Поз.
Артикул
Описание
1
ROOF PANELLING
1
ROOF PANELLING , Replaced By: A1106500570, +001A1106700639, +004A1159971040, +004N000084004137, +004N009021004103
1
ROOF PANELLING , Replaced By: A1106500570
2
FRAME , UP TO CHASSIS: 111.010 001747 111.012 003397 111.014 000712, Replaced By: A1107800529, +001A1107820726, +001A1107820826, +001A1107821498, +001A1157820098
2
FRAME , FROM CHASSIS:111.010 001748-005225111.012 003398-011661111.014 000713-002879, Replaced By: A1107800529, +001A1107821498, +001A1157820098
2
FRAME
3
RUBBER BUFFER TO PLUG THE MOUNTING HOLE USED FOR GROUND CONNECTION IN CASE OF R.H.D.
4
CARPET *** 2 MM, ORDER BY THE METER
4
PAD , Replaced By: A0009833087
4
PAD , Replaced By: A0009833087
8
SEAL , Replaced By: A1157820098
8
SEAL
9
HOSE
10
GROMMET
12
PAD FRAME PART,CENTRAL 860 MM
12
RUBBER PAD , Replaced By: A1107841597
50
COVER RAIL , Replaced By: A1107820113
50
COVER RAIL
51
SLIDING RAIL FRONT LEFT
51
SLIDING RAIL , Replaced By: A1107820726
52
SLIDING RAIL RIGHT
55
FILLER , FROM CHASSIS:110.010 022627 110.110 031398 111.010 036514 111.012 078363 111.014 031345 112.014,015 001250
60
PAD
61
HEADLINER WITH FRAME, STATE COLOR CODE NO.WHEN ORDERING
62
PANELLING LESS BOWS
62
PANELLING , Replaced By: A1116900352
63
FRAME , STATE COLOR NUMBER WHEN ORDERING
64
RUBBER SEAL , Replaced By: A0019876052
64
RUBBER SEAL LEATHER & IMITATION LEATHER 837 MM
65
BOW
66
BOW
999
FOAM PLASTICS , Replaced By: A0009833598
999
FOAM PLASTICS , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0009831298
999
FOAM PLASTICS , Replaced By: A0009831298
999
FOAM PLASTICS ROOF INTERIOR COVERING,7X80X100, ORDER BY THE METER
999
FOAM PLASTICS 10 MM, ORDER BY THE METER
999
FELT WAFFLE-FACED FELT-,FOR FRONT FLOOR,TOP550 X 560 X 10 MM, ORDER BY THE METER 10/50,12/52,000,001,004,010 UP TO CHASSIS 099714,10/50,12/52,100,101,104,110 UP TO CHASSIS 210863,AND FOOTNOTE 4
999
FOAM PLASTICS FRONT ROOF RAIL
999
FELT , Replaced By: A0009830198
999
RUBBER SEAL , FROM CHASSIS:110.010 155808 110.011 013995 110.110 274548 111.010 088651 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0039895485
999
RUBBER SEAL , Replaced By: A0019876052
999
WASHER , 010 UP TO CHASSIS 086235,110 UP TO CHASSIS 137067
999
HOSE , Replaced By: A0009978482
999
CLIP DOOR OUTSIDE
999
CLIP , Replaced By: A0019881778
999
ADHESIVE TAPE (SEAL),BETWEEN OUTSIDE REAR PILLAR AND ROOF 560 MM, ORDER BY THE METER
999
HOSEWASSERABLAUF HINTEN 250 MM
999
SCREW , Replaced By: A1409900436
999
INSULATION , Replaced By: A0009831298
999
INSULATION BETWEEN REINFORCEMENT AND ROOF PANELLING 40X520X10 MM, ORDER BY THE METER
999
INSULATION , Replaced By: A1106820251
999
INSULATION , Replaced By: A0009831298
999
SEAL , UP TO CHASSIS: 111.010 005225 111.012 011661 111.014 002879
999
FRAME ROOF, 010 UP TO CHASSIS 066415,110 UP TO CHASSIS 103373 STATE COLOR CODE NO.WHEN ORDERING
999
CONNECTION , Replaced By: A1107820524
999
MOUNTING RAIL , Replaced By: A1107820524
999
ROD RIGHT
999
SLIDING JAW
999
SPRING , Replaced By: A1107820135
999
SPRING LEFT, UP TO CHASSIS: 111.010 001747 111.012 003397 111.014 000712
999
PLATE RIGHT
999
SLIDING RAIL , Replaced By: A1107820826
999
SPRING RIGHT, UP TO CHASSIS: 111.010 001747 111.012 003397 111.014 000712
999
RAIL LEFT
999
SEAL , FROM CHASSIS:110.010 155808 110.110 274548 111.010 088651, Replaced By: A0039895485
999
SLIDING RAIL FRONT RIGHT
999
SLIDING RAIL LEFT
999
PIN , 010 UP TO CHASSIS 086235,110 UP TO CHASSIS 137067
999
RUBBER BUFFER , Replaced By: A1109870539
999
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1159870240
999
PANELLING LESS BOWS
999
FRAME , Replaced By: A1107800209
999
FRAME , STATE COLOR NUMBER WHEN ORDERING
999
PANELLING , Replaced By: A1126900752
999
PANELLING LESS BOWS
999
FRAME
999
SCREW
999
SCREW FUSE BOX TO SIDE MEMBER,5 097182
999
SCREWR & S, M 4X8
999
WASHER
999
SCREW SHUT-OFF VALVE TO BRACKET
999
SCREW
999
SCREW COVER PLATE TO BRACKET
999
SCREW COVER PLATE TO BRACKET
999
CLAMPING SLEEVE
999
CLAMPING SLEEVE
999
TOOTHED WASHER COVER TO COVERING,K 093739
999
TOOTHED WASHER , 123.020 082784 123.023 100522 123.026 050534 123.120 116041 123.123 080963 123.126 045537 123.130 101733
999
TOOTHED WASHER MASKED STOP LAMP
999
SHEET METAL SCREW
999
SHEET METAL SCREW
999
SCREW ELECTRIC CABLE TO HORN
999
SCREW , Replaced By: N000000001933
999
SCREW , UP TO CHASSIS: 111.010 001747 111.012 003397 111.014 000712
999
SCREW
999
SCREW
999
WASHER , Replaced By: N009021006208
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
SCREW
999
CLAMP CABLE HARNESS MOUNTING 22 MM
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
