Поз.
Артикул
Описание
10
SEAL RING
10
SEAL RING , Replaced By: A0139973648
14
SCREW PLUG MEASURING CONNECTION
15
SEAL RING SCREW PLUG
18
PISTON WITH WORM AND SLEEVE VALVE
19
STEERING BOX COVER
20
GASKET
21
THRUST WASHER
22
LOCK
23
THRUST WASHER
24
ROLLER BEARING
25
NEEDLE BEARING
26
THREADED INSERT
30
LOCK
31
NUT
33
SCREW BALL GUIDE TO PISTON
34
LOCK BALL GUIDE TO PISTON
44
COVER
45
SCREW COLLAR
47
SPRING
48
THRUST WASHER *** 1.0MM
58
LOCK
59
CLAMPING PIN
60
WASHER
61
SPRING
62
LOCK
63
SCREW GROUND STRAP TO CAB CROSS MEMBER M 10X25
64
LOCK WASHER , Replaced By: N912004010102
65
BLEEDER VALVE OIL DRAIN
66
PROTECTIVE CAP , Replaced By: A0004217187
66
PROTECTIVE CAP ,5 962906
67
COVER
73
SEAL RING
74
FITTING RETURN
75
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
76
FITTING DELIVERY LINE
77
SEAL RING VALVE TO VALVE,K 025179
78
SCREW FITTING
79
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
80
SCREW FITTING
81
SEAL RING CHECK VALVE,CONNECTION "1",4 704213
82
SCREW PLUG MEASURING CONNECTION
92
SPRING
93
THRUST PIECE
94
THRUST WASHER , UP TO CHASSIS: 023 009058
95
LOCK
96
STEERING BOX COVER
98
NEEDLE BEARING
101
LOCK BELL HOUSING
103
SPRING
104
SCREW. CAP BOLT COVER TO CASE M8X25
104
SCREW , Replaced By: N000912008202
105
SPRING WASHER , Replaced By: N000137008212
109
SEAL RINGTO 001 431 72 14
115
GASKET KIT
999
BOOT , Replaced By: A0003381397
999
CLAMPING RING BOTTOM, NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
CLAMPING RING TOP, NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
BOOT , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
TUMBLER WITHOUT LOCK UNDEFINED, 000,001,004,010,016 FROM CHASSIS 190318 ALSO INSTALLED ON,SEE FOOTN.10,10/50,12/52,100,101,104,110,116 FROM CHASSIS 358854 ALSO INSTALLED ON,SEE FOOTN.11,AND FOOTN.9
999
COVER , UP TO CHASSIS: 023 008612 UP TO CHASSIS: 073 000003
999
COVER , 077647
999
TUMBLER STATE KEY NO. WHEN ORDERING, UP TO CHASSIS: 023 008612 UP TO CHASSIS: 073 000003
999
STEERING LOCK , FROM CHASSIS: 016 036917, 018 037772, 019 039435, Replaced By: A1164620830, +001A1164620023, +001A1164620279, +001A1236890056, +001A1236890080
999
TUMBLER , 077647
999
STEERING LOCK , Replaced By: A1164620830, +001A1164620023, +001A1164620279, +001A1236890056, +001A1236890080
999
ANGULAR CONTACT BEARING
999
SEAL RING STEERING NUT BEARING 12.4X1.78 MM
999
LOCK
999
SEAL RING
999
SEAL RING , Replaced By: A0139973648
999
SEAL RING
999
SEAL RING , Replaced By: A0149976148
999
SEAL RING
999
SEAL RING
999
SEAL RING STEERING NUT BEARING 75X3 MM
999
NEEDLE BEARING , WITH L.H.D,ON MODELS 111.024,025 FROM STEERING 198396 WITH R.H.D,ON MODELS 111.024,025 FROM STEERING 199281
999
SEAL RING
999
SEAL RING
999
SEAL RING
999
SEAL RING STEERING WORM SECTOR SHAFT TO COVER 10X3 MM
999
PLUG HOUSING 14-POLE
999
COVERTO 009 545 56 28
999
SEAL RING
999
SEAL RINGTO 388 476 71 69
999
STEERING BOX COVER WITH NOZZLE
999
PROTECTIVE PLATE , 016 FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 21, 018 FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 22, 019 FR OM CHASSIS 029326
999
COVERING
999
STEERING SHAFT , FROM CHASSIS 072975
999
STEER. COLUMN JACKET TUBE , 016 FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 21, 018 FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 22, 019 FR OM CHASSIS 029326
999
GASKET , 016 FROM CHASSIS 027623 ALSO INSTALLED ON, SEE GROUP 22/24, FOOTNOTE 6, 018 FROM CHASSIS 028986 ALSO INSTALLED ON, SEE GROUP 2 2/24 FOOTNOTE 7, 019 FROM CHASSIS 029326
999
BOOT , FROM CHASSIS 001859, ALSO INSTALLED ON, SEE FOOTNOTE 33
999
STEERING INTERMEDIATE ARM , 016 FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 21, 018 FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 22, 019 FR OM CHASSIS 029326
999
CLAMP FORKED SUPPORT,TOP
999
STEERG. WORM SECTOR SHAFT , WITH L.H.D,ON MODELS 111.024,025 FROM STEERING 198396 WITH R.H.D,ON MODELS 111.024,025 FROM STEERING 199281
999
STEERING BOX
999
STEERING BOX ASSEMBLY
999
LINE , 057,058 FROM CHASSIS003422 ALSO INSTALLED ON 003407,003409-003412,003416,003418-003420
999
SCREW , WITH L.H.D.,ON MODEL 113.044 FROM STEERING014191 WITH R.H.D.,ON MODEL 113.044 FROM STEERING014401
999
NUT , WITH L.H.D,ON MODELS 111.024,025 FROM STEERING 198396 WITH R.H.D,ON MODELS 111.024,025 FROM STEERING 199281
999
NUT , WITH L.H.D,ON MODELS 111.024,025 FROM STEERING 198396 WITH R.H.D,ON MODELS 111.024,025 FROM STEERING 199281
999
HOSE
999
DRAG LINK
999
RUBBER RING
999
WASHER
999
SPACER WASHER , Replaced By: A1244630077
999
DUST CAP
999
PISTON , WITH L.H.D.,FROM STEERING 003126
999
SEAL RING
999
GASKET
999
THRUST WASHER 1,1 MM, AS REQUIRED
999
THRUST WASHER 1,2 MM, AS REQUIRED
999
THRUST WASHER 1,3 MM, AS REQUIRED
999
THRUST WASHER 1,4 MM, AS REQUIRED
999
THRUST WASHER 1,6 MM, AS REQUIRED
999
THRUST WASHER 1,7 MM, AS REQUIRED
999
THRUST WASHER 1,8 MM, AS REQUIRED
999
THRUST WASHER 1,9 MM, AS REQUIRED
999
THRUST WASHER 2,0 MM, TO BE ADAPTED DURING ASSEMBLY
999
CLAMPING PIECE
999
INSULATING PART , UP TO CHASSIS 019587 STEERING WHEEL: BLACK UP TO CHASSIS 019541 STEERING WHEEL: WHITE
999
SIGNAL RING , UP TO CHASSIS: 073 002526, WHITE STEERING WHEEL 073 002631, BLACK STEERING WHEEL
999
STEERING WHEEL , FROM CHASSIS: 073 002632
999
STEERING LOCK , 023 009623 024 007307 043 011383 WITH CENTRAL LOCKING MECHANISM UP TO CHASSIS: 022 005192 023 012497 024 021807 026 000025 042 004216 043 013577 044 047075 LESS CENTRAL LOCKING MECHANISM UP TO CHASSIS: 022 005267 023 012544 024 022006 026 000061 042 004280 043 013577 044 047451 IN PLACE OF 116 462 02 79 WITH LOCK DEFINED WITH KEY BITTING HD,USE 116 462 01 79, AND WITH KEY BITTING HA,USE 116 460 06 04, Replaced By: A1164620830, +001A1164620023, +001A1164620279, +001A1236890056, +001A1236890080
999
TUMBLER WITHOUT LOCK UNDEFINED, FOR MASTER KEY,SEE GROUP 72 FROM CHASSIS: 115.000,002,010 099406 115.015 123862 115.100,102,103,110,112 259276 115.115 130163 115.005,017,105,107,108,117,119 000001 UP TO CHASSIS: 000,002,010UNTIL PRODUCTION STOP 005,017 016519 015 223255 UP TO CHASSIS: 100,102,103,112UNTIL PRODUCTION STOP 110 421345 105,107,108,117 032884 115 228860 119 034132
999
STEERING LOCK , Replaced By: A1164621030
999
STEERING LOCK
999
BUSHING ,F 189738
999
PROTECTIVE RING
999
PROTECTIVE RING , Replaced By: A6019900540
999
SCREW
999
WASHER
999
SPRING
999
SPRING
999
NUT
999
REPAIR KIT , Replaced By: A1264600819
999
WASHER
999
INTERMEDIATE LEVER REPAIR KIT
999
WASHER
999
SCREW SWITCH TO STEERING LOCK
999
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
999
COTTER PIN DRAG LINK TO LEVER
999
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
SPRING WASHER STEERING COLUMN BRACKET TO CAB
999
NUT , WITH L.H.D,ON MODELS 111.024,025 FROM STEERING 198396 WITH R.H.D,ON MODELS 111.024,025 FROM STEERING 199281
999
SCREW
999
SCREW
999
SCREW COVER PLATE TO BRACKET
999
NUT CYLINDER TO BRACKET TO0002902112
999
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
999
SCREW , TO 115 460 15 05,115 460 16 05 DRAG LINKS
999
SCREW SHOCK ABSORBER TO TOP BRACKET
999
SEAL RING LINE CONNECTION
999
SCREW PLUG 4/2-WAY VALVE
999
SCREW PLUG AIR DEHYDRATOR
999
SHEET METAL SCREW BRACKET TO CAB FLOOR, EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 5 180559
999
HOSE HAND BRAKE VALVE BLEEDING, ORDER BY THE METER
999
SCREW PUMP TO BRACKET
999
NUT BATTERY MOUNTING
999
NUT COMBINATION CYLINDER TO BEARING BRACKET
999
LOCK PROTECTIVE PLATE AND SCREENING PLATE TO BRACKET
999
LOCK , UP TO CHASSIS: 005,007,008,015,017 207357 011 101648 060 102313 062 101808
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
999
COMBINATION BOLT CABLE TO FUSE BOX
999
CLAMP , Replaced By: N000000000667
