Поз.
Артикул
Описание
17
RUBBER MOUNTING ENGINE REAR SUSPENSION
17
23
HEXAGON HEAD BOLT ENGINE MOUNTING TO CONSOLE M18X1.5X55
32
SUPPORTING ARM ENGINE RIGHT REAR MOUNTING
32
SUPPORTING ARM ENGINE LEFT REAR MOUNTING
38
SUPPORTING ARM ENGINE LEFT REAR MOUNTING
38
SUPPORTING ARM ENGINE RIGHT REAR MOUNTING
47
HEXAGON HEAD BOLT SUPPORTING ARM TO TRANSMISSION CASE
50
50
HEXAGON HEAD BOLT SUPPORTING ARM TO TRANSMISSION CASE M22X140
50
SCREW. HEXAGON HEAD BOLT SUPPORTING ARM TO TRANSMISSION CASE M22X80
62
RUBBER MOUNTING ENGINE REAR SUSPENSION
62
62
62
68
HEXAGON HEAD BOLT ENGINE MOUNTING TO CONSOLE M18X1.5X55
71
HEXAGON HEAD BOLT SUPPORTING ARM TO BELL HOUSING M18X1.5X60
80
HEXAGON HEAD BOLT. SCREW MOUNTING PARTS M 14X1.5X35
80
HEXAGON HEAD BOLT. SCREW GUSSET PLATE TO FRAME M14 X 1.5 X 70
80
HEXAGON HEAD BOLT. SCREW SUPPORT TO FRAME M14 X 1.5 X 55
80
HEXAGON HEAD BOLT. SCREW SPACER TUBE BETWEEN STABILIZER SHACKLES M14X1,5X80,D 228766
80
HEXAGON HEAD BOLT BRACKET TO FRAME M14X1.5X30
80
SCREW. HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X40
82
HEXAGON HEAD BOLT. SCREW SUPPORT TO FRAME M14 X 1.5 X 65
95
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
