Поз.
Артикул
Описание
6
REAR SEAT CUSHION FABRIC, 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648
12
CUSHION FRAME WITH SPRING CORE
12
CUSHION FRAME , Replaced By: A1089200322
18
PAD , 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648
26
COVER FABRIC, 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648
31
BRACKET REAR SEAT CUSHION TO FLOOR, 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648 010 UP TO CHASSIS 162208, 011 UP TO CHASSIS 017208, 110 UP TO CHASSIS 289679
36
BACKREST WITH FOLDING ARMREST, FABRIC, 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648 SPECIAL VERSION
46
BACKREST FRAME FOLDING ARMREST, 010 UP TO CHASSIS 154561, 011 UP TO CHASSIS 013336, 110 UP TO CHASSIS 271740
53
PAD , 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648
59
COVER , Replaced By: A1109203047
64
FOLDING ARMREST FABRIC, 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648 010 UP TO CHASSIS 154561, 011 UP TO CHASSIS 013336, 110 UP TO CHASSIS 271740
69
COVER FABRIC, 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648 010 UP TO CHASSIS 154561, 011 UP TO CHASSIS 013336, 110 UP TO CHASSIS 271740
78
ARMREST , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1109700701
86
SAFETY BELT , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1158600785
93
SAFETY BELT
99
CAP
106
SCREW , Replaced By: A0009840833
111
SCREW
116
SPACER RING
121
WASHER
126
BRACKET , UP TO CHASSIS: 108.014,015 UNTIL PRODUCTION STOP 108.012 073175 108.016 013806, ALSO INSTALLED ON: 013884 108.018 012469, ALSO INSTALLED ON: 013006 108.019 012301 109.015 UNTIL PRODUCTION STOP 109.016 000814 109.018 000142 HAS NOT BEEN USED ON MODEL 109.015
131
CLAMP , UP TO CHASSIS: 108.012 073232 108.016 013952 108.018,019 012816 109.016 000842 UP TO CHASSIS: 109.018 000159 108.014,015 UNTIL PRODUCTION STOP 109.015 UNTIL PRODUCTION STOP
136
CLAMP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0008680432
999
SCREW LICENSE PLATE TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021006208
999
SCREW
999
LOCK PLATE
999
NUT BALL PIVOT TO LEVER
999
SCREW
999
SCREW , Replaced By: N304017006020
999
WASHER BRACKET TO HEAT SHIELD
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
ARMREST , 010 UP TO CHASSIS 188187 EXCEPT FOR, SEE FOOTNOTE 29, 011 UP TO CHASSIS 032040 EXCEPT FOR, SEE FOOTNOTE 30, 110 UP TO CHASSIS 352302 EXCEPT FOR, SEE FOOTNOTE 31 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1109700801
999
ARMREST , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1109700701
999
FOLDING ARMREST IMITATION LEATHER, 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648 010 UP TO CHASSIS 154561, 011 UP TO CHASSIS 013336, 110 UP TO CHASSIS 271740
999
COVER FABRIC, 010 FROM CHASSIS 154562, 011 FROM CHASSIS 013335, 110 FROM CHASSIS 271741
999
FOLDING ARMREST FABRIC, 010 UP TO CHASSIS 068345, 110 UP TO CHASSIS 105977 FROM CHASSIS 013335
999
FOLDING ARMREST , Replaced By: A1119703830
999
FOLDING ARMREST , STATE COLOR NUMBER WHEN ORDERING UP TO CHASSIS: 111.010 087905 110.011 013335
999
FOLDING ARMREST LEATHER, 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648 010 UP TO CHASSIS 154561, 011 UP TO CHASSIS 013336, 110 UP TO CHASSIS 271740
999
COVER LEATHER, 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648 010 UP TO CHASSIS 154561, 011 UP TO CHASSIS 013336, 110 UP TO CHASSIS 271740
999
COVER , 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648 010 UP TO CHASSIS 154561, 011 UP TO CHASSIS 013336, 110 UP TO CHASSIS 271740
999
ARMREST RIGHT
999
ARMREST LEFT
999
PAD , Replaced By: A1109240816
999
PAD , STATE COLOR NUMBER WHEN ORDERING
999
PAD , Replaced By: A1089240514
999
PAD
999
COVER , STATE COLOR NUMBER WHEN ORDERING
999
BACKREST WITH FOLDING ARMREST,IMITATION LEATHER, 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648
999
COVER FOLDING ARMREST, 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648 FOR VEHICLES HAVING FOLDING ARMREST
999
BACKREST WITH FOLDING ARMREST, LEATHER, 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648
999
REAR SEAT CUSHION , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1109203220
999
COVER , STATE COLOR NUMBER WHEN ORDERING
999
BACKREST , Replaced By: A1109203030
999
REAR SEAT CUSHION , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1109203320
999
BACKREST , Replaced By: A1109203130
999
BACKREST , Replaced By: A1109202930
999
COVER , STATE COLOR NUMBER WHEN ORDERING
999
COVER IMITATION LEATHER, FULL-FLUTED, 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648 FOR VEHICLES HAVING FOLDING ARMREST
999
BACKREST LESS COVER .
999
BACKREST LESS COVER , Replaced By: A1109201004
999
BACKREST LESS COVER COMPLETE,BUT LESS COVER, FROM CHASSIS:110.010 130558 110.110 225648
999
BACKREST FRAME FOLDING ARMREST, 010 FROM CHASSIS 154562, 011 FROM CHASSIS 013335, 110 FROM CHASSIS 271741
999
SEAT CUSHION LESS COVER .
999
BACKREST LESS COVER , Replaced By: A1109200804
999
SEAT CUSHION LESS COVER LEATHER, 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648
999
SEAT CUSHION LESS COVER FABRIC
999
PAD , STATE COLOR NUMBER WHEN ORDERING
999
PAD , Replaced By: A1089240614
999
BRACKET REAR SEAT CUSHION TO FLOOR, 010 FROM CHASSIS 162209, 011 FROM CHASSIS 017209, 110 FROM CHASSIS 289680
999
NUT RETAINER , Replaced By: A0009907191
999
NUT RETAINER , Replaced By: A3229900091
999
NUT RETAINER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0009908391
999
WASHER
999
EDGE GUARD SECTION 895 MM ORDER BY THE METER
999
RUBBER RING SIGNAL LAMP TO ROOF
999
RUBBER RING , Replaced By: A0009873841
999
CLIP COVER TO PAD
999
SCREW
999
SCREW , UP TO CHASSIS: 108.014,015 UNTIL PRODUCTION STOP 108.012 073175 108.016 013806, ALSO INSTALLED ON: 013884 108.018 012469, ALSO INSTALLED ON: 013006 108.019 012301 109.015 UNTIL PRODUCTION STOP 109.016 000814 109.018 000142
999
SCREW , Replaced By: A0009841033
999
CLAMP
999
CLAMP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0008680632
999
SPRING , UP TO CHASSIS: 111.024 001495 111.025 001772
