL PIPE. LINE RETURN LINE TO TRANSMISSION
265
HOSE
265
HOSE
270
OIL PIPE. LINE RETURN LINE TO TRANSMISSION
275
CUTTING RING. GLAND LINE CONNECTION
280
CUTTING RING. GLAND LINE CONNECTION
285
UNION NUT OIL LINE
290
NUT. UNION NUT LINE CONNECTION
295
SCREW-IN FITTING FROM DELIVERY LINE TO STEERING
300
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
305
LINE FROM STEERING TO OIL TANK
310
GLAND LINE CONNECTION
312
UNION NUT LINE CONNECTION
315
TANK
320
COVER , Replaced By: A0004664405
322
SEAL RINGTO 000 466 38 02
324
NUTTO 000 466 38 02
326
OIL DIPSTICK
328
RUBBER SLEEVETO 000 466 38 02
330
CENTERING RINGTO 000 466 38 02
332
REINFORCEMENT , Replaced By: A0004660095
334
FILTER CARRIERTO 000 466 38 02
336
SPACER TUBETO 000 466 38 02
338
FITTING , 993034
338
FITTING , Replaced By: A0004660571
340
SPACER WASHERTO 000 466 38 02
340
WASHER , Replaced By: A9402680552
342
FILTER
342
FILTER
342
FILTER , Replaced By: A0004660604
344
BRACKET
344
BRACKET , Replaced By: A0004660940
348
SEAL RINGTO 000 466 38 02
348
SEAL RING , Replaced By: A0059970848
348
SEALING CORD , Replaced By: A0059970848
350
CONNECTOR ,12068001, 344.030,031,032,03312009118, 345.001,002,003,300
352
CONNECTOR ,12068001, 344.030,031,032,03312009118, 345.001,002,003,300
354
SEAL RING
356
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
358
NUT
360
HEXAGON HEAD BOLT BRACKET TO TRANSMISSION
362
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
370
LINE FROM TANK TO HOSE
370
LINE FROM TANK TO HOSE
370
LINE , Replaced By: A3554601524
370
LINE FROM OIL TANK TO HOSE, 10 FROM CHASSIS 629395,20 FROM CHASSIS 6011094 400445
375
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
375
HOSE , Replaced By: A3859971582
377
CLAMP25-40X13 MM
377
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
377
LOOM TIE , Replaced By: N916017025000
380
LINE FROM HOSE TO POWER STEERING PUMP
380
LINE , Replaced By: A3604603424
385
SEAL CONE LINE CONNECTION
385
GLAND , Replaced By: A0019901267
387
NUT LINE CONNECTION
387
UNION NUT LINE CONNECTION, Replaced By: N000000006243
390
BRACKET WITH STABILIZER ROD TO FRAME
390
BRACKET , Replaced By: A3812952440
395
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
395
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
395
CLAMP LINE MOUNTING
395
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
400
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
400
CLAMP , Replaced By: N916016018202
402
SCREW BRACKET TO CROSS CONNECTION STRUT
402
SCREW , Replaced By: N304017008034
402
SCREW PIPE CLAMP
402
SCREW , Replaced By: N304017008021
402
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
404
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
404
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
406
NUT
406
NUT BRACKET TO SUPPORT AND TO END PIECE
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
999
SCREW LICENSE PLATE TO BRACKET
999
NUT BALL PIVOT TO LEVER
999
SCREW , Replaced By: N304017008027
999
SCREW , Replaced By: N304017006020
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125008443
999
COTTER PIN JOINT TO TIE ROD
999
COTTER PINROCKINGER,TYP 260 G150,260 G140
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PIN4X32, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
999
COTTER PIN LEVER TO SUPPORT
999
LINE , Replaced By: A3604604924
999
LINE FROM STEERING TO OIL TANK,4 428827
999
SCREW STEERING TO STEERING BRACKET, 979738
999
SCREW STEERING TO STEERING BRACKET
999
STEERING BOX ASSEMBLY LESS PITMAN ARM L S 5, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
STEERING BOX ASSEMBLY LESS PITMAN ARM L S 5
999
STEERING BRACKET
999
STEERING BRACKET AT FRAME
999
BOOT UNIVERSAL JOINT COVERING
999
WASHER UNIVERSAL JOINT COVERING
999
SCREW STEERING BRACKET TO FRAME
999
SCREW STEERING TO STEERING BRACKET
999
COVERING , NO.8316INO.7C52INO.7B90INO.9051I II I
999
STEERING BRACKET
999
STEERING BRACKET ,902203
999
NUT STEERING TO STEERING BRACKET TO 327 990 01 14,322 990 09 14
999
PISTON STEERING
999
SEAL RING STEERING NUT BEARING
999
SEAL RING , Replaced By: A0149976947
999
BOOT FIXED PART OF JOINT
999
BOOT FIXED PART OF JOINT
