Поз.
Артикул
Описание
1
SHIFTING TUBE
3
BEARING COVER BOTTOM
4
RUBBER RING
5
WASHER
6
LOCK
10
BEARING
11
BUSHING
14
BEARING COVER TOP
15
COVER PLATE
16
BOOT
17
BOOT BOTTOM
20
SCREW COVER PLATE TO BRACKET
21
WASHER , Replaced By: N000125007408
21
WASHER COVER PLATE TO COVER PLATE
22
SPRING WASHER LICENSE PLATE TO BRACKET
23
SCREW YOKE TO SHIFTING TUBE
24
LOCK WASHER TAIL LAMP TO BRACKET
25
NUT
25
NUT , Replaced By: N304032008006
26
SHIFT LEVER
27
KNOB
28
SCREW
29
BUSHING
30
WASHER
31
NUT
35
PULL ROD
36
END PIECE
37
BUSHING
40
NUT
42
WASHER
43
NUT
45
STEER. COLUMN JACKET TUBE , 004,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTNOTE 010,104,116 UP TO CHASSIS 358853 EXCEPT FOR,SEE FOOTNOTE 011,AND FOOTNOTE017 ON SPECIAL REQUEST,FLOOR SHIFT
46
COVERING STEERING PASSAGE, ON SPECIAL REQUEST,DB POWER STEERING
47
COVER FLOOR SHIFT
48
SEAL
49
BOOT
50
STEERING SHAFT , 000,001,004,010,016 FROM CHASSIS 190318 ALSO INSTALLED ON,SEE FOOTN.10,10/50,12/52,100,101,104,110,116 FROM CHASSIS 358854 ALSO INSTALLED ON,SEE FOOTN.11,AND FOOTN.9
999
NEEDLE BEARING
999
NEEDLE BEARING
999
BALL SOCKET
999
SWITCH,AUTOMATIC
999
SWITCH,AUTOMATIC
999
SHIFTING ROD
999
PULL ROD
999
SHIFTING TUBE , 000,001,004,010,016 FROM CHASSIS 190318 ALSO INSTALLED ON, SEE FOOTN.36,002,003,005,011,017 FROM CHASSIS 034217 ALSO INSTAL- LED ON,SEE FOOTN.37 AND FOOTN.41
999
SHIFTING TUBE
999
KNOB DARK GRAPHITE GREY
999
KNOB DARK GRAPHITE GREY
999
KNOB , UP TO CHASSIS: 000,002,010 007280 015 004403 100,102,103,110,112 017470 115 007978
999
STEER. COLUMN JACKET TUBE , Replaced By: A1084605016
999
STEER. COLUMN JACKET TUBE , Replaced By: A1084605116
999
STEER. COLUMN JACKET TUBE
999
STEER. COLUMN JACKET TUBE
999
BALL SOCKET
999
LEVER
999
BALL SOCKET
999
BEARING BRACKET
999
LEVER
999
BEARING BRACKET
999
SHIFTING TUBE
999
SHIFTING TUBE
999
HOUSING
999
BRACKET
999
LEVER
999
LEVER
999
LEVER
999
PULL ROD
999
SHIFTING TUBE
999
SHIFTING ROD
999
STEER. COLUMN JACKET TUBE
999
STEER. COLUMN JACKET TUBE , 001,002,004,010,016 FROM CHASSIS 190318,ALSO INSTALLED ON,SEE FOOTNOTE 010,100,101,104,110,116 FROM CHASSIS 358854,ALSO INSTAL LED ON,SEE FOOTNOTE 011,AND FOOTNOTE 019 ON SPECIAL REQUEST,FLOOR SHIFT
999
STEER. COLUMN JACKET TUBE FLOOR SHIFT, 001,002,004,010,016 FROM CHASSIS 190318,ALSO INSTALLED ON,SEE FOOTNOTE 010,100,101,104,110,116 FROM CHASSIS 358854,ALSO INSTAL LED ON,SEE FOOTNOTE 011,AND FOOTNOTE 019 ON SPECIAL REQUEST,DB POWER STEERING
999
STEER. COLUMN JACKET TUBE , 001,002,004,010,016 FROM CHASSIS 190318 ALSO INSTALLED ON,SEE FOOTNOTE 010,100,101,104,110,116 FROM CHASSIS 362507 ALSO INSTAL LED ON,SEE FOOTNOTE 011,AND FOOTNOTE 019 ON SPECIAL REQUEST,FLOOR SHIFT
999
STEERING SHAFT , 001,002,004,010,016 FROM CHASSIS 190318,ALSO INSTALLED ON,SEE FOOTNOTE 010,100,101,104,110,116 FROM CHASSIS 358854,ALSO INSTAL LED ON,SEE FOOTNOTE 011,AND FOOTNOTE 019 ON SPECIAL REQUEST,DB POWER STEERING AND FLOOR SHIFT
999
BALL SOCKET
999
LEVER
999
BALL SOCKET
999
LEVER
999
LEVER , Replaced By: A1112601381
999
LEVER
999
BEARING BRACKET
999
SHIFTING ROD
999
BEARING BRACKET , 040898
999
SHIFTING ROD
999
SHIFTING ROD
999
RUBBER RING
999
BEARING
999
SPACER RING
999
RUBBER PAD
999
BOOT , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.38
999
SHAFT
999
GUIDE PIVOT , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.38
999
COVER
999
SHAFT
999
COVER
999
KNOB , 114.010 058796 114.011 003269 114.015 071505 114.021 005601 114.022 013880
999
BUSHING
999
STEER. COLUMN JACKET TUBE , 004,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTNOTE 010,104,116 UP TO CHASSIS 362506 EXCEPT FOR,SEE FOOTNOTE 011 AND FOOTNOTE017 ON SPECIAL REQUEST,FLOOR SHIFT
999
BALL
999
BUSHING
999
SEAL RING
999
SEAL RING
999
LEVER
999
LEVER
999
PULL ROD
999
PULL ROD
999
SHIFTING TUBE
999
SHIFTING TUBE
999
SHIFTING ROD
999
SHIFTING ROD
999
SHIFTING ROD
999
SHIFTING ROD
999
BUSHING
999
SPACER TUBE
999
LEVER
999
SHAFT
999
COVER
999
WASHER
999
LEVER
999
SHIFT LEVER , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.38
999
KNOB. BRACKET
999
SEAL RING
999
SPRING
999
LOCK
999
PIN
999
WASHER
999
WASHER
999
NUT
