Поз.
Артикул
Описание
20
FRONT SPRING 8-LEAF, 352.067, 601522-724933 352.068.069, 601522 352.088,089, 600674
20
FRONT SPRING , 352.067,068,069, 601251 352.088,089,097, 600763 ONLY REPLACEABLE BY PAIRS, Replaced By: A3523201902
24
SPRING LEAFNO.1, 352.067, 601522-724933 352.068.069, 601522 352.088,089, 600674
24
SPRING LEAFNO.1, 624667
27
BUSHING
27
BUSHING
30
SPRING LEAF WITH SPRING CLAMP NO.3
30
SPRING LEAFNO. 2, 352.067,068,069, 601251 352.088,089,097, 600763
34
SPRING LEAF WITH SPRING CLAMP NO.3
34
SPRING LEAF , Replaced By: A3523211412, +002A3123240633
40
SPRING CLAMP , TO BE ADAPTED DURING ASSEMBLY
40
SPRING CLAMP ,4 811925, Replaced By: A3123240633
40
SPRING CLAMP AT LEAF N0.3
43
RIVET SPRING CLAMP TO SPRING LEAF
43
RIVET , 654576
47
SPRING LEAF LESS SPRING CLAMP NO.4
49
SPRING CLAMP , TO BE ADAPTED DURING ASSEMBLY
49
SPRING CLAMP ,4 811925, Replaced By: A3123240633
49
SPRING CLAMP AT SPRING LEAF NO.7
51
RIVET SPRING CLAMP TO SPRING LEAF
51
RIVET , 654576
56
SHIM
60
SPACER TUBE SPRING CLAMP
60
SPACER TUBE SPRING CLAMP TO SPRING LEAF,5 484790
60
SPACER TUBE , Replaced By: A0003213253
64
SCREW 3/2-WAY VALVE TO BRACKET
64
SCREW , Replaced By: N304014008009
67
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
67
NUT , Replaced By: N913004008001
72
SPRING BOLTM 12X155
74
NUT STRAP TO SUPPORT,5 149419
100
SHACKLE FRONT-SPRING CENTRAL BRACKET VORDERACHSE II
100
SHACKLE FRONT SPRING REAR BRACKET
100
SHACKLE FRONT SPRING SUSPENSION,REAR
105
BUSHING
105
BUSHING
110
SHACKLE PIN PARTS KIT
110
REPAIR KIT , Replaced By: A3853200165
110
REPAIR KIT , Replaced By: A3855860332
113
GREASE NIPPLE
113
GREASE NIPPLE
113
GREASE NIPPLE PROTECTIVE TUBE
119
WASHER AS REQUIRED 4.30 MM
119
WASHER AS REQUIRED 4.20 MM
119
WASHER , Replaced By: A3523230476
119
WASHER AS REQUIRED 4.00 MM
119
WASHER , Replaced By: A3523230376
119
WASHER , Replaced By: A3523230376
119
WASHER , Replaced By: A3523230376
124
SEAL RING SPRING SUSPENSION
128
BOLT SPRING SHACKLE TO SPRING REAR BRACKET
130
WASHER RADIATOR TO RUBBER MOUNTING
130
WASHER , Replaced By: N000125010532
132
NUT STRAP TO BRACKET
132
NUT , Replaced By: N910113010000
138
PLATE FRONT SPRINGS TO FRONT AXLE
138
PLATE
140
HELPER SPRING ,6951998 0000014 168249, Replaced By: A3183240008, +001A3143310727, +001A3143310827
140
RUBBER BUFFER SPRING STOP TO FRAME BOTTOM SIDE, 624667
146
U-BOLT FRONT SPRINGS TO FRONT AXLE M18X1,5X230 MMTO 695 320 02 02
150
NUT , Replaced By: N000934018001
155
SHIM FRONT AXLE,RIGHT
155
SHIM FRONT AXLE,RIGHT
999
RUBBER MOUNTING004 326 01 00
999
SPACER TUBE , Replaced By: A0003230553
999
RUBBER BUFFER , Replaced By: A0003233144
999
RUBBER MOUNTING TOP AND BOTTOM TO 675 326 11 00
999
RUBBER BUFFER SHOCK ABSORBER,BOTTOM TO 003 326 45 00, Replaced By: A0003238085
999
RUBBER MOUNTINGTO 003 326 46 00
999
SEAL RING ,478039
999
WASHER ,478039
999
SEAL RING ,478039
999
RUBBER BUFFER , Replaced By: A0003230785
999
BUSHING , Replaced By: A3443267250
999
RUBBER MOUNTING ,478039
999
JOINT BEARING
999
PIN ,478039
999
BRACKET RIGHT
999
SPRING LEAFNO. 3, 352.067,068,069, 601251 352.088,089,097, 600763
999
SPRING LEAFNO. 4, 352.067,068,069, 601251 352.088,089,097, 600763
999
SHACKLE PIN , Replaced By: A3855860332
999
SPRING LEAF
999
SPRING LEAFNO.7,TO 352 320 11 06, UP TO IDENT NO.: 691430 EXCEPT FOR 691039,691051,691063,691081,691084,691093,691126,691129,691139,691146,691152,691275,691360, 691363,691370,691377,691400,691408,691411,691417,691420 TO 352 320 11 06
999
SPRING LEAFNO.9
999
SPRING LEAF
999
SPRING LEAFNO.7
999
SPRING LEAFNO.5
999
PLATE
999
SHACKLE PIN , Replaced By: A3855860232
999
PIN TORSION BAR TO BEARING BRACKET,D 005410
999
BRACKET BEARING BRACKET TO FRAME,5 1310715 136646
999
BRACKET BEARING BRACKET TO FRAME
999
BRACKET BEARING BRACKET TO FRAME,5 136647
999
LOCK
999
PIN ARTICULATED ROD TO LEVER,D 012295
999
SPACER TUBE BEARING BRACKET TO STEERING COLUMN BRACKET
999
CONSOLE TORSION BAR,4 369364
999
BRACKET AT SHOCK ABSORBER BRACKET
999
BRACKET STABILIZER TO FRONT AXLE
999
SHACKLE PIN (PARTS KIT) FRONT SPRING TO FRONT SPRING BRACKET
999
SHACKLE PIN , Replaced By: A3855860332
999
SHACKLE PIN , Replaced By: A3855860232
999
REPAIR KIT , Replaced By: A3855860232
999
REPAIR KIT , Replaced By: A3853200065
999
STIFFENING TORSION BAR,RIGHT,4 714334
999
STIFFENING TORSION BAR,LEFT,4 714334
999
BRACKET LEFT SHOCK ABSORBER
999
SHIM BRACKET TO SPRING SADDLE
999
BRACKET TORSION BAR
999
LOCK RING TORSION BAR TO LINK,5 903513
999
SCREW SUPPORT TO CROSS MEMBER M 10X28
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
999
SCREW BEARING TO TRANSFER CASE M 14X140
999
SCREW BRACKET TO CONSOLE
999
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
999
SCREW BRACKET TO SUPPORT
999
LOCK RING SHACKLE TO TORSION BAR
999
SERRATED WASHER BEARING BRACKET AND PLATE TO FRAME
999
GREASE NIPPLE
999
GREASE NIPPLE
999
NUT BATTERY CABLE
999
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
999
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
999
SCREW CONSOLE TO FRAME
999
NUT SUPPORT TO SIDE MEMBER
999
NUT BRACKET TO SIDE MEMBER
999
NUT CONSOLE TO SUPPORT
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
