Поз.
Артикул
Описание
3
YOKE
6
PIN DOUBLE LEVER TO PUSH ROD
9
WASHER VIBRATION ABSORBER TO BRACKET
9
WASHER , Replaced By: N000433010510
12
FITTING CONNECTION TO STOP LIGHT SWITCH, Replaced By: A3899970272
12
FITTING CONNECTION TO STOP LIGHT SWITCH
15
BRACKET DOUBLE LEVER TO PUSH ROD
18
SCREW CLAMP TO BRACKET AND TO PIPE
21
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
24
NUT
27
VALVE ADDITIONAL GEAR CLUSTER ACTUATION BOSCH
27
VALVE GEAR CLUSTER SHIFT
30
HANDLETO 000 434 23 01
33
REPAIR KIT 3/2-WAY VALVE WABCO
36
NUT SUCTION LINE TO OIL PUMP
39
HOLLOW SCREW LINE CONNECTION
42
SEAL RING LINE CONNECTION
45
FITTING CONNECTION TO STOP LIGHT SWITCH
45
FITTING CONNECTION TO STOP LIGHT SWITCH, Replaced By: A3899970272
48
SEAL RING LINE CONNECTION
51
LEVER
54
ROLLER LEVER
57
BUSHING OPERATING VALVE
60
RIVET LEVER
63
SCREW CLUTCH PEDAL
66
NUT
69
PIN STRAP TO CONSOLE 20 L
72
WASHER VIBRATION ABSORBER TO BRACKET
72
WASHER , Replaced By: N000433010510
999
LINE , Replaced By: A0004296201
999
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
999
CUP 3/2-WAY VALVE WABCO
999
PLASTIC PIPE RISING PIPE 4X6 MM
999
SEAL CONE
999
LOOM TIE LINE MOUNTING 280 MM
999
LOOM TIE LINE MOUNTING
999
TS DOUBLE FITTING SOLENOID VALVE
999
FITTING , Replaced By: A0029906071
999
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
999
YOKE BRAKE BOOSTER, NOT USED
999
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
999
CLAMP LINE MOUNTING
999
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
999
BREATHER , Replaced By: A3933280065
999
COTTER PIN STRAP TO CONSOLE
999
GLAND , Replaced By: A0019901667
999
UNION NUT
999
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
999
SLEEVE LEAK LINE
