Поз.
Артикул
Описание
1
WINDOW REGULATOR RIGHT
4
WINDOW REGULATOR RIGHT
6
GEARING
10
GEARING
10
GEARING , Replaced By: A0008203107
13
SEAL
17
STOP RIGHT
20
STOP
23
HOUSING RIGHT
23
HOUSING , Replaced By: A0007681075, +001A0009900457, +001N914114006007
26
STOP RIGHT
30
SPRING ,033 053207
33
CONNECTOR
36
ELECTRIC MOTOR
36
PART NAME MISSING , Replaced By: A0008201142
36
ELECTRIC MOTOR , Replaced By: A0008201142
40
ELECTRIC MOTOR , Replaced By: A0018200442
40
ELECTRIC MOTOR RIGHT
42
WINDOW REGULATOR RAIL RIGHT
53
PANELLING RIGHT FRONT DOOR
150
FRAME (QUADRUPLE ROCKER SWITCH), FROM CHASSIS: 111.021,023 083954-088724 UP TO CHASSIS 111.021,023 088724
170
FRAME ROCKER SWITCH, FROM CHASSIS: 111.021,023 083954
178
WINDOW REGULATOR RIGHT REAR DOOR
180
WINDOW REGULATOR RIGHT REAR DOOR
210
SCREW
210
SCREW , Replaced By: N914114006006
215
WINDOW REGULATOR RAIL RIGHT
217
GROMMET CABLE PASSAGE THRU CENTRAL PILLARS
219
GROMMET (CABLE HARNESS THRU REAR DOOR)
223
WINDOW RUN RIGHT REAR DOOR
240
PANELLING RIGHT REAR DOOR
280
FIXTURE , Replaced By: A1098050114
280
BRACKET
283
PLASTIC PIPE , Replaced By: A0009870527
283
PLASTIC PIPE FROM CENTRAL PILLAR TO REAR DOOR 500 MM, ORDER BY THE METER STATE COLOR NUMBER WHEN ORDERING
287
RELAY
289
BRACKET
291
BRACKET (ADDITIONAL FUSE BOX), FROM CHASSIS: 111.021,023 083954 UP TO CHASSIS: 111.024,026 004206 111.025 004214 FROM CHASSIS:SEE SA 55787
295
FUSE BOX BIPOLAR,K 100807 MIT AUSNANME VON K 093739
295
FUSE BOX , FROM CHASSIS:114.010 031095 114.015 033617 UP TO CHASSIS: 114.010 044486 114.023 001704
295
FUSE BOX , Replaced By: A0005459901
295
FUSE BOX , Replaced By: A0005457101
295
FUSE BOX , Replaced By: A0005456701
298
SWITCH FRONT DOOR, 4-POLE, UP TO CHASSIS: 111.021,023 088724 112.021,023 009135 FROM CHASSIS: 112.021,023 009136 SEE STANDARD VERSION UP TO CHASSIS: 110.000,001,010 188149 110.002,003,005,011 031989 110.100,101,104,110 352118 111.010 106622
305
SWITCH FRONT DOOR, UP TO CHASSIS: 111.021,023 088724 112.021,023 009135 FROM CHASSIS: 112.021,023 009136 SEE STANDARD VERSION UP TO CHASSIS: 110.000,001,010 188149 110.002,003,005,011 031989 110.100,101,104,110 352118 111.010 106622
306
SWITCH FRONT DOOR, ONLY APPLICABLE TO 111.021,023 FROM CHASSIS: 111.021,023 088725 UP TO CHASSIS: 111.021,023 UNTIL PRODUCTION STOP 111.024,025 002863 EXCEPT FOR 002123,002193,002327,002402,002539,002546,002726,002731,002744,002748,002757,002760,002763,002797, 002862. FROM CHASSIS:110.000,001,010 188150 110.002,003,005,011 031990 110.100,101,104,110 352119 111.010 106623
310
SWITCH , ONLY APPLICABLE TO 111.021,023 FROM CHASSIS: 111.021,023 088725 UP TO CHASSIS: 111.021,023 UNTIL PRODUCTION STOP 111.024,025 002863 EXCEPT FOR 002123,002193,002327,002402,002539,002546,002726,002731,002744,002748,002757,002760,002763,002797, 002862. FROM CHASSIS:110.000,001,010 188150 110.002,003,005,011 031990 110.100,101,104,110 352119 111.010 106623
320
SWITCH WITH ELECTRIC WINDOW REGULATOR SAFETY SWITCH,CENTRAL CONSOLE
325
COVERING QUADRUPLE TUMBLER SWITCH
328
CASE , UP TO CHASSIS: 108.012 053398 108.014 042066 108.015 002579
329
CASE , FROM CHASSIS:108.012 053399 108.014 042067 108.015 002580 108.016,018,019 000001
333
CASE
333
CASE , Replaced By: A1238210265
333
CASE (ROCKER SWITCH,REAR SIDE)
333
CASE , Replaced By: A1098210265
335
HOSE
355
CABLE CONNECTOR 3-POLE
355
CABLE CONNECTOR , Replaced By: A0015465841, +003N000125004311, +003N000137004202, +003N007985004162
365
GROMMET
365
GROMMET , Replaced By: A0089971781
365
GROMMET ELECTRIC CABLE THRU FIRE WALL
369
PLUG , Replaced By: A0095459428, +005A0045456628, +001A0095459528
369
PLUG , Replaced By: A0045456528
369
PLUG , Replaced By: A0045456528
369
PLUG. PIN BUSHING HOUSING ELECTRIC WINDOW REGULATOR SWITCH
371
PLUG HOUSING
371
PLUG , Replaced By: A0095454028, +002A0015453826, +001A0095454128
373
PLUG STOP LIGHT SWITCH,BIPOLAR
376
CLIP STARTING MOTOR BRANCH-OFF
378
CLIP
381
GROMMET BATTERY CASE
383
LOOM TIE
383
LOOM TIE , Replaced By: A1149970590
384
LOOM TIE
390
CLAMP ELECTRIC CABLE TO BRACKET
393
CLAMP , Replaced By: A0019951301
393
CLAMP TUBE TO REAR PILLAR
405
LOOM TIE TO MOUNT PLASTIC PIPING
405
LOOM TIE , Replaced By: A0019974390
405
LOOM TIE , Replaced By: A0019974190
411
CLAMP CABLE HARNESS TO TAIL CENTRAL PIECE
411
CLAMP ELECTRIC CABLE TO BRACKET
415
CLIP
418
GROMMET PLUG SOCKET
430
CLAMP , Replaced By: A3449957120
433
CLAMP TO MOUNT MAIN CABLE HARNESS
999
SCREW
999
SCREW
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER T-FITTING TO BRACKET
999
SCREW , Replaced By: N304017006026
999
FUSE , Replaced By: A0015457534
999
FUSE , Replaced By: A0005458334
999
CLAMP
999
PART NAME MISSING CABLE HARNESS TO CENTRAL PILLAR
999
INSULATING HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
999
INSULATING HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
999
INSULATING HOSE BLACK 10 MM, ORDER BY THE METER
999
INSULATING HOSE ELECTRONICS AT SUPPORT, ORDER BY THE METER
999
WASHER COVERING TO CYCLONE AIR TRAP
999
WASHER , Replaced By: N009021004207
999
SCREW
999
SCREW , Replaced By: N007985004107
999
SHEET METAL SCREW CABLE CONNECTOR TO RIGHT WHEEL ARCH PANEL
999
SHEET METAL SCREW
999
SHEET METAL SCREW , Replaced By: N007981004233
999
SHEET METAL SCREW , Replaced By: N000000002062
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
SHEET METAL SCREW
999
SHEET METAL SCREW
999
SHEET METAL SCREW BRACKET TO CAB FLOOR
999
TAPPING SCREW
999
TOOTHED WASHER , Replaced By: N006797004333
999
NUT BALL PIVOT TO LEVER
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
SCREW , Replaced By: N304017006026
999
SCREW AT INSTRUMENT PANEL M 4X16,036897
999
LOCK WASHER. SPRING LOCK WASHER ELECTRIC CABLE TO HORN TO 004 542 44 20 /45 20
999
WASHER CABLE HARNESS TO FRONT DOOR INTERIOR PLATE, UP TO CHASSIS: 108.016 082417 108.018 088585 108.057,058 004580 108.019 UNTIL PRODUCTION STOP
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
SCREW ELECTRIC CABLE TO CABLE CONNECTOR
999
SCREW
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
CLAMP
999
CLAMP MAIN CABLE HARNESS TO LEFT SIDE PART
999
LOOM TIE , Replaced By: A1149970290
999
LOOM TIE , Replaced By: A1149970590
999
PART NAME MISSING , Replaced By: A0008201142
999
PAD , Replaced By: A1087680095
999
WASHER , Replaced By: A1087680113
999
CRANK , 000,001,004,010 UP TO CHASSIS 188465,100,101,104,110 UP TO CHASSIS 352550,002,003,005,011 UP TO CHASSIS 032300 EXCEPT FOR SEE FOOTN.25
999
CLAMP , 107.023 UP TO CHASSIS 009336,107.024 UP TO006399,107.043 UP TO CHASSIS 011238,107.044 UP TO CHASSIS 018373,CONTINUED SEEFOOTNOTE 50
999
CASE (ROCKER SWITCH,REAR SIDE)
999
WINDOW REGULATOR LEFT, REAR DOOR
999
WINDOW REGULATOR LEFT, REAR DOOR
999
WINDOW RUN LEFT REAR DOOR
999
WINDOW REGULATOR LEFT
999
FRAME , STATE COLOR NUMBER WHEN ORDERING UP TO CHASSIS: 111.021,023 UNTIL PRODUCTION STOP 111.024,025 002863 EXCEPT FOR 002123,002193,002327,002402,002539,002546,002726,002731,002744,002748,002757,002760,002763,002797, 002862.
999
WINDOW REGULATOR LEFT
999
WINDOW REGULATOR RAIL LEFT
999
FRAME (SINGLE AND QUADRUPLE ROCKER SWITCHES), ONLY APPLICABLE TO 111.021,023 FROM CHASSIS: 111.021,023 088725 UP TO CHASSIS: 111.021,023 UNTIL PRODUCTION STOP 111.024,025 002863 EXCEPT FOR 002123,002193,002327,002402,002539,002546,002726,002731,002744,002748,002757,002760,002763,002797, 002862. FROM CHASSIS:110.000,001,010 188150 110.002,003,005,011 031990 110.100,101,104,110 352119 111.010 106623
999
PANELLING RIGHT
999
PANELLING RIGHT SINGLE-COLORED AS REQUIRED
999
PANELLING LEFT
999
PANELLING ONE-COLORED,LEFT
999
PANELLING RIGHT
999
PANELLING RIGHT DOUBLE-COLORED AS REQUIRED
999
PANELLING LEFT
999
PANELLING TWO-COLORED,LEFT
999
PANELLING RIGHT
999
PANELLING LEFT
999
PANELLING RIGHT SINGLE-COLORED AS REQUIRED
999
PANELLING ONE-COLORED,LEFT
999
PANELLING RIGHT
999
PANELLING LEFT
999
PANELLING RIGHT
999
PANELLING LEFT
999
PANELLING RIGHT DOUBLE-COLORED AS REQUIRED
999
PANELLING TWO-COLORED,LEFT
999
PANELLING RIGHT SINGLE-COLORED AS REQUIRED
999
PANELLING ONE-COLORED,LEFT
999
PANELLING RIGHT
999
PANELLING LEFT
999
PANELLING LEFT REAR DOOR
999
PANELLING LEFT REAR DOOR
999
PANELLING RIGHT REAR DOOR
999
PANELLING LEFT REAR DOOR
999
PANELLING RIGHT REAR DOOR
999
PANELLING LEFT REAR DOOR
999
PANELLING RIGHT REAR DOOR
999
PANELLING LEFT
999
PANELLING RIGHT REAR DOOR
999
PANELLING RIGHT DOUBLE-COLORED AS REQUIRED
999
PANELLING LEFT REAR DOOR
999
PANELLING TWO-COLORED,LEFT
999
PANELLING RIGHT REAR DOOR
999
PANELLING LEFT REAR DOOR
999
PANELLING RIGHT REAR DOOR
999
PANELLING LEFT REAR DOOR
999
PANELLING RIGHT
999
PANELLING LEFT
999
PANELLING RIGHT
999
PANELLING LEFT
999
PANELLING RIGHT REAR DOOR
999
PANELLING RIGHT DOUBLE-COLORED AS REQUIRED
999
PANELLING LEFT REAR DOOR
999
PANELLING TWO-COLORED,LEFT
999
PANELLING RIGHT REAR DOOR
999
PANELLING RIGHT SINGLE-COLORED AS REQUIRED
999
PANELLING LEFT REAR DOOR
999
PANELLING ONE-COLORED,LEFT
999
PANELLING RIGHT REAR DOOR
999
PANELLING RIGHT
999
PANELLING LEFT REAR DOOR
999
PANELLING LEFT
999
PANELLING RIGHT
999
PANELLING LEFT
999
PANELLING RIGHT
999
PANELLING LEFT
999
PANELLING RIGHT
