Поз.
Артикул
Описание
157
REAR AXLE TUBE RIGHT, 000628
162
BUSHING
226
BOOT
231
BOOT SPLIT
236
CLIPTO 343 357 00 22
271
BRAKE DISC
281
PIN , 000,001,100,101 FROM REAR AXLE 000287, 010 FROM REAR AXLE 129303, 110 FROM REAR AXLE 087840
286
SPACER TUBE
291
SPACER WASHER 2.0 MM
295
SPACER WASHER , Replaced By: A1803511452
295
SPACER WASHER 2.0 MM
300
SPACER RING
304
RUBBER RING
308
PIN
312
LOCK WASHER TAIL LAMP TO BRACKET
317
NUT
321
LOCK
327
EXPANSION PLUG
331
SCREW PLUG
336
LOCK
341
GREASE NIPPLE LOCK ANGLE SENSOR
345
GREASE NIPPLE
351
RUBBER MOUNTING , 000,001,100,101 FROM REAR AXLE 000287, 010 FROM REAR AXLE 129303, 110 FROM REAR AXLE 087840
357
SUPPORT
361
GROOVED PIN
366
SCREW
371
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
391
THRUST ARM LEFT
396
REPAIR KIT
401
RUBBER MOUNTING
405
LOCK
409
SCREW
414
RUBBER MOUNTING
418
PAD
422
SCREW PISTON ON TRAILING AXLE
426
LOCK WASHERROCKINGER TYP 59 G140,59 G150
431
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
436
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
441
ROD
446
NUT SHOCK ABSORBER TO LOWER BEARING BRACKET
451
BRACKET
456
RUBBER MOUNTING
460
BRACKET
465
SCREW , Replaced By: N304017010028
465
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
470
SPRING WASHER STEERING COLUMN BRACKET TO CAB
474
SCREW
478
SPRING WASHER CAB FLOOR
478
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
482
RUBBER BUFFER
486
CUP
491
CUP
496
NUT , Replaced By: N308673012002
496
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
501
NUT
505
RUBBER MOUNTING
509
MOUNTING PLATE
512
WASHER PROTECTIVE PLATE TO BRACKET,5 502998
517
LOCK WASHER TAIL LAMP TO BRACKET
521
NUT
525
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
529
NUT , Replaced By: N308673014001
529
NUT BRACKET TO SIDE MEMBER,K 035196
999
CLAMP REAR AXLE HOUSING
999
CLAMP REAR AXLE TUBE
999
SCREW PIPE CLAMP
999
TAPERED ROLLER BEARING
999
TAPERED ROLLER BEARING RING GEAR BEARING
999
TAPERED ROLLER BEARING
999
SEAL RING
999
VALVE
999
AXLE HOUSING
999
RING GEAR AND PINION RATIO: 1:3.46, 003789
999
RING REPAIR SIZE
999
DIFFERENTIAL PINION , Replaced By: A1163530214
999
SNAP RING , 016 FROM CHASSIS 054213, 018,019 FROM CHASSIS 059186
999
AXLE HOUSING , Replaced By: A1093500803, +001A1093570150
999
AXLE HOUSING , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
AXLE HOUSING , Replaced By: A1093501103, +001A1093570150
999
REAR AXLE TUBE LEFT
999
AXLE HOUSING , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
REAR AXLE , NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS
999
REAR AXLE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 108.016 080478 108.018 086710 108.057,058 003381 109.018 005895 109.056 007250 111.026,027 004431 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1093504000
999
THRUST WASHER
999
THRUST WASHER , Replaced By: A1293530962
999
THRUST WASHER , Replaced By: A1293531062
999
SCREW
999
RING GEAR AND PINION
999
THRUST ARM RIGHT
999
SPACER WASHER 1.9 MM AS REQUIRED
999
SPACER WASHER 2.0 MM AS REQUIRED
999
SPACER WASHER AS REQUIRED 2.1 MM
999
SPACER WASHER , Replaced By: A1123531152
999
SPACER WASHER AS REQUIRED 1.6 MM
999
SPACER WASHER AS REQUIRED 1.7 MM
999
SPACER WASHER AS REQUIRED 1.8 MM
999
DOWEL PIN
999
DIFFERENTIAL PINION , Replaced By: A1403530514
999
SCREW
999
THRUST WASHER AS REQUIRED 2,9 MM, WITH LINING ON ONE SIDE
999
THRUST WASHER AS REQUIRED 2,8 MM, WITH LINING ON ONE SIDE
999
SPACER TUBE AS REQUIRED 25.0 MM
999
SPACER WASHER 2.1 MM
999
SPACER TUBE , Replaced By: A1803511653
999
SPACER WASHER 2.2 MM
999
SPACER TUBE AS REQUIRED 25.4 MM
999
SPACER WASHER 2.3 MM
999
SPACER TUBE AS REQUIRED 25.6 MM
999
SPACER WASHER 2.4 MM
999
SPACER TUBE AS REQUIRED 25.8 MM
999
SPACER WASHER 2.5 MM
999
SPACER WASHER 3.0 MM
999
SPACER WASHER AS REQUIRED 2.6 MM
999
SPACER WASHER AS REQUIRED 2.7 MM
999
SPACER WASHER , Replaced By: A1803513052
999
SPACER WASHER AS REQUIRED 2.8 MM
999
SPACER WASHER AS REQUIRED 3.1 MM
999
SPACER WASHER , Replaced By: A1803513152
999
LOCK
999
LOCK
999
LOCK
999
LOCK
999
THRUST WASHER AS REQUIRED 1.40 MM
999
THRUST WASHER AS REQUIRED 1.50 MM
999
THRUST WASHER AS REQUIRED 1.60 MM
999
THRUST WASHER AS REQUIRED 1.70 MM
999
WASHER MOUNTING PLATE TO BODY FLOOR
999
SCREW , Replaced By: N304017008021
999
SCREW BRACKET TO SIDE MEMBER
