Поз.
Артикул
Описание
1
INSTRUMENT PANEL
3
COVER REAR AXLE HOUSING
5
CROSS MEMBER
5
CROSS MEMBER
8
GROUND CABLE FROM ALTERNATOR TO FRAME SIDE MEMBER, UP TO IDENT NO. 727921 EXCEPT FOR,500001-599999,FROM IDENT NO. SEE ENGINE MICROFICHE
8
GROUND CABLE , Replaced By: A3521500032
14
PLUG
16
PIN BUSHING HOUSING BIPOLAR
18
PIN BUSHING HOUSING 6-POLE
18
PIN BUSHING HOUSING 8-POLE
22
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
22
PIN BUSHING , Replaced By: A0075458226
22
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
22
PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 4-6 MM2
22
PIN BUSHING WITH DETENT,LESS CATCH FOR HOUSING 6 MM2,5 097182
26
GROMMET3.0 MM
26
GROMMET HOSE LINE PROTECTION TO 000 546 16 30,71 30
28
GROMMET
32
PLUG HOUSING 6-POLE
32
PLUG HOUSING 8-POLE
35
GROMMET3.0 MM
36
CABLE CONNECTOR 6-POLE
40
CLAMP TO MOUNT PLASTIC PIPING
44
CABLE HARNESS PLUG SOCKET
46
CAP , Replaced By: A0005453503
46
CAP PLUG SOCKET
46
CAP PLUG SOCKET
47
SPACER RING TRAILER PLUG SOCKET
50
FUSE BOX
52
SWITCH BOX , Replaced By: A0005453813
52
SWITCH (TRACTION SWITCH)
54
SWITCH , Replaced By: A0005454204, +001A0005450481
54
SWITCH , Replaced By: A0005454104
54
SWITCH (LIGHT SWITCH)
55
SWITCH ABS AND ASR
57
BUTTON ABS AND ASR
57
BUTTON
58
NUT SWITCH TO APPARATUS PLATE
58
NUT ,928519
60
CABLE CONNECTOR BIPOLAR, ON LP1313(352)UP TO CHASSIS 601003 ALSO INSTALLED ON 601006,601009,601010,601017,601018,601024 WITH THE EXCEPTION OF 600917,60 0992,600993,600996-999,601001,601002 CONTINUED ON 009
63
MASKED HEADLAMPBOSCH
63
MASKED HEADLAMPHELLA
66
TAIL LAMP , 846814, Replaced By: A0015444503, +001A3435401238
66
TAIL LAMP LEFT
66
TAIL LAMP , 846814, Replaced By: A0015444603, +001A3435401338
68
TAIL LAMP RIGHT
70
MASKED STOP LAMP
73
MASKED LAMP
73
GUIDE CROSS LAMP , Replaced By: A0005405096
73
MASKED LAMP
73
GUIDE CROSS LAMP , Replaced By: A0005405096
77
BRACKET GUIDE CROSS LAMP
82
BRACKET MASKED HEADLAMP
86
HORN , Replaced By: A0025428320
87
BRACKET LEFT
90
REGULATOR AND CUT-OUT12 V,5 005483
90
REGULATOR AND CUT-OUT WITH HOSE-PROOF ENCLOSURE 24 V
90
REGULATOR AND CUT-OUT , Replaced By: A0001546906
95
SPACER TUBE REGULATOR MOUNTING
98
SENDER UNIT HAZARD WARNING LIGHT, UP TO IDENT NO. 655197 EXCEPT FOR 500001-599999
98
SENDER UNIT HAZARD WARNING LIGHT, UP TO IDENT NO. 655197 EXCEPT FOR 500001-599999
98
SENDER UNIT , 674501
102
RELAY , Replaced By: A0025422419
102
RELAY
102
RELAY
104
BRACKET
110
CAP HAND LAMP PLUG SOCKET
114
KEY , Replaced By: A0005451435
114
KEY SWITCH BOX
999
ELECTRIC CABLE FROM ALTERNATOR TO REGULATOR,5 005483
999
ANTI-GLARE RIM WITH CAP
999
GASKET
999
LENSTO 000 544 07 14
999
ANTI-GLARE RIM WITH CAP
999
KEY IGNITION AND LIGHT SWITCH
999
FUSE , Replaced By: N072581008101
999
COVERING WITH GASKET
999
LENS
999
SCREW
999
WASHER
999
WASHERTO 000 544 08 14
999
WASHERTO 000 544 07 14
999
SEAL RINGTO 000 544 08 14,5 300077
999
SEAL RINGTO 000 544 07 14,5 300077
999
GROMMETTO 000 544 08 14,5 300077
999
GROMMETTO 000 544 07 14,5 300077
999
HORN , Replaced By: A0035423220
999
FUSE25 A
999
SPACER TUBE REGULATOR MOUNTING
999
BRACKET
999
CABLE HARNESS FROM CABLE CONNECTOR TO LEFT TAIL LAMP,A 001697
999
CABLE HARNESS , Replaced By: A3145400007
999
BRACKET , Replaced By: A3525405773
999
BRACKET , Replaced By: A3525405873
999
CABLE HARNESS CAB MAIN CABLE HARNESS, UP TO IDENT NO. 655197 EXCEPT FOR 500001-599999
999
ELECTRIC CABLE , Replaced By: A3585401427
999
CABLE HARNESS
999
CABLE HARNESS
999
CABLE HARNESS RIGHT TAIL LAMP
999
BRACKET RIGHT
999
ELECTRIC CABLE , Replaced By: A3535406827
999
ELECTRIC CABLE
999
ELECTRIC CABLE , Replaced By: A3585401427
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
SCREW BRACKET TO COVERING
999
SCREW
999
SCREW
999
SCREWAM 6X45
999
WASHER , Replaced By: N000433005304
999
LOCK WASHER CONTACT PLATE TO STEERING WHEEL
999
WASHER
999
WASHER BOOT TO CAB FLOOR
999
SCREW
999
SCREW COVER PLATE TO BRACKET
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
NUT BALL PIVOT TO LEVER
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
SHEET METAL SCREW GEAR INDICATOR TO INSTRUMENT PANEL
999
SHEET METAL SCREW , Replaced By: N007981004233
999
SCREW
999
SCREW CLAMP MOUNTING
999
SCREW , Replaced By: N000000001145
999
SCREW FROM PLUG SOCKET TO BATTERY MASTER SWITCH CASE
999
FUSEA8
999
FUSE , Replaced By: A0015457534
999
BULB12 V 18 W, 846814
999
BULB2W
999
BULB MASKED HEADLAMP 24V-18W
999
BULB , Replaced By: N072601024192
999
BULB TAIL LAMP 21 W
999
BULB , Replaced By: N072601024704
999
BULB WITH REINFORCED COILED FILAMENT 24 V/10 W
999
BULB TELL-TALE LAMP
999
NUT , Replaced By: N304032005005
999
NUT IN CASE OF SUBSEQUENT INSTALLATION
999
LOCK WASHER BRACKET TO STEERING COLUMN END
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
