Поз.
Артикул
Описание
4
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
6
UNION NUT LINE CONNECTION
10
GLAND LINE CONNECTION
14
LINE , Replaced By: A0005516256
14
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
18
UNION NUT BUTT SCREW CONNECTION
20
GLAND LINE CONNECTION
21
VALVE , FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
22
SEALBOSCH 024, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
23
VALVE DISC024, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
24
VALVE DISC101
25
CUP , INCLUDED IN RANGE OF DELIVERY OF 000 431 68 06
26
CUP , Replaced By: A0014312386
26
CUP101
27
CUPTO BOSCH-NR.0481 027 104
28
GASKETTO 000 429 16 30
29
PROTECTIVE CAP101
30
VALVE104
31
SPRING , Replaced By: A0009935205
32
GASKET , Replaced By: A0179974148
32
SEAL RING101
33
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
34
SEAL RING LINE CONNECTION
38
O-RING CHECK VALVE TO AIR RESERVOIR
38
O-RING CHECK VALVE TO AIR RESERVOIR
42
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
42
THRUST RING CHECK VALVE TO AIR RESERVOIR
42
THRUST RING CHECK VALVE TO AIR RESERVOIR
46
NUT CHECK VALVE TO AIR RESERVOIR
50
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
50
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
55
BRAKE HOSE COMPRESSED AIR LINE, ORDER BY THE METER5 062721
60
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
60
CLAMP , Replaced By: N000000000665
65
T-FITTING FITTING,5 461950
70
BRACKET BETWEEN THE LINES
75
SCREW PIPE CLAMP
75
SCREW , Replaced By: N304017008021
80
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
80
NUT , Replaced By: N913004008001
85
SWITCH SUPPLY PRESSURE,5 966147
90
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
90
HOSE , Replaced By: A0009872827
95
FITTING (PARTS KIT),LINE RUPTURE
95
FITTING , Replaced By: A0029906171
100
UNION NUT LINE CONNECTION, Replaced By: N000000006239
100
UNION NUT LINE CONNECTION
105
GLAND , Replaced By: A0019901967
105
SEAL CONE LINE CONNECTION
110
BUSHING , Replaced By: N915062009000
110
SLEEVE LINE CONNECTION
115
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
120
FITTING , Replaced By: A0029905971
120
FITTING (PARTS KIT),LINE RUPTURE
125
UNION NUT LINE CONNECTION
130
GLAND LINE CONNECTION
135
SLEEVE , Replaced By: N915062006000
135
SLEEVE LINE CONNECTION
140
LOOM TIE LINE MOUNTING 280 MM
140
LOOM TIE LINE MOUNTING
140
LOOM TIE LINE MOUNTING 280 MM
145
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
150
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
155
LOOM TIE LINE MOUNTING
160
BRACKET COMPRESSED AIR LINES
165
SCREW END PIECE TO EXHAUST PIPE M 10X25
170
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
175
NUT , Replaced By: N910113010000
175
NUT STRAP TO BRACKET
180
WASHER , Replaced By: N000125010532
180
WASHER RADIATOR TO RUBBER MOUNTING
185
SCREW COVER PLATE TO BRACKET
190
NUT , Replaced By: N913004006001
190
NUT PUMP TO BRACKET
999
SLIDETO 000 431 50 14,000 431 24 14
999
FILTER BOTTOMTO 000 431 24 14
999
VALVE , Replaced By: A0004320807
999
DRUCKFEDER. SPRING , Replaced By: A3145860142
999
BEARING BRACKET
999
PIN
999
DAMPING RING
999
PAWL , Replaced By: A3145860142
999
HANDLE
999
BUSHING
999
PLATE , Replaced By: A3145860142
999
WASHER BRAKE LEVER TO BEARING BRACKET, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
END PIECE
999
BEARING BRACKET
999
ROD , UP TO CHASSIS 741766
999
ROD
999
BEARING BRACKET
999
BRACKET INTERMEDIATE LEVER
999
STRAP AIR RESERVOIR TO CONSOLE
999
CONSOLE AIR RESERVOIR TO SUPPORT
999
SPRING LEVER
999
BEARING BRACKET INTERMEDIATE LEVER TO BEARING BRACKET
999
PIN , 674068
999
CABLE PULLEY
999
BRAKE INTERMEDIATE SHAFT , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
BRAKE INTERMEDIATE SHAFT REAR
999
BRACKET INTERMEDIATE LEVER
999
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
999
PIN PULL ROD TO BRAKE LEVER,REAR AXLE
999
PIN ROD TO INTERMEDIATE LEVER
999
BUSHING LEVER
999
LEVER FRONT
999
BRACKET , FROM IDENT NO. 685038 ALSO INSTALLED ON:500001-599999
999
PROTECTIVE CAP , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
BRAKE LEVER PAWL ROD, 674067
999
LEVER
999
LEVER FRONT
999
BRAKE CABLE
999
RATCHET ROD , Replaced By: A3604200188
999
BRAKE LEVER
999
BRAKE CABLE
999
BEARING BRACKET BRAKE CABLE, 674067
999
RATCHET ROD
999
BEARING BRACKET BRAKE CABLE, 674067
999
BEARING BRACKET , FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
WASHER HANDLE TO RATCHET ROD, 674067
999
BEARING BRACKET , 674068
999
BEARING BRACKET
999
BRAKE LEVER HAND BRAKE
999
BRAKE LEVER , FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
COVERING LINES,5 062721
999
ELECTRIC CABLE FROM FRONT PLUG CONNECTION TO SPRINGLOAD ACCUMULATOR BRAKE SWITCH
999
ELECTRIC CABLE FROM FRONT PLUG CONNECTION TO SPRINGLOAD ACCUMULATOR BRAKE SWITCH, FROM IDENT NO. 674068 ALSO INSTALLED ON 500001-599999,673432,673497,673628,673629
