Поз.
Артикул
Описание
180
TRANSMISSION CASE REAR
190
THREADED PIN TRANSMISSION CASE
195
SCREW TRANSMISSION CASE M 12X1.5X50
200
SCREW TRANSMISSION CASE TO TRANSMISSION CASE M 12X48
200
STUD TRANSMISSION CASE
215
NUT BATTERY CABLE
235
SCREW PLUG CASE,LEFT
240
TRANSMISSION CASE COVER OUTPUT SHAFT,REAR,218760
240
TRANSMISSION CASE COVER , Replaced By: A3892611920, +001A9029970032, +001N007603018100
255
SEAL RING INSIDE
255
SEAL RING INSIDE
255
SEAL RING INSIDE
260
SEAL RING OUTSIDE
260
SEAL RING OUTSIDE
260
SEAL RING OUTSIDE
270
SPACER RING TRANSMISSION CASE REAR COVER TO TRANSMISSSION CASE
280
SCREW TRANSMISSION CASE REAR COVER TO TRANSMISSSION CASE
280
SCREW , Replaced By: A9459901001
285
GASKET P.T.O. TO TRANSMISSION
410
PULSE STAR (PULSE PLATE),P.T.O.SHAFT SPEED
410
BUSHING , Replaced By: A9452620628
415
FLANGE (OUTPUT FLANGE) 200 MM
415
FLANGE (OUTPUT FLANGE)
420
SEAL RING INTERMEDIATE FLANGE TO P.T.O.
425
SEAL RING30X25 MM
430
HEXAGON HEAD BOLT FLANGE TO PLANETARY CARRIER M 20X95
430
SCREW FLANGE TO PLANETARY CARRIER M 24X2X95
430
SCREW FLANGE TO PLANETARY CARRIER M20X95, Replaced By: A9459900600
435
THRUST WASHER FLANGE TO PLANETARY CARRIER
440
OIL PUMP SHAFT , Replaced By: A9472691110
440
OIL PUMP SHAFT
455
SEAL RING
460
SEAL RING SUCTION LINE
465
BUSHING OIL STRAINER
635
DRIVE GEAR RETARDER
635
GEAR RETARDER
640
SEAL RING RETARDER
999
LINE
999
PIPE LINE
999
PIPE LINE RETARDER COOLING WATER FEED
999
LINE SUCTION LINE
999
LINE DELIVERY LINE
