Поз.
Артикул
Описание
5
RADIATOR GRILLE SHELL
8
REPAIR KIT , Replaced By: A1078800297
8
REPAIR KIT RADIATOR GRILLE SHELL
11
MERCEDES STAR , UP TO CHASSIS 022 000288 023 010180 024 009240 042 000282 043 011797 044 024229, Replaced By: A1078800386, +002N006797005110, +002N007981004226
11
MERCEDES STAR , FROM CHASSIS 022 000289 023 010181 024 009241 042 000283 043 011798 044 024230
14
COMBINATION BOLT BRACKET TO STEERING COLUMN END
17
RUBBER RING , Replaced By: A0009871541
20
TOOTHED WASHER BLINKER LAMP TO BODY
23
SHEET METAL SCREW BRACKET TO FLOOR PLATE
23
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
23
SHEET METAL SCREW BRACKET TO CAB 4,2X13
26
TOOTHED WASHER BLINKER LAMP TO BODY
29
RUBBER BUFFER REAR BACKREST TO REAR BODY PANEL, FROM CHASSIS 107.042 005125 107.043 014036 107.044 051723
32
SHEET METAL SCREW GEAR INDICATOR TO INSTRUMENT PANEL
32
TAPPING SCREW SIDE REFLECTORS,K 057592
35
WASHER
38
INSERT1012 MM
38
PLASTIC PAD , Replaced By: A1078880197
41
GRILLE RIGHT, FROM CHASSIS 023 000008 043 004851
41
GRILLE LEFT, FROM CHASSIS 023 000008 043 004851
47
SHEET METAL SCREW BRACKET TO FLOOR PLATE
47
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
50
WASHER AS REQUIRED 1.0 MM, ON BUSES UP TO CHASSIS 053510,ON TRUCKS UP TO CHASSIS 209647,FROM CHASSIS SEE 766.3
53
GARNISH MOULDING RIGHT
53
GARNISH MOULDING LEFT
56
SHEET METAL SCREW HOSE TO FIRE WALL
59
WASHER , Replaced By: N000125004319
59
WASHER BRACKET TO SUPPORT
65
SCREW CONTROL UNIT TO CAB
65
COMBINATION BOLT BRACKET TO STEERING COLUMN END
65
SCREW ELECTRIC CABLE TO PIPE BEND
65
SCREW RELAY TO BRACKET M 5X12
71
SPRING WASHER ALTERNATOR CONNECTION D+
74
GRILLE RIGHT, 024 004127 EXCEPT FOR: 001229,003388,003754,003939,003942,003945,003949,003962,003969,003970,003973,003995,004001,004014, 004017. 044 015081 EXCEPT FOR: 010423,014375,014449,014610,014817,014845,014853,014858,014890,014917,014919,014923,014929,014933, 014959,015075.
74
GRILLE RIGHT, 024 004128 ALSO INSTALLED ON 001229,003388,003754,003939,003942,003945,003949,003962,003969,003970,003973,003995,004001,004014, 004017. 044 015082 ALSO INSTALLED ON 010423,014375,014449,014610,014817,014845,014853,014858,014890,014917,014919,014923,014929,014933, 014959,015075.
74
GRILLE LEFT, 024 004127 EXCEPT FOR: 001229,003388,003754,003939,003942,003945,003949,003962,003969,003970,003973,003995,004001,004014, 004017. 044 015081 EXCEPT FOR: 010423,014375,014449,014610,014817,014845,014853,014858,014890,014917,014919,014923,014929,014933, 014959,015075.
74
GRILLE LEFT, 024 004128 ALSO INSTALLED ON 001229,003388,003754,003939,003942,003945,003949,003962,003969,003970,003973,003995,004001,004014, 004017. 044 015082 ALSO INSTALLED ON 010423,014375,014449,014610,014817,014845,014853,014858,014890,014917,014919,014923,014929,014933, 014959,015075.
77
SHEET METAL SCREW SWITCH PANEL ON FRONT END
80
WASHER , Replaced By: N009021004206
80
WASHER CENTRAL DEFROSTER NOZZLE TO INSTRUMENT PANEL
83
BAFFLE PLATE
86
RUBBER BUFFER
89
SHEET METAL SCREW
92
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
92
WASHER , Replaced By: N009021005205
95
CLIP-TYPE NUT BRACKET TO RELAY PLATE, A 994528 F 110300
95
LOCK BRACKET TO CROSS MEMBER
999
TOOTHED WASHER
