Поз.
Артикул
Описание
1
WINDOW REGULATOR RIGHT
4
WINDOW REGULATOR RIGHT
6
GEARING
10
GEARING
10
GEARING , Replaced By: A0008203107
13
SEAL
17
STOP RIGHT
20
STOP
23
HOUSING RIGHT
23
HOUSING , Replaced By: A0007681075, +001A0009900457, +001N914114006007
26
STOP RIGHT
30
SPRING ,033 053207
33
CONNECTOR
36
ELECTRIC MOTOR , Replaced By: A0008201142
36
PART NAME MISSING , Replaced By: A0008201142
36
ELECTRIC MOTOR
40
ELECTRIC MOTOR , Replaced By: A0018200442
40
ELECTRIC MOTOR RIGHT
42
WINDOW REGULATOR RAIL RIGHT
53
PANELLING RIGHT FRONT DOOR
150
FRAME (QUADRUPLE ROCKER SWITCH), FROM CHASSIS: 111.021,023 083954-088724 UP TO CHASSIS 111.021,023 088724
170
FRAME ROCKER SWITCH, FROM CHASSIS: 111.021,023 083954
178
WINDOW REGULATOR RIGHT REAR DOOR
180
WINDOW REGULATOR RIGHT REAR DOOR
210
SCREW
210
SCREW , Replaced By: N914114006006
215
WINDOW REGULATOR RAIL RIGHT
217
GROMMET CABLE PASSAGE THRU CENTRAL PILLARS
219
GROMMET (CABLE HARNESS THRU REAR DOOR)
223
WINDOW RUN RIGHT REAR DOOR
240
PANELLING RIGHT REAR DOOR
280
BRACKET
280
FIXTURE , Replaced By: A1098050114
283
PLASTIC PIPE , Replaced By: A0009870527
283
PLASTIC PIPE FROM CENTRAL PILLAR TO REAR DOOR 500 MM, ORDER BY THE METER STATE COLOR NUMBER WHEN ORDERING
287
RELAY
289
BRACKET
291
BRACKET (ADDITIONAL FUSE BOX), FROM CHASSIS: 111.021,023 083954 UP TO CHASSIS: 111.024,026 004206 111.025 004214 FROM CHASSIS:SEE SA 55787
295
FUSE BOX , Replaced By: A0005456701
295
FUSE BOX , Replaced By: A0005457101
295
FUSE BOX , Replaced By: A0005459901
295
FUSE BOX , FROM CHASSIS:114.010 031095 114.015 033617 UP TO CHASSIS: 114.010 044486 114.023 001704
295
FUSE BOX BIPOLAR,K 100807 MIT AUSNANME VON K 093739
298
SWITCH FRONT DOOR, 4-POLE, UP TO CHASSIS: 111.021,023 088724 112.021,023 009135 FROM CHASSIS: 112.021,023 009136 SEE STANDARD VERSION UP TO CHASSIS: 110.000,001,010 188149 110.002,003,005,011 031989 110.100,101,104,110 352118 111.010 106622
305
SWITCH FRONT DOOR, UP TO CHASSIS: 111.021,023 088724 112.021,023 009135 FROM CHASSIS: 112.021,023 009136 SEE STANDARD VERSION UP TO CHASSIS: 110.000,001,010 188149 110.002,003,005,011 031989 110.100,101,104,110 352118 111.010 106622
306
SWITCH FRONT DOOR, ONLY APPLICABLE TO 111.021,023 FROM CHASSIS: 111.021,023 088725 UP TO CHASSIS: 111.021,023 UNTIL PRODUCTION STOP 111.024,025 002863 EXCEPT FOR 002123,002193,002327,002402,002539,002546,002726,002731,002744,002748,002757,002760,002763,002797, 002862. FROM CHASSIS:110.000,001,010 188150 110.002,003,005,011 031990 110.100,101,104,110 352119 111.010 106623
310
SWITCH , ONLY APPLICABLE TO 111.021,023 FROM CHASSIS: 111.021,023 088725 UP TO CHASSIS: 111.021,023 UNTIL PRODUCTION STOP 111.024,025 002863 EXCEPT FOR 002123,002193,002327,002402,002539,002546,002726,002731,002744,002748,002757,002760,002763,002797, 002862. FROM CHASSIS:110.000,001,010 188150 110.002,003,005,011 031990 110.100,101,104,110 352119 111.010 106623
320
SWITCH WITH ELECTRIC WINDOW REGULATOR SAFETY SWITCH,CENTRAL CONSOLE
325
COVERING QUADRUPLE TUMBLER SWITCH
328
CASE , UP TO CHASSIS: 108.012 053398 108.014 042066 108.015 002579
329
CASE , FROM CHASSIS:108.012 053399 108.014 042067 108.015 002580 108.016,018,019 000001
333
CASE
333
CASE , Replaced By: A1098210265
333
CASE (ROCKER SWITCH,REAR SIDE)
333
CASE , Replaced By: A1238210265
335
HOSE
355
CABLE CONNECTOR 3-POLE
355
CABLE CONNECTOR , Replaced By: A0015465841, +003N000125004311, +003N000137004202, +003N007985004162
365
GROMMET ELECTRIC CABLE THRU FIRE WALL
365
GROMMET , Replaced By: A0089971781
365
GROMMET
369
PLUG , Replaced By: A0045456528
369
PLUG , Replaced By: A0045456528
369
PLUG , Replaced By: A0095459428, +005A0045456628, +001A0095459528
369
PLUG. PIN BUSHING HOUSING ELECTRIC WINDOW REGULATOR SWITCH
371
PLUG , Replaced By: A0095454028, +002A0015453826, +001A0095454128
371
PLUG HOUSING
373
PLUG STOP LIGHT SWITCH,BIPOLAR
376
CLIP STARTING MOTOR BRANCH-OFF
378
CLIP
381
GROMMET BATTERY CASE
383
LOOM TIE
383
LOOM TIE , Replaced By: A1149970590
384
LOOM TIE
390
CLAMP ELECTRIC CABLE TO BRACKET
393
CLAMP TUBE TO REAR PILLAR
393
CLAMP , Replaced By: A0019951301
405
LOOM TIE , Replaced By: A0019974190
405
LOOM TIE , Replaced By: A0019974390
405
LOOM TIE TO MOUNT PLASTIC PIPING
411
CLAMP ELECTRIC CABLE TO BRACKET
411
CLAMP CABLE HARNESS TO TAIL CENTRAL PIECE
415
CLIP
418
GROMMET PLUG SOCKET
430
CLAMP , Replaced By: A3449957120
433
CLAMP TO MOUNT MAIN CABLE HARNESS
999
RELAY , ALSO APPLICABLE TO VERSION 55705/11-/62 UP TO CHASSIS: 114.022 002348 115.000,002,010 037068 115.015 035901 115.100,102,103,110,112 084963 115.115 038667 FROM CHASSIS,SEE SA 55968
999
FUSE , Replaced By: A0005458334
999
FUSEA16
999
CABLE CONNECTOR , FROM CHASSIS:108.016 050831 108.018 053598 108.019 054235
999
STOP LEFT
999
HOUSING , Replaced By: A0007680975, +001A0009900457, +001N914114006007
999
HOUSING , Replaced By: A0007681075, +001A0009900457, +001N914114006007
999
STOP LEFT
999
HOUSING LEFT
999
ELECTRIC MOTOR , Replaced By: A0008201142
999
ELECTRIC MOTOR , Replaced By: A0018200542
999
ELECTRIC MOTOR , Replaced By: A0018200442
999
GEARING , Replaced By: A0008203107
999
CARBON BRUSH SET , Replaced By: A0008352575
999
CARBON BRUSH SET
999
CLIP CABLE HARNESS TO ROOF RAIL
999
NUT
999
SCREW , Replaced By: N914114006006
999
RIVET , NO LONGER AVAILABLE
999
SCREW , Replaced By: N914114006007
999
LOCK. WASHER ELECTRIC MOTOR TO BRACKET
999
LOCK
999
LOCK LEATHER & IMITATION LEATHER
999
CLAMP ELECTRIC CABLE TO FRONT SEAT
999
GROMMET ,D 314239
999
ELECTRIC MOTOR (REAR SIDE,LEFT), FROM CHASSIS: 111.024,025 002864 ALSO INSTALLED ON 002123,002193,002327,002402,002539,002546,002726,002731,002744,002748,002757,002760,002763,002797, 002862. 111.026,027 FROM CHASSIS 000001
999
SWITCH SINGLE
999
SWITCH , FROM CHASSIS:110.000,001,010 188150 110.002,003,005,011 031990 110.100,101,104,110 352119 111.010 106623, Replaced By: A0018213351
999
SWITCH QUADRUPLE
999
SWITCH ELECTRIC WINDOW REGULATOR,CENTRAL CONSOLE
999
SWITCH ELECTRIC WINDOW REGULATOR,REAR DOORS
999
SWITCH FRONT DOORS
999
PLUG , Replaced By: A0055451328
999
PLUG , Replaced By: A0085453728, +002A0035452626, +001A0085453828
999
PLUG , Replaced By: A0045458628
999
PIN BUSHING HOUSING , Replaced By: A0095458328, +002A0045456628, +001A0095458228
999
PLUG , Replaced By: A0075450028, +004A0035452626, +001A0095452128
999
PLUG , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0065458028, +006A0015453726, +001A0095453028
999
PIN BUSHING HOUSING 4-POLE
999
PIN BUSHING HOUSING 4-POLE, UP TO CHASSIS: 114.005,007,008,015,017 049721 114.010 044486 114.021 003371 114.022 007377 114.023 001704 FROM CHASSIS SEE 10948
999
PIN BUSHING HOUSING , 10/20 UP TO CHASSIS 4 411810,50/60 UP TO CHASSIS 4 414810
999
PIN BUSHING HOUSING
999
PLUG TRIPLE
999
PANELLING LEFT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING , Replaced By: A1087202762
999
PANELLING , Replaced By: A1087202862
999
PANELLING LEFT, FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING LEFT, FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING , Replaced By: A1087208770
999
PANELLING RIGHT FRONT DOOR
999
PANELLING , Replaced By: A1087208870
999
PANELLING , Replaced By: A1087208970
999
PANELLING , Replaced By: A1087209070
999
PANELLING LEFT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING LEFT, FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING ONE-COLORED,LEFT
999
PANELLING LEFT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING RIGHT SINGLE-COLORED AS REQUIRED FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING ONE-COLORED,LEFT
999
PANELLING LEFT, FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING RIGHT SINGLE-COLORED AS REQUIRED FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING TWO-COLORED,LEFT
999
PANELLING LEFT FRONT DOOR
999
PANELLING RIGHT DOUBLE-COLORED AS REQUIRED FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING TWO-COLORED,LEFT
999
PANELLING LEFT FRONT DOOR
999
PANELLING RIGHT DOUBLE-COLORED AS REQUIRED FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
999
PANELLING LEFT FRONT DOOR
999
PANELLING RIGHT FRONT DOOR
