Поз.
Артикул
Описание
7
REAR FENDER LEFT
12
REINFORCEMENT LEFT
18
SUPPORT OUTSIDE LEFT
25
END PIECE LEFT
31
PILLAR , 016 UP TO CHASSIS 049099, 018 UP TO CHASSIS 052477, 019 UP TO CHASSIS 052616, Replaced By: A1086300910
37
PILLAR CENTRAL LEFT
43
HINGE TOP LEFT, 012 FROM CHASSIS 000081,014 FROM CHASSIS 000024
48
BUSHING
55
PIN
55
HINGE PIN , Replaced By: A1157330015
59
GREASE NIPPLE
63
HINGE BOTTOM, 012 FROM CHASSIS 000081, 014 FROM CHASSIS 000024, 015 FROM CHASSIS 000015
70
ROOF RAIL INSIDE LEFT
75
ROOF RAIL OUTSIDE LEFT
81
ROOF RAIL LEFT
87
PILLAR OUTSIDE LEFT
92
WHEELHOUSE REAR LEFT
97
WHEELHOUSE REAR OUTSIDE LEFT
102
ROOF RAIL INSIDE LEFT
105
STRUT
110
BOTTOM SPARE WHEEL WELL,LEFT
115
CLAMP ON LEFT SPARE WHEEL WELL PLATE
120
STRUT
125
BUFFER REAR SEAT BENCH BACKREST FRAME MOUNTING, 016 UP TO CHASSIS 043198,018 UP TO CHASSIS 044203,019 UP TO CHASSIS 044488
131
SIDE MEMBER , Replaced By: A1096300140
999
INSULATING HOSE
999
ROOF RAIL RIGHT
999
SIDE MEMBER , Replaced By: A1096370240
999
BRACING , 018 FROM CHASSIS 002020, ALSO INSTALLED ON 001907, 001911
999
CLAMP AT STRUT, 018 FROM CHASSIS 002020, ALSO INSTALLED ON 001907, 001911
999
ROOF RAIL INSIDE RIGHT
999
ROOF RAIL OUTSIDE RIGHT
999
SUPPORT OUTSIDE RIGHT
999
ROOF RAIL , UP TO CHASSIS 038030, Replaced By: A1096370445, +001A1096300635, +001A1096300835
999
ROOF RAIL ,038030, Replaced By: A1096370345, +001A1096300535, +001A1096300735
999
HINGE TOP RIGHT, 012 FROM CHASSIS 000081, 014 FROM CHASSIS 000024, 015 FROM CHASSIS 000015
999
HINGE PIN , Replaced By: A1157330015
999
WHEELHOUSE REAR OUTSIDE RIGHT
999
ROOF RAIL OUTSIDE RIGHT
999
ROOF RAIL INSIDE RIGHT
999
ROOF RAIL RIGHT
999
RECESS SPARE WHEEL WELL,RIGHT
999
END PIECE RIGHT
999
REAR FENDER RIGHT
999
ROOF RAIL OUTSIDE LEFT
999
ROOF RAIL , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1096300735
999
ROOF RAIL LEFT
999
RECESS , Replaced By: A1086300042
999
PILLAR RIGHT
999
PILLAR LEFT
999
PILLAR RIGHT
999
PILLAR , 016 UP TO CHASSIS 049099,018 UP TO CHASSIS 052477,019 UP TO CHASSIS 052616, Replaced By: A1086301010
999
WHEELHOUSE REAR RIGHT
999
ROOF RAIL INSIDE RIGHT
999
REINFORCEMENT RIGHT
999
PILLAR OUTSIDE RIGHT
