Поз.
Артикул
Описание
261
TRANSMISSION CASE COVER , 040899
264
TRANSMISSION CASE COVER TOP, 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 490816, 002,003,005,011,017 FROM TRANSMISSION 021531
265
BUSHING INTERLOCK PIN, 184087, 309.030-035,051-059 192298, 309.050 182066, 309.1
266
INTERLOCK PIN REVERSE SPEED, 184087, 309.030-035,051-059 192298, 309.050 182066, 309.1556499
268
SPRING
269
SEAL RING SOLENOID VALVE A 18X24
270
SCREW PLUG
271
INTERLOCK PLUG , Replaced By: A3442657044
272
DETENT PLATE
274
SHAFT
275
SHIFTING FINGER
276
SPACER WASHER
277
NEEDLE BEARING
278
EXPANSION PLUG
279
LOCK RING
280
SEAL RING
282
SHIFTING FINGER
283
SEAL RING
284
LEVER
285
BUSHING , 000421
288
GUIDE PLATE , 040899
289
WASHER DETENT PLATE TO COVER, UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
290
NUT , FROM TRANSMISSION
291
SHIFTING FORK 1ST AND 2ND SPEED
293
SHIFTING FORK 3RD AND 4TH SPEED
294
LEVER REVERSE SPEED
295
SPRING
296
BALL
297
SPACER TUBE
298
SPACER TUBE
299
WASHER 0.30 MM
301
SHIFTING ROD 1ST AND 2ND SPEED
302
SHIFTING ROD 3RD AND 4TH SPEED
303
SHIFTING ROD REVERSE SPEED
304
SPACER TUBE
305
KEY
306
BREATHER TRANSFER CASE
314
LEVER
315
BUSHING , 000421
316
GASKET
317
SCREW LEVER TO SHAFT
318
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
318
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
319
SPRING WASHER , Replaced By: N000137008212
319
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
320
SWITCH BACK-UP LIGHT, 040899
321
PLUG HOUSING
321
PLUG , Replaced By: A0095454028, +002A0015453826, +001A0095454128
322
SEAL RING SOLENOID VALVE A 18X24
323
BRACKET
324
CLIP LINE MOUNTING
324
CLIP TAIL LAMP CABLE HARNESS TO REAR LID
330
SHIFTING TUBE , 000,001,004,010,016 FROM CHASSIS 190318 ALSO INSTALLED ON, SEE FOOTN.36,002,003,005,011,017 FROM CHASSIS 034217 ALSO INSTAL- LED ON,SEE FOOTN.37 AND FOOTN.41
331
GUIDE PIVOT , 000,001,004,010,016 FROM CHASSIS 190318 ALSO INSTALLED ON, SEE FOOTN.36,002,003,005,011,017 FROM CHASSIS 034217 ALSO INSTAL- LED ON,SEE FOOTN.37 AND FOOTN.41
332
SEAL RING
333
WASHER
334
LOCK
335
PIN
336
SPRING
337
BOOT , 000,001,004,010,016 FROM CHASSIS 190318 ALSO INSTALLED ON,SEE FOOTN.36,002,003,005,011,017 FROM CHASSIS 034217 ALSO INSTALLED ON SEE FOOTN.37 AND FOOTN.47
339
SHIFT LEVER , 000,001,004,010,016 FROM CHASSIS 190318 ALSO INSTALLED ON, SEE FOOTN.36,002,003,005,011,017 FROM CHASSIS 034217 ALSO INSTAL- LED ON,SEE FOOTN.37 AND FOOTN.41
340
RUBBER PAD
341
COVER
342
KNOB DARK GRAPHITE GREY
343
BEARING BRACKET
344
NEEDLE BEARING
345
LEVER
346
BUSHING
347
SPACER RING
348
SPRING WASHER LICENSE PLATE TO BRACKET
349
NUT BALL PIVOT TO LEVER
352
COVER
353
LEVER
353
LEVER , Replaced By: A1112601381
355
NEEDLE BEARING
356
SEAL RING
357
WASHER
358
SPRING WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
359
LOCK PLATE INTERMEDIATE BEARING
360
LOCK WASHER TAIL LAMP TO BRACKET
361
NUT
363
LEVER
364
SHAFT
366
SCREW
367
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
368
SEAL RING
369
SPRING WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
370
LEVER
372
BALL SOCKET
373
NUT BATTERY CABLE MOUNTING,5 193595
373
NUT BATTERY CABLE TO CABLE CONNECTOR,5 193595
374
BALL SOCKET
375
SECURING CLIP. CIRCLIP
377
SHIFTING ROD
380
SHIFTING ROD
382
NUT
383
BALL SOCKET
384
WASHER , 016 UP TO CHASSIS 027622 EXCEPT FOR, SEE FOOTNOTE 45, 018 UP TO CHASSIS 028985 EXCEPT FOR, SEE FOOTNOTE 43, 019 UP TO CHASSIS 029325
999
SEALING CORD , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
SEAL RING , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
BALL BEARING
999
BALL BEARING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
999
KNOB DARK GRAPHITE GREY
999
BOOT , 000,001,004,010,016 FROM CHASSIS 190318 ALSO INSTALLED ON,SEE FOOTN.36,002,003,005,011,017 FROM CHASSIS 034217 ALSO INSTALLED ON SEE FOOTN.37 AND FOOTN.49
999
GEAR , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 365564 ALSO INSTALLED ON, SEE FOOTNOTE 6 CONTINUED, SEE FOOTNOTE 22
999
LEVER
999
LEVER
999
COUNTERSHAFT , 000,001,010,100,101,110 FROM TRANSMISSION 024407-365563 EXEPT FOR, SEE FOOTNOTE 6 AND 7
999
COUNTERSHAFT , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 414557, 002,003,005,011,017 FROM TRANSMISSION 011431
999
LEVER
999
TRANSMISSION CASE COVER , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 040899-490815, 002,003,005,011,017 UP TO TRANSMISSION 021530, Replaced By: A1112603114, +001A1112610066
999
SHIFTING TUBE , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.38
999
LEVER
999
TRANSMISSION CASE COVER
999
BEARING BRACKET , 040898
999
PIPE , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 490816, 002,003,005,011,017 FROM TRANSMISSION 021531
999
GASKET , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
BOOT , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.38
999
SHAFT
999
GUIDE PIVOT , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.38
999
COVER
999
REPAIR KIT TRANSMISSION CASE FRONT COVER
999
WASHER1.0 MM, 10/50,12/52 UP TO CHASSIS 096085, 20/60,22/62 UP TO CHASSIS 095140
999
WASHER0.5 MM, 10/50,12/52 UP TO CHASSIS 096085, 20/60,22/62 UP TO CHASSIS 095140
999
TRANSMISSION CASE COVER FRONT
999
TRANSMISSION WITH BELL HOUSING
999
TRANSMISSION WITH BELL HOUSING
999
SHIFTING ROD
999
SHIFTING ROD
999
GASKET
999
REPAIR KIT , Replaced By: A1115860126
999
BALL PIVOT TRANSMISSION CASE FRONT COVER TO TRANSMISSION CASE
999
GEAR 30 TEETH, 1ST SPEED, 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 365564-414556 ALSO INSTALLED ON, SEE FOOTNOTE 6 AND 9
999
SEAL RING , Replaced By: A0119976447
999
THRUST WASHER 4.50 MM
999
THRUST WASHER , NOT USED
999
THRUST WASHER , Replaced By: A1202622062
999
THRUST WASHER AS REQUIRED
999
SPACER WASHER 0.20 MM
999
SPACER WASHER 0.2 MM
999
SPACER WASHER 0.3 MM
999
SPACER WASHER 0.30 MM
999
SNAP RING , Replaced By: A1369940935
999
SNAP RING 2.05 MM
999
SHIFT LEVER , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.38
999
SEAL RING
999
THRUST WASHER 3.90 MM
999
THRUST WASHER 4.00 MM
999
THRUST WASHER 4.10 MM
999
THRUST WASHER AS REQUIRED 4.20 MM
999
THRUST WASHER AS REQUIRED 4.30 MM
999
THRUST WASHER 4.40 MM
999
THRUST WASHER 4.50 MM
999
SHIFTING FORK 1ST AND 2ND SPEED
999
SPACER WASHER AS REQUIRED 0.10 MM, UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
999
SPACER WASHER 0.25 MM
999
SPACER WASHER 0.50 MM
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
SPRING WASHER STEERING COLUMN BRACKET TO CAB
999
HEADLESS SETSCREW , Replaced By: A1109900110, +001N000137010101
999
SCREW TIGHTENER PULLEY TO BRACKET ON ENGINE
999
SCREW , Replaced By: N000933006194
999
SCREW SELECTOR LEVER TO SELECTOR FINGER
999
SCREW COVER PLATE TO BRACKET
999
NUT CYLINDER TO BRACKET TO0002902112
999
SNAP RING , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 365564 ALSO INSTALLED ON, SEE FOOTNOTE 6 CONTINUED, SEE FOOTNOTE 22
999
NUT BATTERY MOUNTING
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
