Поз.
Артикул
Описание
34
SEAL RING
90
SPACER TUBE
122
DAMPING PAD EXHAUST PIPE SUSPENSION
134
DAMPING PAD EXHAUST PIPE SUSPENSION
141
RUBBER BUFFER IN FRONT OF,AND BEHIND,POSTERIOR MUFFLER
205
SCREW LINES UNDER FUEL TANK
211
RUBBER RING SIGNAL LAMP TO ROOF
217
WASHER , Replaced By: N009021006208
217
WASHER COMPRESSED AIR LINE TO BRACKET
222
SPRING WASHER LICENSE PLATE TO BRACKET
229
NUT BATTERY MOUNTING
229
NUT CYLINDER TO BRACKET TO0002902112
245
PROTECTIVE PLATE
253
PROTECTIVE PLATE
999
CLAMP
999
SCREW , Replaced By: N007976004217
999
NUT POWER CYLINDER TO BRACKET
999
CLAMP , 003 078976 086 003333 EXCEPT FOR 002924,002958,002959,002981,003004,003013,003017,003025,003114,003171,003282-003298,003300-003332.
999
CLAMP , Replaced By: A1074900041
999
PROTECTIVE PLATE AT LUGAGGE COMPARTMENT
999
REPAIR KIT EXHAUST PIPE SUSPENSION
999
EXHAUST PIPE RIGHT, FROM CHASSIS 000219 ALSO INSTALLED ON 000193,000195-000198,000200-000202,000205-000210,000212-000217,000168,000170,000172-0001 75,000177-000179,000182-000191
999
EXHAUST PIPE
999
EXHAUST PIPE FRONT RIGHT
999
MUFFLER , NOT USED
999
EXHAUST PIPE CENTRAL
999
END PIECE
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
SCREW , Replaced By: N304017008043
999
SCREW , Replaced By: N304017006018
999
NUT HEAT SHIELD MOUNTING
999
NUT
999
WASHER , Replaced By: N009021006208
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
999
SCREW VALVE TO BRACKET M 8X55
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
SEAL RING FRONT EXHAUST PIPE TO EXHAUST MANIFOLD
999
NUT , Replaced By: A0009903250
