Поз.
Артикул
Описание
101
STEERING BOX
105
SEAL RING , Replaced By: A0139973648
105
SEAL RING
109
NEEDLE BEARING , WITH L.H.D,ON MODELS 111.024,025 FROM STEERING 198396 WITH R.H.D,ON MODELS 111.024,025 FROM STEERING 199281
113
SCREW PLUG MEASURING CONNECTION
117
SEAL RING SCREW PLUG
129
PISTON WITH WORM AND SLEEVE VALVE
133
STEERING BOX COVER
137
GASKET
141
THRUST WASHER
145
LOCK
149
THRUST WASHER
153
ROLLER BEARING
157
NEEDLE BEARING
161
THREADED INSERT
165
LOCK
169
NUT
173
SCREW BALL GUIDE TO PISTON
177
LOCK BALL GUIDE TO PISTON
181
PISTON , WITH L.H.D.,FROM STEERING 003126
185
ANGULAR CONTACT BEARING
189
LOCK
193
COVER
197
SCREW COLLAR
201
SPRING
205
THRUST WASHER *** 1.0MM
209
LOCK
213
CLAMPING PIN
217
WASHER
221
SPRING
225
LOCK
229
SCREW GROUND STRAP TO CAB CROSS MEMBER M 10X25
233
LOCK WASHER , Replaced By: N912004010102
237
BLEEDER VALVE OIL DRAIN
241
PROTECTIVE CAP ,5 962906
241
PROTECTIVE CAP , Replaced By: A0004217187
245
COVER
293
STEERG. WORM SECTOR SHAFT , WITH L.H.D,ON MODELS 111.024,025 FROM STEERING 198396 WITH R.H.D,ON MODELS 111.024,025 FROM STEERING 199281
297
SCREW
301
SPRING
305
THRUST PIECE
309
THRUST WASHER , UP TO CHASSIS: 023 009058
313
LOCK
317
STEERING BOX COVER
321
NEEDLE BEARING
325
LOCK BELL HOUSING
329
SPRING
333
SCREW CONNECTOR TO CYLINDER HEAD M 8X25
337
SPRING WASHER , Replaced By: N000137008212
341
NUT , WITH L.H.D,ON MODELS 111.024,025 FROM STEERING 198396 WITH R.H.D,ON MODELS 111.024,025 FROM STEERING 199281
345
SEAL RINGTO 001 431 72 14
349
NUT , WITH L.H.D,ON MODELS 111.024,025 FROM STEERING 198396 WITH R.H.D,ON MODELS 111.024,025 FROM STEERING 199281
353
NUT , WITH L.H.D,ON MODELS 111.024,025 FROM STEERING 198396 WITH R.H.D,ON MODELS 111.024,025 FROM STEERING 199281
357
GASKET KIT
999
BOOT , Replaced By: A0003381397
999
CLAMPING RING BOTTOM, NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
CLAMPING RING TOP, NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
BOOT , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
TUMBLER WITHOUT LOCK UNDEFINED, 000,001,004,010,016 FROM CHASSIS 190318 ALSO INSTALLED ON,SEE FOOTN.10,10/50,12/52,100,101,104,110,116 FROM CHASSIS 358854 ALSO INSTALLED ON,SEE FOOTN.11,AND FOOTN.9
999
STEERING LOCK , FROM CHASSIS: 016 036917, 018 037772, 019 039435, Replaced By: A1164620830, +001A1164620023, +001A1164620279, +001A1236890056, +001A1236890080
999
STEERING LOCK , Replaced By: A1164620830, +001A1164620023, +001A1164620279, +001A1236890056, +001A1236890080
999
SEAL RING STEERING NUT BEARING 12.4X1.78 MM
999
SEAL RING
999
SEAL RING , Replaced By: A0139973648
999
SEAL RING
999
SEAL RING , Replaced By: A0149976148
999
SEAL RING
999
SEAL RING
999
SEAL RING STEERING NUT BEARING 75X3 MM
999
SEAL RING
999
SEAL RING
999
SEAL RING
999
SEAL RING STEERING WORM SECTOR SHAFT TO COVER 10X3 MM
999
COVERTO 009 545 56 28
999
SEAL RING
999
SEAL RINGTO 388 476 71 69
999
PROTECTIVE PLATE , 016 FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 21, 018 FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 22, 019 FR OM CHASSIS 029326
999
STEERING SHAFT , FROM CHASSIS 072975
999
STEER. COLUMN JACKET TUBE , 016 FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 21, 018 FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 22, 019 FR OM CHASSIS 029326
999
BOOT CABLE PASSAGE THRU STEERING COLUMN JACKET TUBE, 012 FROM CHASSIS 073567, 016 FROM CHASSIS 016180, 018 FROM CHASSIS 015555
999
STEERING INTERMEDIATE ARM , 016 FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 21, 018 FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 22, 019 FR OM CHASSIS 029326
999
PITMAN ARM
999
DRAG LINK
999
WASHER
999
SEAL RING
999
GASKET
999
THRUST WASHER 1,1 MM, AS REQUIRED
999
THRUST WASHER 1,2 MM, AS REQUIRED
999
THRUST WASHER 1,3 MM, AS REQUIRED
999
THRUST WASHER 1,4 MM, AS REQUIRED
999
THRUST WASHER 1,6 MM, AS REQUIRED
999
THRUST WASHER 1,7 MM, AS REQUIRED
999
THRUST WASHER 1,8 MM, AS REQUIRED
999
THRUST WASHER 1,9 MM, AS REQUIRED
999
THRUST WASHER 2,0 MM, TO BE ADAPTED DURING ASSEMBLY
999
CLAMPING PIECE
999
PAD BLACK, UP TO CHASSIS 019587 STEERING WHEEL: BLACK UP TO CHASSIS 019541 STEERING WHEEL: WHITE
999
STEERING WHEEL , FROM CHASSIS: 073 002632
999
STEERING LOCK , 023 009623 024 007307 043 011383 WITH CENTRAL LOCKING MECHANISM UP TO CHASSIS: 022 005192 023 012497 024 021807 026 000025 042 004216 043 013577 044 047075 LESS CENTRAL LOCKING MECHANISM UP TO CHASSIS: 022 005267 023 012544 024 022006 026 000061 042 004280 043 013577 044 047451 IN PLACE OF 116 462 02 79 WITH LOCK DEFINED WITH KEY BITTING HD,USE 116 462 01 79, AND WITH KEY BITTING HA,USE 116 460 06 04, Replaced By: A1164620830, +001A1164620023, +001A1164620279, +001A1236890056, +001A1236890080
999
TUMBLER WITHOUT LOCK UNDEFINED, FOR MASTER KEY,SEE GROUP 72 FROM CHASSIS: 115.000,002,010 099406 115.015 123862 115.100,102,103,110,112 259276 115.115 130163 115.005,017,105,107,108,117,119 000001 UP TO CHASSIS: 000,002,010UNTIL PRODUCTION STOP 005,017 016519 015 223255 UP TO CHASSIS: 100,102,103,112UNTIL PRODUCTION STOP 110 421345 105,107,108,117 032884 115 228860 119 034132
999
BOOT
999
STEERING LOCK , Replaced By: A1164621030
999
STEERING LOCK
999
BUSHING ,F 189738
999
PROTECTIVE RING
999
PROTECTIVE RING , Replaced By: A6019900540
999
SCREW
999
WASHER
999
SPRING
999
SPRING
999
BUSHING
999
INTERMEDIATE LEVER REPAIR KIT
999
WASHER
999
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
999
COTTER PIN DRAG LINK TO LEVER
999
SPRING WASHER , Replaced By: N000137006204
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
SCREW , Replaced By: N000912006064
999
SCREW
999
SCREW
999
SCREW BRACKET TO AIR INTAKE PIPE
999
NUT CYLINDER TO BRACKET TO0002902112
999
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
999
SEAL RING LINE CONNECTION
999
SEAL RING
999
NUT BATTERY MOUNTING
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
COMBINATION BOLT CABLE TO FUSE BOX
999
CLAMP , Replaced By: N000000000667
