Поз.
Артикул
Описание
88
GASKET WATER PUMP TO CYLINDER CRANKCASE
92
LOCK PLATE , Replaced By: A0000710473
92
LOCK
93
SCREW WATER PUMP COVER TO WATER PUMP HOUSING M 8X28
104
SCREW CLUTCH TO FLYWHEEL
104
SCREW. HEXAGON HEAD BOLT TRANSMISSION CASE M10X80
110
GASKET , Replaced By: A3522032380
110
GASKET1 MM
112
HOUSING THERMOSTAT HOUSING
116
INTERMEDIATE PIECE
118
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
120
COMBINATION BOLT OIL COOLER TO CYLINDER CRANKCASE M 8X45, FROM ENGINE 351139 YEAR OF MANUFACTURE 1994
122
SEAL RING VALVE TO VALVE,K 025179
124
ADAPTER FITTING COOLING WATER LINE
125
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
128
SCREW PLUG
128
SCREW PLUG WATER DRAIN
130
LINE HEATING WATER RETURN
131
LINE HEATING RETURN
132
SEAL CONE LINE CONNECTION,K 273860
133
GLAND LINE CONNECTION
134
UNION NUT LINE CONNECTION
135
UNION NUT FEED LINE
137
BRACKET HEATING WATER RETURN FLOW
140
CLAMP LINE MOUNTING
141
SCREW PUMP TO BRACKET
142
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
143
NUT SPRING-LOADED PUSH ROD
146
BRACKET
147
GROMMET CLOCK
150
GASKET COVER TO THERMOSTAT HOUSING,078816
150
GASKET COVER TO THERMOSTAT HOUSING, NOT USED
152
COVER THERMOSTAT
155
SPRING WASHER LICENSE PLATE TO BRACKET
156
SCREW BATTERY CABLE TO BRACKET M6X45
172
GASKET , Replaced By: A3522032680
172
GASKET DE-AERATION LINE TO HEATING LINE
210
THERMOSTAT ELEMENT
210
THERMOSTAT ELEMENT , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 430461YEAR OF MANUFACTURE 1996, Replaced By: A0052032675
210
THERMOSTAT ELEMENT , Replaced By: A0042038375
210
THERMOSTAT ELEMENT
225
SCREW PLUG ,006116
225
SCREW PLUG ,006116
230
LINE UPPER COOLING WATER LINE TO CYLINDER HEAD
232
SEAL RING CLUTCH BOOSTER
234
SCREW PLUG , Replaced By: N007604014110
234
SCREW PLUG FUEL TANK
236
SEAL RING ON OIL PUMP HOUSING
238
CONNECTOR AT ENGINE,591819
240
SCREW PLUG WATER DRAIN
240
SCREW PLUG
242
GASKET , Replaced By: A3522032680
242
GASKET DE-AERATION LINE TO HEATING LINE
245
FLANGE , 352 849318 353 849318 360 109917, Replaced By: A3522034239, +002N000125008418, +002N000931008322
245
FLANGE HEATING FEED, 352 849319 353 849319 360 109918
246
PIPE ELBOW
246
PIPE ELBOW ,352 849318, Replaced By: A3522003518, +002N000125008418, +002N000931008322
247
BRACKET TEMPERATURE GAUGE
248
SCREW PLUG WATER DRAIN
248
SCREW PLUG
249
SCREW PLUG , Replaced By: N007604014110
249
SCREW PLUG FUEL TANK
250
SEAL RING CLUTCH BOOSTER
265
SCREW BRACKET TO CROSS MEMBER
265
HEXAGON HEAD BOLT. SCREW , Replaced By: N910143008016
265
HEXALOBULAR BOLT BRACKET TO SUPPORT M8X80
265
SCREW FILTER BOWL TO FILTER HEAD M 8X90,841477 ONLY FOR USE WITH BOSCH DOUBLE FILTER
265
SCREW VALVE BODY ASSEMBLY TO TRANSMISSION M 8X55
267
WASHER EXHAUST MUFFLER TO STRAP
267
WASHER , Replaced By: N000125008443
270
SEAL RING FUEL LINE TO FEED PUMP
277
GASKET PIPE SOCKET TO CYLINDER HEAD, UP TO IDENT NO.5 448662, FROM IDENT NO. 5 448663 SEE UNIT MICROFICHE
279
SCREW DIFFERENTIAL CASE
279
SCREW EXHAUST PIPE TO MUFFLER AND TO HEATER UNIT M 8X55
279
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
279
HEXALOBULAR BOLT. SCREW SUPPORT TO CYLINDER HEAD
281
WASHER , Replaced By: N000125008443
281
WASHER EXHAUST MUFFLER TO STRAP
289
BRACKET , 027477
295
SEAL RING CLUTCH BOOSTER
296
SCREW PLUG , Replaced By: N007604014110
296
SCREW PLUG FUEL TANK
297
SEAL RING FUEL LINE TO FEED PUMP
999
THERMOSTAT ELEMENT ,078816, Replaced By: A0032032875, +001A3522032280
999
THERMOSTAT ELEMENT , 314.9 259272 352.9 437435, Replaced By: A0032033175, +001A3522032280
999
THERMOSTAT ELEMENT , NOT USED, Replaced By: A0032032975
999
THERMOSTAT ELEMENT , NOT USED, Replaced By: A0032033275
999
GASKET FOR REPAIR PURPOSES ONLY 0.5 MM
999
LINE ,000141000186, Replaced By: A3522000354, +001N003901015002
999
LINE , 004711 024899, Replaced By: A3522032901, +002N000931008061, +002N000931008210
999
WATER PUMP , Replaced By: A3522009301
999
COVER , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 740566, Replaced By: A3522011803
999
HOUSING , 004711-021981, Replaced By: A3522031173, +001N007603018101, +001N007604018101
999
LINE ,000155, Replaced By: A3522032901, +002N000931008061, +002N000931008210
999
HOUSING , Replaced By: A3522031173, +001A3522000354
999
LINE , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 369347, Replaced By: A3522033301
999
REPAIR KIT , Replaced By: A3522000560
999
REPAIR KIT , Replaced By: A3522001304
