Поз.
Артикул
Описание
18
RUBBER MOUNTING 20.0 MM
30
TORSION BAR
42
BRACKET
54
NUT SWITCH TO FLOOR PLATE
66
REPAIR KIT , 010 ON SPECIAL REQUEST, HARDER SPRINGS 001 SPECIAL BODIES 000 AMBULANCE
78
SHOCK ABSORBER
90
DUST CAP
102
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
102
NUT , Replaced By: N308673010000
114
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
126
NUT
126
NUT , Replaced By: N304032008006
138
REPAIR KIT
150
REAR SPRING DIA.,15.90 MM, ON SPECIAL REQUEST, HYDROPNEUMATIC COMPENSATING SPRING
162
HYD.PNEUM.SPRING LEG ASSY , ON SPECIAL REQUEST, HYDROPNEUMATIC COMPENSATING SPRING
174
BALL JOINT LEFT, ON SPECIAL REQUEST, HYDROPNEUMATIC COMPENSATING SPRING
186
BALL JOINT
198
BOOT , 000,001,004,010,016 FROM CHASSIS 134952, 100,101,104,110,116 FROM CHASSIS 233249, 002,003,005,011,017 FROM CHASSIS 001796
210
LOCK WASHER
222
CLAMP , Replaced By: A0069972690
222
LOOM TIE. CLAMP HOSE FASTENING
234
BEARING RING
246
WASHER
258
NUT PLATFORM MOUNTING
258
NUT
270
SCREW , 010,011,016,017,110,116 ON SPECIAL REQUEST, HYDROPNEUMATIC COMPENSARING SPRING, ON SPECIAL REQUEST, H.D. SPRINGS AND HYDROPNEU MATIC COMPENSATING SPRING
282
LOCK WASHER FITTING TO BRACKET
294
BUSHING
306
SPRING CASE
318
BUSHING
330
SCREW
342
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
354
NUT
354
NUT , Replaced By: N304032008006
366
RUBBER BUFFER , 000,001 UP TO CHASSIS 018992, 100,101 UP TO CHASSIS 026467
378
SCREW FUEL TANK TO FRAME
390
SPRING WASHER , Replaced By: N000137008212
402
SHOCK ABSORBER REAR
414
RUBBER MOUNTING
426
SCREW SENSOR CABLE TO PROTECTIVE PLATE
438
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
450
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
450
NUT , Replaced By: N308673010000
462
REPAIR KIT
999
RUBBER MOUNTING
999
FRONT SPRING
999
LOCK
999
BUSHING
999
BUSHING
999
RUBBER MOUNTING BOTTOM
999
RETAINER
999
WASHER
999
RUBBER MOUNTING 22.5 MM
999
RUBBER MOUNTING 25.0 MM
999
RUBBER MOUNTING 27.5 MM
999
RUBBER MOUNTING 30.0 MM
999
RUBBER MOUNTING 32.5 MM
999
RUBBER BUFFER
999
RETAINER
999
SCREW
999
SPACER TUBE
999
RUBBER MOUNTING
999
RETAINER , Replaced By: A1233230367
999
RETAINER FRONT SHOCK ABSORBERS TO FRAME
999
RUBBER BUFFER
999
NUT , Replaced By: N308673010000
