Поз.
Артикул
Описание
1
CAMSHAFT WITH INJECTION TIMING DEVICE
1
CAMSHAFT , UP TO ENGINE 470359 YEAR OF MANUFACTURE 1977 IN THE CASE OF CAMSHAFT-DRIVEN AIR COMPRESSOR,ALSO ORDER: 352 130 04 16 CONNECTING ROD,352 131 25 33 PARTS KITBEARING SHELLS
3
THRUST WASHER ,104742, 340.919/002-007/010-014 INAPPLICABLE TO ENGINES WITH CAMSHAFT DRIVEN INJECTION TIMING DEVICE
3
THRUST WASHER CAMSHAFT FIXING, 340.930 FROM ENGINE 085456 ONLY APPLICABLE TO ENGINES WITH CAMSHAFT DRIVEN INJECTION TIMING DEVICE
6
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
10
SCREW COVER PLATE TO COVER PLATE
10
SCREW THRUST WASHER TO CRANKCASE, UP TO ENGINE 283201 YEAR OF MANUFACTURE 1978
15
DRIVE GEAR
19
SPACER RING ,104742, 340.919/002-007/010-014 INAPPLICABLE TO ENGINES WITH CAMSHAFT DRIVEN INJECTION TIMING DEVICE
21
WOODRUFF KEY CRANKSHAFT
24
CAMSHAFT GEAR
26
LOCK , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: N000933008177
28
SCREW BRACKET TO EXHAUST PIPE BRACKET
28
SCREW , Replaced By: N304017008024
30
VALVE TAPPET REPAIR SIZE III 28.73 MM - 28.74 MM
30
VALVE TAPPET REPAIR SIZE I 28.18 MM-28.19 MM
30
VALVE TAPPET STANDARD 27.98 MM-27.99 MM
32
PUSH ROD
35
ROCKER ARM WITH BUSHING,LEFT
40
ROCKER ARM WITH BUSHING,RIGHT
45
BUSHINGTO 366 050 05 33,04 34
48
BALL PIN ROCKER ARM
50
NUT
53
SPRING LONG,ROCKER ARM SPACING
55
ROCKER ARM SPINDLE
57
EXPANSION PLUG LATERAL P.T.O. WITH REVERSE SPEED
59
OIL PIPE
61
SPRING
61
SPRINGTO 312 055 05 33
63
SPACER TUBE
65
ROCKER ARM BRACKET OIL SUPPLY NO.1
67
ROCKER ARM BRACKETNO.2,5,6
69
ROCKER ARM BRACKETNO.3,4
69
ROCKER ARM BRACKET , Replaced By: A3520550210, +001N000417006001
71
SHIM , ONLY FOR REPAIR PURPOSES ON REGROUND CYLINDER HEAD
73
SCREW
73
SCREW ROCKER SHAFT TO CYLINDER HEAD
75
SCREW ROCKER SHAFT TO CYLINDER HEAD
75
SCREW , Replaced By: A0029903804
77
HEXAGON HEAD BOLT. SCREW VALVE TO BRACKET
77
HEADLESS SETSCREW PLANET GEAR, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
79
SPRING
81
SPRING
83
INTAKE VALVE
83
INTAKE VALVE , Replaced By: A3520500126
85
EXHAUST VALVE , Replaced By: A3660500627
85
EXHAUST VALVE ,042963
85
EXHAUST VALVE
87
WASHER VALVE SPRING
87
WASHER
90
VALVE SPRING
90
VALVE SPRING
92
SPRING RETAINER
94
VALVE COLLET (VALVE CONE HALF)
94
VALVE COLLET
94
VALVE COLLET
999
LOCK
999
CAMSHAFT , Replaced By: A3520502101
999
CAMSHAFT ,082678
999
THRUST WASHER , Replaced By: A3120520262
999
THRUST WASHER , FROM ENGINE 026136-026468,SEE SERVICE INFORMATION 07/6 VOM 12.07.1968, Replaced By: A3120520262
999
VALVE TAPPET REPAIR SIZE II 28.48 MM-28.49 MM
