Поз.
Артикул
Описание
5
PLATE ACCELERATOR PEDAL
5
PLATE , Replaced By: A3523000902
8
BALL PIVOT
12
PIN ACCELERATOR PEDAL TO CAB
12
PIN PEDAL TO CAB FLOOR
16
COVERING ACCELERATOR PEDAL
21
ROD CONTROL ROD TO ACCELERATOR PEDAL LEVER
21
ROD , Replaced By: A3523009615
21
ROD LOAD SENSOR CONTROL
21
ROD , Replaced By: A3604302692
25
NUT BALL PIVOT TO LEVER
29
BALL SOCKET PULL ROD TO LEVER
29
BALL SOCKET , Replaced By: A0009912422
29
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
33
SHAFT ACCELERATOR PEDAL CONTROL, 067,068,069 4 667209 088,089,097 4 758189
35
LEVER (FOLLOWER LEVER),4 6033974 667210
38
BUSHING
42
BUSHING , USED WITH AIR BRAKE
46
SCREW , USED WITH AIR BRAKE
51
WASHER COMPRESSED AIR LINE TO BRACKET
51
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
55
NUT BALL PIVOT TO LEVER
59
FITTED WASHER , USED WITH AIR BRAKE
61
LEVER
64
BUSHING
67
BALL PIVOT LEVER
67
BALL PIVOT , Replaced By: A3129910120
71
GREASE NIPPLE
76
ROD FROM INTERMEDIATE LEVER TO ENGINE
77
NUT BALL PIVOT TO LEVER
81
BALL SOCKET PULL ROD TO LEVER
81
BALL SOCKET , Replaced By: A0009912422
88
PAD ACCELERATOR PEDAL
88
PLATE ACCELERATOR PEDAL
88
PLATE , Replaced By: A3523000602, +001A3523010082
88
PLATE ACCELERATOR PEDAL
93
PIN ACCELERATOR PEDAL TO CAB
93
PIN PEDAL TO CAB FLOOR
97
ROD CONTROL ROD TO ACCELERATOR PEDAL LEVER
97
ROD FROM ACCELERATOR PEDAL TO FRONT INTERMEDIATE LEVER
102
BALL SOCKET PULL ROD TO LEVER
102
BALL SOCKET , Replaced By: A0009912422
106
NUT BALL PIVOT TO LEVER
111
SCREW CONTROL LEVER TO INJECTION PUMP LEVER
111
BALL PIVOT CONTROL LEVER TO INJECTION PUMP LEVER, Replaced By: N000000004467
115
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
118
NUT BALL PIVOT TO LEVER
122
LEVER CONTROL SHAFT, 601109
122
LEVER CONTROL SHAFT, 601108
125
BALL PIVOT LEVER
125
BALL PIVOT , Replaced By: A3129910120
125
BALL PIVOT LEVER
129
SHAFT INTERMEDIATE SHAFT
129
SHAFT (CONTROL SHAFT), 601108
133
LEVER CONTROL SHAFT
137
LEVER MANUAL CONTROL
137
LEVER , Replaced By: A3523001217
140
SCREW , USED WITH AIR BRAKE
144
BUSHING , USED WITH AIR BRAKE
147
BUSHING
151
WASHER COMPRESSED AIR LINE TO BRACKET
151
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
156
NUT BALL PIVOT TO LEVER
160
PULL ROD FROM INTERMEDIATE LEVER TO ENGINE, 10/20 FROM CHASSIS 879084,50/60 FROM CHASSIS 880343
170
KNOB WITH SPINDLE AND WIRE CABLE
170
KNOB , Replaced By: A3523001407
170
KNOB , Replaced By: A3523001407
170
KNOB , Replaced By: A3523001407
170
KNOB , Replaced By: A3523001407
175
TUBE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3123021006
175
TUBE , Replaced By: A3523020006
175
TUBE MANUAL CONTROL,4 155516
180
WIRE CABLE , UP TO IDENT NO. 4 155516 ALSO INSTALLED ON 500001-521292
180
WIRE CABLE , Replaced By: A3523000230
180
WIRE CABLE , Replaced By: A3523000230
180
WIRE CABLE , Replaced By: A3523000230
186
KNOB , FROM IDENT NO. 739256 ALSO INSTALLED ON:500001-599999 UP TO IDENT NO. 4 155516 ALSO INSTALLED ON 500001-521292
186
KNOB , Replaced By: A3523020201
186
KNOB , UP TO IDENT NO. 739255 EXCEPT FOR 500001-599999, Replaced By: A3523020201, +001A3523020308
186
KNOBTO 323 300 00 07
191
WASHER , UP TO IDENT NO. 4 155516 ALSO INSTALLED ON 500001-521292
191
WASHER MANUAL CONTROL,4 155516
195
GUIDE , FROM IDENT NO. 739256 ALSO INSTALLED ON:500001-599999 UP TO IDENT NO. 4 155516 ALSO INSTALLED ON 500001-521292
195
GUIDE , Replaced By: A3523020308
195
GUIDE , UP TO IDENT NO. 739255 EXCEPT FOR 500001-599999, Replaced By: A3523020308, +001A3523020201
199
NUT , UP TO IDENT NO. 4 155516 ALSO INSTALLED ON 500001-521292
204
BRACKET MANUAL CONTROL
209
BRACKET MANUAL CONTROL
209
BRACKET , Replaced By: A3523021440
209
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 355269, Replaced By: A3523021440
213
GROMMET MANUAL CONTROL,4 603397
213
GROMMET WIRE CABLE TO MOUNTING CLAMP, FROM IDENT NO. 4 155517 ALSO INSTALLED ON:500001-599999
213
GROMMET WIRE CABLE TO MOUNTING CLAMP, FROM IDENT NO. 4 155517 ALSO INSTALLED ON:500001-599999
213
GROMMET WIRE CABLE TO MOUNTING CLAMP, FROM IDENT NO. 4 155517 ALSO INSTALLED ON:500001-599999
213
GROMMET , Replaced By: A3453027091
217
BEFESTIGUNGSSCHELLE. CLAMP WIRE CABLE TO BRACKET
220
BRACKET
220
BRACKET , Replaced By: A3813020240
999
COVERTO 323 300 00 07
999
WASHER , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3559940016
999
LEVER , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3523001117
999
LOCK IDLE SWITCH TO BRACKET
999
STOP ACCELERATOR PEDAL
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
COTTER PIN LEVER TO ROD
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER BOOT TO CAB FLOOR
999
NUT , Replaced By: N304035008001
999
NUT POSITIVE CABLE TO STARTING MOTOR, TERMINAL: 30
999
LOCK RING , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
SCREW CONSOLE TO REAR CROSS MEMBER M 8X38
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017006020
999
SCREW , Replaced By: N304017006016
999
SCREW , Replaced By: N304017008040
999
SCREW , Replaced By: N304017008016
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
SCREW BRACKET TO SUPPORT
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
SNAP RING SPRING-LOADED PUSH ROD
999
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
999
SECURING CLIP CABLE
999
SCREW PUMP TO BRACKET
999
SCREW LICENSE PLATE TO BRACKET
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW BRACKET TO SIDE MEMBER
999
NUT
999
NUT
999
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
999
HEXALOBULAR BOLT. SCREW MANUAL PUMP BRACKET TO FENDER BRACKET
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
