Поз.
Артикул
Описание
5
TANK
8
SEAL VACUUM SUPPLY TANK
9
BRACKET
10
SPACER TUBE
11
SCREW APPARATUS PLATE M 6X45
11
SCREW , Replaced By: N304017006027
14
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
14
WASHER COMPRESSED AIR LINE TO BRACKET
17
NUT OIL TANK TO BRACKET
17
NUT , Replaced By: N913002006009
20
SCREW , Replaced By: N304017006018
20
SCREW COVER PLATE TO COVER PLATE M 6 X 12
23
SPRING WASHER LICENSE PLATE TO BRACKET
26
NUT BALL PIVOT TO LEVER
32
ELEMENT RIGHT FRONT DOOR
41
SPRING
44
SHEET METAL SCREW OIL LINE MOUNTING
48
WASHER , Replaced By: N000433005304
48
WASHER BOOT TO CAB FLOOR
50
LOCK
53
SWITCH (ON THE LEFT IN CASE OF L.H.D.,ON THE RIGHT IN CASE OF R.H.D.), IN CASE OF R.H.D.,TURN SHIFTING ROD BY 180 DEGS. 107.022,042 FROM PRODUCTION START,107.023 FROM CHASSIS 009633,107.024 FROM CHASSIS 007327 CONTINUED,SEE FOOTNOTE 059,060,061
53
SWITCH , Replaced By: A1168000473
56
CLAMP
59
BRACKET FRONT DOOR VACUUM SWITCH
62
ADHESIVE TAPE *** 4X9X45 MM, ORDER BY THE METER
65
SHEET METAL SCREW MODULE TO HOUSING
65
SHEET METAL SCREW REFLECTOR TO BUMPER
68
TOOTHED WASHER OVERLOAD PROTECTOR TO TERMINAL BOARD
71
WASHER
74
ELEMENT
83
SHEET METAL SCREW , Replaced By: N007981004233
86
LOCK PLATE
89
SPRING , 114.010 FROM CHASSIS 025756,114.015,017 FROM CHASSIS 026340,114.021 FROM CHASSIS 000169,114.022 FROM CHASSIS 000026 115.010 FROM CHASSIS 027738,115.015 FROM CHASSIS 025224,115.110,112 FROM CHASSIS 060732,115.115 FROM CHASSIS 027945
92
ELEMENT
110
BRACKET VACUUM ELEMENT AT FILLER NECK FLAP
113
SHEET METAL SCREW , Replaced By: N007981004233
119
SCREW , Replaced By: A1239900036
119
SCREW
122
WASHER BRACKET TO SUPPORT
122
WASHER , Replaced By: N000125004319
125
SPRING
128
BUSHING , 000 194867 003 101568 007 085543 102,103 232424 105 226121 200 021073
131
HOSE ORDER BY THE METER
143
GROMMET
146
GROMMET FOR PASSAGE OF LINE, UP TO IDENT NO. 5 033766,ALSO INSTALLED ON 5 039977
149
CLAMP FIRE WALL,CENTER
152
CLAMP
155
SHEET METAL SCREW BRACKET TO CAB FLOOR
158
LOOM TIE , UP TO CHASSIS: 108.012 UNTIL PRODUCTION STOP 108.016 042417 108.018,019 043374 109.016 002452
161
CLIP
170
HOSE *** 30 MM
173
BRANCH-OFF FITTING
176
VALVE , Replaced By: A1168000378
176
VALVE , FROM CHASSIS: 010 060996 110 152519
