Поз.
Артикул
Описание
10
DOOR SHELL RIGHT
15
HINGE LEFT FRONT DOOR
15
HINGE , Replaced By: A1087200137
25
SCREW , UP TO CHASSIS: 000,002,010 083223 015 097126 100,102,103,110,112 212123 115 104333
29
SCREW BRACKET TO CROSS CONNECTION STRUT
29
SCREW , Replaced By: N304017008034
34
LOCK WITH INTERIOR LOCKING MECHANISM,RIGHT
42
LOCKING ROD
45
LOCK PULL ROD TO DOOR LOCK
49
ROD , Replaced By: A1087230269
56
CLIP , Replaced By: A0069886378
56
CLIP
60
LOCK PULL ROD TO DOOR LOCK
65
NUT RETAINER , Replaced By: A0009907191
65
NUT RETAINER , Replaced By: A3229900091
71
EDGING RIGHT
78
LOCKING EYE RIGHT, FROM CHASSIS: 010 031987 ALSO INSTALLED ON: 026127-026384 110 071329 ALSO INSTALLED ON: 057116-057347
84
PLATE , UP TO CHASSIS: 000,002,010 032736 EXCEPT FOR 026127-026384 015 030665 EXCEPT FOR 023687-023770 100,102,103,110,112 073207 EXCEPT FOR 057116-057347 115 033411 EXCEPT FOR 026238-026496
90
RUBBER BUFFER AS REQUIRED,5.5 MM, 000,001,002,003,004,005,010,011 FROM CHASSIS 066085,100,101,104,110 FROM CHASSIS 102826
95
RUBBER BUFFER , 010 FROM CHASSIS 050273,012 FROM CHASSIS 111521
102
INTERIOR HANDLE ASSEMBLY RIGHT
108
NUT RETAINER , Replaced By: A0009907191
108
NUT RETAINER , Replaced By: A3229900091
112
LOCK. WASHER ELECTRIC MOTOR TO BRACKET
120
ESCUTCHEON RIGHT
130
INSERT RIGHT
133
KNOB , 023 116973 033 048510 123 097280 130 120563
136
DOOR CHECK
139
ROLLER , Replaced By: A3147230068
139
ROLLER
142
PIN
145
WASHER DOOR CHECK TO FRONT PANEL PILLAR
152
LOCK
165
DOOR HANDLE LESS KEY,RIGHT, STATE LOCK NUMBER WHEN ORDERING
169
PIN
175
KEY , STATE LOCK NUMBER WHEN ORDERING THE LOCK NUMBER MUST NOT BE IDENTICAL WITH THE LOCK NUMBER(MASTER AND SECONDARY DEY SYSTEM)OF THE CAR
178
KEY SECONDARY KEY HUF, STATE LOCK NUMBER WHEN ORDERING
184
DISC SPRING
188
SCREW , Replaced By: N000912006095
188
SCREW DOOR HANDLE TO DOOR
195
PAD FRONT, 012 FROM CHASSIS 044562,014 FROM CHASSIS 035569
199
PAD REAR RIGHT, 012 FROM CHASSIS 044562, 014 FROM CHASSIS 035569, 015 FROM CHASSIS 002425
210
VENTILATOR WINDOW RIGHT, 016 FROM CHASSIS 080592, 018 FROM CHASSIS 086841, 057,058 FROM CHASSIS 003450
216
SEAL RIGHT
222
VENTILATOR WINDOW RIGHT, 016 FROM CHASSIS 080592, 018 FROM CHASSIS 086841, 057,058 FROM CHASSIS 003450
228
MOUNTING RIGHT, UP TO CHASSIS: 000,002,010 081998 015 095544 100,102,103,110,112 209525 115 102596
236
MOUNTING INSIDE
240
SPRING
246
SPRING
251
PLATE
258
FASTENER RIGHT
264
FASTENER , 012 FROM CHASSIS 058444 ALSO INSTALLED ON,SEE FOOTNOTE 056,014 FROM CHASSIS 045294 ALSO INSTALLED ON,SEE FOOTNOTE 057
268
PIN
272
LOCK PULL TO FASTENER
272
LOCK , Replaced By: N912002008003
275
ROD
278
LOCK
285
NUT RETAINER , Replaced By: A3229900091
285
NUT RETAINER , Replaced By: A0009907191
292
GUIDE RAIL RIGHT
297
LOCK. WASHER ELECTRIC MOTOR TO BRACKET
302
SEALING SECTION 2240 MM, ORDER BY THE METER
308
CLIP
312
WINDOW REGULATOR RIGHT
320
GEARING
324
SCREW
328
GEARING
331
SEAL
338
STOP RIGHT
341
STOP
350
HOUSING LEFT
356
SPRING ,033 053207
359
CONNECTOR
364
ELECTRIC MOTOR
367
CARBON BRUSH SET , Replaced By: A0008352575
367
CARBON BRUSH SET
372
ELECTRIC MOTOR RIGHT
378
WINDOW REGULATOR RAIL RIGHT
382
SLIDE , Replaced By: A1155860072
386
WASHER , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
390
WASHER , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
394
LOCK. WASHER ELECTRIC MOTOR TO BRACKET
400
GLASS PANE RIGHT
404
RETAINING RAIL
408
RUBBER MOULDING
420
SEALING RAIL 2200 MM
424
CLIP
428
CLIP , Replaced By: A1159880078
999
SCREW
999
SCREW
999
LOCK PLATE CONSOLE TO REAR PANELLING,TOP
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
SPRING WASHER SHIFTING CYLINDER TO YOKE
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
SCREW PUMP TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021006208
999
SCREW
999
SCREW
999
SCREW
999
SCREW
999
SCREW
999
SHEET METAL SCREW
999
SHEET METAL SCREW DOOR LINING TO REAR DOORS
999
SHEET METAL SCREW
999
SHEET METAL SCREW
999
SHEET METAL SCREW GARNISH MOULDING TO COVERING
999
SHEET METAL SCREW , Replaced By: N007982003209
999
SHEET METAL SCREW GLOVE COMPARTMENT TO INSTRUMENT PANEL
999
SHEET METAL SCREW
999
SHEET METAL SCREW COVERING TO HOUSING
999
SHEET METAL SCREW ANTENNA CABLE TO REAR INSIDE PILLAR
999
SHEET METAL SCREW
999
TOOTHED WASHER MASKED STOP LAMP
999
TOOTHED WASHER CABLE TO FUSE BOX
999
NUT BALL PIVOT TO LEVER
999
SCREW , Replaced By: N304017006034
999
SCREW , Replaced By: N304017006018
999
SCREW COVER PLATE TO BRACKET
999
WASHER
999
WASHER
999
WASHER BRACKET TO SUPPORT
999
WASHER , Replaced By: N000125004319
999
SCREW
999
REPAIR KIT
999
SEAL INSIDE 4000 MM
999
MOLDED PIECE , Replaced By: A0029888378
999
SEAL , FROM CHASSIS: 010 076074 110 193042 017,117 000001
999
CLIP , 003030
999
CLIP
999
SEAL
999
SEAL , Replaced By: A1167250198
999
PLATE 1.5 MM, FROM CHASSIS: 010 031987, ALSO INSTALLED ON: 026127-026384 110 071329, ALSO INSTALLED ON: 057116-057347
999
PLATE 0.5 MM, FROM CHASSIS: 010 031987, ALSO INSTALLED ON: 026127-026384 110 071329, ALSO INSTALLED ON: 057116-057347
999
PLATE , Replaced By: A1157230611
999
PLATE , Replaced By: A1157230511
999
LOCKING EYE LEFT
999
LOCK CENTRAL DOOR,001274
999
LOCK LEFT AT CENTRAL SIDE DOOR,001274
999
LOCKING EYE , Replaced By: A1157200604, +001A1157230511
999
LOCK WITH INTERIOR LOCKING MECHANISM,LEFT
999
LOCKING EYE , Replaced By: A1157200504, +001A1157230511
999
PLATE
999
REPAIR KIT , Replaced By: A1237200114
999
DISC SPRING
999
RUBBER BUFFER 8.5 MM AS REQUIRED, 000,001,002,003,004,005,010,011 FROM CHASSIS 066085,100,101,104,110 FROM CHASSIS 102826
999
RUBBER BUFFER 7.5 MM AS REQUIRED, 000,001,002,003,004,005,010,011 FROM CHASSIS 066085,100,101,104,110 FROM CHASSIS 102826
999
RUBBER BUFFER PIN BUSHING
999
GARNISH MOULDING , Replaced By: A1087280631
999
GARNISH MOULDING , Replaced By: A1087280531
999
GARNISH MOULDING , Replaced By: A1087280431
999
GARNISH MOULDING , Replaced By: A1087280331
999
GARNISH MOULDING TOP LEFT
999
GARNISH MOULDING LEFT
999
PANELLING RIGHT, STATE COLOR AND CHASSIS NO. WHEN ORDERING ENCLOSE SAMPLE OF VENEER WHEN ORDERING 016 UP TO CHASSIS 001858 EXCEPT FOR, SEE FOOTNOTE 44, 018 UP TO CHASSIS 002019 EXCEPT FOR 001907,001911
999
PANELLING LEFT, STATE COLOR AND CHASSIS NO. WHEN ORDERING ENCLOSE SAMPLE OF VENEER WHEN ORDERING 016 UP TO CHASSIS 001858 EXCEPT FOR, SEE FOOTNOTE 44, 018 UP TO CHASSIS 002019 EXCEPT FOR 001907,001911
999
PANELLING (VELOURS), RIGHT, STATE COLOR AND CHASSIS NO. WHEN ORDERING ENCLOSE SAMPLE OF VENEER WHEN ORDERING 016 UP TO CHASSIS 001858 EXCEPT FOR, SEE FOOTNOTE 45, 018 UP TO CHASSIS 002019 EXCEPT FOR 001907, 001911
999
PANELLING (VELOURS), LEFT, STATE COLOR AND CHASSIS NO. WHEN ORDERING ENCLOSE SAMPLE OF VENEER WHEN ORDERING 016 UP TO CHASSIS 001858 EXCEPT FOR, SEE FOOTNOTE 45, 018 UP TO CHASSIS 002019 EXCEPT FOR 001907, 001911
999
PANELLING , STATE COLOR AND CHASSIS NO.WHEN ORDERING, Replaced By: A1087202551
999
PANELLING (VELOURS), LEFT, 016 FROM CHASSIS 001859 EXCEPT FOR, SEE FOOTNOTE 45, 018 FROM CHASSIS 002020 EXCEPT FOR 001907, 001911 STATE COLOR AND CHASSIS NO. WHEN ORDERING ENCLOSE SAMPLE OF VENEER WHEN ORDERING
999
WINDOW REGULATOR RIGHT
999
PANELLING REAR LEFT, ENCLOSE SAMPLE OF VENEER WHEN ORDERING
999
WINDOW REGULATOR LEFT
999
PANELLING TOP LEFT, ENCLOSE SAMPLE OF VENEER WHEN ORDERING
999
PANELLING FRONT LEFT, ENCLOSE SAMPLE OF VENEER WHEN ORDERING
999
DOOR SHELL LEFT
999
WINDOW REGULATOR LEFT
999
FRAME LEFT
999
WINDOW REGULATOR RAIL LEFT
999
GARNISH MOULDING TOP LEFT, ENCLOSE SAMPLE OF VENEER WHEN ORDERING
999
WASHER
999
CLIP , Replaced By: A1159880078
999
PAD REAR LEFT, 012 FROM CHASSIS 044562,014 FROM CHASSIS 035569
999
PAD , 012 FROM CHASSIS 044562,014 FROM CHASSIS 035569, Replaced By: A1077661005
999
ESCUTCHEON LEFT
999
INSERT LEFT
999
DOOR HANDLE WITH KEY,RIGHT, WITH LOCK NUMBER UNDEFINED,FOR STORAGE PURPOSES ONLY
999
DOOR HANDLE WITH KEY,LEFT, WITH LOCK NUMBER UNDEFINED,FOR STORAGE PURPOSES ONLY
999
DOOR HANDLE LESS KEY,LEFT, STATE LOCK NUMBER WHEN ORDERING
999
INTERIOR HANDLE ASSEMBLY LEFT, 000,001,004,010 FROM CHASSIS 188150,100,101,104,110 FROM CHASSIS 352119,002,003,005,011 FROM CHASSIS 031990
999
GARNISH MOULDING REAR LEFT
999
GARNISH MOULDING TOP LEFT
999
PAD
999
GARNISH MOULDING FRONT LEFT
999
GARNISH MOULDING DOOR EDGE,LEFT
999
PAD , Replaced By: A1087280397
999
SEAL , Replaced By: A1087280180
999
RAIL LEFT
999
SEAL CENTRAL PILLAR,LEFT
999
SEAL , Replaced By: A0029894185
999
MOUNTING LEFT, UP TO CHASSIS: 000,002,010 081998 015 095544 100,102,103,110,112 209525 115 102596
999
SEAL LEFT
999
GLASS PANE LEFT CRANK OPERATED WINDOW
999
SEAL , Replaced By: A1157251298
999
HINGE PLATE , Replaced By: A1087200137, +001A1087200237
999
PULL ROD (FRONT DOOR)
999
HINGE PLATE , Replaced By: A1087200137, +001A1087200237
999
HINGE PLATE , Replaced By: A1087200137, +001A1087200237
999
EDGING
