Поз.
Артикул
Описание
9
REAR FENDER LEFT
15
REINFORCEMENT LEFT
22
SIDE MEMBER LEFT
29
END PIECE LEFT
36
PILLAR , 016 UP TO CHASSIS 049099, 018 UP TO CHASSIS 052477, 019 UP TO CHASSIS 052616, Replaced By: A1086300910
42
PILLAR CENTRAL LEFT
49
HINGE TOP LEFT, 012 FROM CHASSIS 000081,014 FROM CHASSIS 000024
55
BUSHING
62
HINGE PIN , Replaced By: A1157330015
62
PIN
69
GREASE NIPPLE
76
HINGE BOTTOM, 012 FROM CHASSIS 000081, 014 FROM CHASSIS 000024, 015 FROM CHASSIS 000015
101
PILLAR OUTSIDE LEFT
107
WHEELHOUSE REAR LEFT
115
WHEELHOUSE REAR OUTSIDE LEFT
121
ROOF RAIL INSIDE LEFT
128
STRUT
135
RECESS , Replaced By: A1086300042
142
CLAMP ON LEFT SPARE WHEEL WELL PLATE
148
STRUT
999
PILLAR , Replaced By: A1086300611
999
PILLAR , Replaced By: A1086300511
999
HINGE TOP RIGHT, 012 FROM CHASSIS 000081, 014 FROM CHASSIS 000024, 015 FROM CHASSIS 000015
999
HINGE PIN , Replaced By: A1157330015
999
WHEELHOUSE REAR OUTSIDE RIGHT
999
ROOF RAIL OUTSIDE RIGHT
999
ROOF RAIL INSIDE RIGHT
999
ROOF RAIL RIGHT
999
RECESS SPARE WHEEL WELL,RIGHT
999
END PIECE RIGHT
999
SIDE MEMBER RIGHT
999
REAR FENDER RIGHT
999
ROOF RAIL OUTSIDE LEFT
999
ROOF RAIL , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1096300735
999
ROOF RAIL LEFT
999
PILLAR RIGHT
999
PILLAR LEFT
999
PILLAR RIGHT
999
PILLAR , 016 UP TO CHASSIS 049099,018 UP TO CHASSIS 052477,019 UP TO CHASSIS 052616, Replaced By: A1086301010
999
WHEELHOUSE REAR RIGHT
999
ROOF RAIL INSIDE RIGHT
999
REINFORCEMENT RIGHT
999
PILLAR OUTSIDE RIGHT
999
BOTTOM SPARE WHEEL WELL,LEFT
