Поз.
Артикул
Описание
32
STEERING KNUCKLE LEFT
40
CYLINDRICAL PIN
48
GREASE NIPPLE INTERMEDIATE LEVER
56
GREASE NIPPLE FOR SPRING
64
SPACER WASHER AS REQUIRED 1.7 MM
72
REPAIR KIT STEERING KNUCKLE
80
REPAIR KIT UPPER TRANSVERSE CONTROL ARM
88
REPAIR KIT LOWER CONTROL ARM
96
GREASE NIPPLE INTERMEDIATE LEVER
104
LOCK
112
NUT BRACKET TO SIDE MEMBER,K 035196
112
NUT , Replaced By: N308673014001
120
WHEEL HUB
128
RETAINER
134
SEAL RING
142
NUT
150
HUB CAP
158
CONTACT SPRING FRONT WHEEL HUB TO STEERING KNUCKLE
182
REPAIR KIT , Replaced By: A1073300051
182
REPAIR KIT FRONT WHEEL BEARING
190
TRANSVERSE CONTROL ARM BOTTOM LEFT
198
SEAL RING
206
SCREW
214
LOCK WASHER FITTING TO BRACKET
222
NUT , Replaced By: N308673012002
222
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
230
GREASE NIPPLE INTERMEDIATE LEVER
238
PIN
244
SEAL RING
252
NUT
260
COTTER PIN
268
REPAIR KIT LOWER CONTROL ARM PIVOT PIN
274
TRANSVERSE CONTROL ARM TOP
282
SCREW
290
LOCK
298
WASHER HUB CAP TO BRACKET
306
SEAL RING
314
GREASE NIPPLE FOR SPRING
322
SCREW COLLAR
330
PIN
338
SEAL RING
346
WASHER
354
WASHER
362
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
370
NUT
370
NUT , Replaced By: N304032010002
378
LOCK
386
SCREW COVER PLATE TO COVER PLATE M 6 X 10
386
SCREW , Replaced By: N304017006034
392
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
400
REPAIR KIT UPPER CONTROL ARM PIVOT PIN
408
TIE ROD
408
TIE ROD , NO LONGER AVAILABLE
416
CLAMP , Replaced By: A0003384245
416
CLAMP JOINT TO TIE ROD,063899-073467
422
BALL JOINT , Replaced By: A0003385210, +001N913002010002
422
BALL JOINT R.H. THREAD
422
BALL JOINT R.H. THREAD
430
BALL JOINT L.H. THREAD, 000,003,007,102,103,105,200 10/50,12/52 A 063107 20/60,22/62 A 072609 083,086,093,183,190,193,280,283 F 007679
430
BALL JOINT L.H. THREAD, 023 128307 EXCEPT FOR 127479,127481,127553,127564,127586,127637,127646,127652,127654,127657,127661,127664,127669,127671, 127673,127675,127676,127678,127684,127687,127689,127690,127692-127696,127698,127701,127702,127704, 127705,127708-127727,127729-127892,127894-128306. 033 052425 EXCEPT FOR 052340,052362,052366,052367,052373-052375,052380,052382,052383,052386-052388,052393-052398,052400- 052404,052406-052423.
430
BALL JOINT , 003 114309 007 106209 093 012242 102,103 359715 105 289849 183 023856 190 027445 193 012550 200 125617 280 005879 283 013383 000,003,007,102,103,105,200 10/50,12/52 A 063106 20/60,22/62 A 072608 083,086,093,183,190,193,280,283 F 007678, Replaced By: A0003385010, +001N913002010002
438
REPAIR KIT TIE ROD BOOT AND DRAG LINK BOOT,RESP., 000,003,007,102,103,105,200 10/50,12/52 A 063106 20/60,22/62 A 072608 083,086,093,183,190,193,280,283 F 007678
446
NUT
454
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
486
RUBBER BUFFER
999
CLAMPING RING BOTTOM, NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
CLAMPING RING TOP, NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
BOOT , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
TIE ROD , Replaced By: A1153300703
999
TAPERED ROLLER BEARING INSIDE,F 023121 ALSO INSTALLED ON F 027127
999
TAPERED ROLLER BEARING OUTSIDE,F 023121 ALSO INSTALLED ON F 027127
999
STEERING KNUCKLE RIGHT
999
HALF FRONT AXLE LEFT, MIND RANGE OF DELIVERY NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS
999
HALF FRONT AXLE , NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS
999
WASHER
999
BRAKE DISC , 016 FROM CHASSIS 075176,018,019 FROM CHASSIS 081819
999
REPAIR KIT , Replaced By: A1103300218, +001A1103300318
999
RUBBER MOUNTING
999
TRANSVERSE CONTROL ARM BOTTOM RIGHT
999
HALF FRONT AXLE , 016 UP TO CHASSIS 088514, 018 UP TO CHASSIS 094050, 067,068 UP TO CHASSIS 009896 016 FROM CHASSIS 075176,018,019 FROM CHASSIS 081819, Replaced By: A1083301298, +001A0005867242
999
HALF FRONT AXLE , 005158, Replaced By: A1083301398, +001A0004206720
999
RETAINER
999
KINGPIN , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
BUSHING BOTTOM
999
PIN
999
PIN LOWER CONTROL ARMS
999
SCREW COLLAR THREAD O. D. 30.9 MM
999
SCREW COLLAR THREAD O. D. 29.9 MM
999
RUBBER MOUNTING
999
HUB CAP , Replaced By: A1083340025, +002A2015470085
999
TIE ROD , NO LONGER AVAILABLE
999
TIE ROD , Replaced By: A1073300103, +002N913002010002
999
RING
999
LOCK
999
ECCENTRIC BUSHING
999
SPACER RING , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
THRUST WASHER BOTTOM, NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
DUST CAP , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
THRUST WASHER TOP, NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
SCREW COLLAR THREAD O. D. 29.9 MM
999
SCREW COLLAR THREAD O. D. 30.9 MM
999
SCREW , ON SPECIAL REQUEST, FLOOR SHIFT
999
SPACER WASHER AS REQUIRED 2.3 MM
999
SPACER WASHER AS REQUIRED 2.5 MM
999
SPACER WASHER AS REQUIRED 2.7 MM
999
SPACER WASHER AS REQUIRED 1.9 MM
999
SPACER WASHER AS REQUIRED 2.1 MM
999
BUSHING TOP
999
STEERING KNUCKLE SUPPORT
999
LOCK WASHER
999
SPRING WASHER BRACKET TO TIMING CASE
999
SCREW BRACKET TO FRAME SIDE MEMBER M 8X75
999
NUT
999
NUT , Replaced By: N308673012002
999
NUT
999
SCREW , Replaced By: N000960012225
999
SCREW ENGINE TO ENGINE FRONT SUPPORT
999
NUT BRACKET TO CROSS MEMBER
