Поз.
Артикул
Описание
5
ENGINE HOOD ALUMINUM
8
ENGINE HOOD CATCH
20
HEXAGON HEAD BOLT
20
SCREW , Replaced By: N910105006002
23
LEVER , Replaced By: A1078870174
23
LEVER RIGHT
26
SCREW PUMP TO BRACKET
26
SCREW , Replaced By: N304017006016
35
NUT , Replaced By: N913012006001
35
NUT , Replaced By: N913019006000
35
NUT CLAMP TO BRACKET
38
BUSHING HINGE LEVER TO COWL
41
SCREW PIPE CLAMP
41
SCREW , Replaced By: N304017008021
47
WASHER , Replaced By: N000125008443
47
WASHER EXHAUST MUFFLER TO STRAP
50
BUFFER LEFT, FROM CHASSIS: 010 077937
50
BUFFER , Replaced By: A2019880511
53
NUT BALL PIVOT TO LEVER
56
ENGINE HOOD CATCH
59
SCREW CENTRAL PILLAR,BOTTOM
62
SEAL
68
ENGINE HOOD RELEASE CABLE , FROM CHASSIS 023 000009 043 004434
71
CLAMP WIRE CABLE TO CAB, FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB
71
CLAMP , Replaced By: A1279950020
71
CLAMP , Replaced By: N072571001035
74
SHEET METAL SCREW PRE-GLOW TIME RELAY TO STEERING COLUMN JACKET TUBE CONSOLE
74
SHEET METAL SCREW ALARM UNIT TO STRUT
77
SHEET METAL SCREW FRONT FENDER TO BRACKET AT FRONT LATERAL STIFFENING
77
SHEET METAL SCREW , Replaced By: N007982004259
77
SHEET METAL SCREW ENGINE HOOD RELEASE CABLE HANDLE TO LEFT FRONT PANEL PILLAR
80
SAFETY HOOK
83
SCREW LINE TO BRACKET,B 891198
86
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
89
HANDLE
92
PIN ENGINE HOOD RELEASE CABLE TO ENGINE HOOD CATCH LOWER PART
95
SUPPORT RIGHT
95
SUPPORT LEFT
98
SCREW HINGE LEVER TO SUPPORT UPPER PART, ONLY FOR REPAIR PURPOSES,IN PLACE OF SERIES EQPUIPMENT CLINCH-BOLT
101
WASHER HINGE LEVER TO SUPPORT UPPER PART
104
WASHER , Replaced By: N000125010532
104
WASHER RADIATOR TO RUBBER MOUNTING
110
LOCK STAY TO WHEELHOUSE
113
SPRING , 022 008366 ALSO INSTALLED ON 008313,008315-008330,008332-008339,008341-008364. 024 030199 ALSO INSTALLED ON 030181-030185,030187-030189,030193,030194,030196. 042 007870 ALSO INSTALLED ON 007854,007856,007858,007861-007866,007868. 044 062340 ALSO INSTALLED ON 006308-062310,062312-062314,062316-062338.
116
RUBBER RING EXPANSION-VALVE-TO-COMPRESSOR REFRIGERANT LINE
119
RUBBER BUFFER
122
WASHER BRACKET TO SUPPORT
122
WASHER , Replaced By: N000125004319
125
SHEET METAL SCREW HOSE TO FIRE WALL
128
MERCEDES BADGE , Replaced By: A6888807088
131
GROMMET CONTROL UNIT TO BRACKET
