Главная
›
Mercedes
›
ENGINE
›
M 352
›
352.929
›
03 MOVING PARTS
›
001 INTERMEDIATE FLANGE AND INTERMEDIATE HOUSING AT TRANSMISSION IL.2
Mercedes N000137012203 - ШАЙБА ПОД 3*Ю ОПОРУ ДВ-ЛЯ / FEDERSCHEIBE
M 352 352.929
03 MOVING PARTS - 001 INTERMEDIATE FLANGE AND INTERMEDIATE HOUSING AT TRANSMISSION IL.2
Поз.
Артикул
Описание
23
A3522510008
INTERMEDIATE PIECE
94
N304017012020
SCREW END PIECE TO EXHAUST PIPE M 12X30
94
N000933012056
SCREW , Replaced By: N304017012020
101
N912004012100
LOCK WASHER FITTING TO BRACKET
109
A0122510201
BELL HOUSING
117
N000933012071
SCREW BRACKET TO SIDE MEMBER M 12X40
126
N000137012203
SPRING WASHER CAB FLOOR
135
A0122510204
END COVER
144
N006503060100
SEAL RING
153
N000835010037
STUD
162
N912004010102
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
171
N000934010014
NUT BRACKET TO SUPPORT AND TO END PIECE
180
A0122510033
COVER
189
N304017008016
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
189
N000933008212
SCREW , Replaced By: N304017008016
198
N912004008102
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
207
A0122510304
END COVER
216
N000835010037
STUD
225
N912004010102
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
234
N000934010014
NUT BRACKET TO SUPPORT AND TO END PIECE
