Поз.
Артикул
Описание
6
DOOR SHELL RIGHT
9
DOOR CHECK , Replaced By: A1107301016
14
CAP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1107230824
17
BUFFER
23
DOOR LOCK RIGHT
27
EDGING , Replaced By: A1087230224
31
PULL ROD
35
MOLDED PIECE , Replaced By: A0029888378
39
LOCK PULL ROD TO DOOR LOCK
43
DOOR LOCKING DEVICE , Replaced By: A1107300493
47
SPRING WASHER SHIFTING CYLINDER TO YOKE
52
SPACER RING
56
LOCKING EYE RIGHT
61
PLATE 2.0 MM 2.0 MM, TO BE ADAPTED DURING ASSEMBLY
61
PLATE , Replaced By: A1007230211
65
INTERIOR HANDLE ASSEMBLY RIGHT, 000,001,004,010 FROM CHASSIS 130558-188149,100,101,104,110 FROM CHASSIS 225648-352118,002,003,005,011 UP TO CHASSIS 031989
70
ESCUTCHEON RIGHT, 000,001,004,010 FROM CHASSIS 130558-188149,100,101,104,110 FROM CHASSIS 225648-352118,002,003,005,011 UP TO CHASSIS 031989
76
INSERT , 000,001,004,010 FROM CHASSIS 130558-188149,100,101,104,110 FROM CHASSIS 225648-352118,002,003,005,011 UP TO CHASSIS 031989
81
KNOB , 023 116973 033 048510 123 097280 130 120563
86
DOOR HANDLE OUTSIDE RIGHT
91
PIN
95
PAD
99
PAD
99
PAD , Replaced By: A1207660005
103
SCREW
108
DISC SPRING
112
PIN DOOR CHECK
117
LOCK , Replaced By: N912001005000
121
GLASS PANE
126
SEAL RIGHT
131
CLIP , 010 UP TO CHASSIS 174260,110 UP TO CHASSIS 318289,011 UP TO CHASSIS 023499
135
WINDOW STAYBAR RIGHT
140
WINDOW RUN ON SIDE OF LOCK,RIGHT
145
SEALING SECTION 2040 MM, ORDER BY THE METER
151
CLIP
155
CAP , 000,001,004,010 FROM CHASSIS 125855-158417,100,101,104,110 FROM CHASSIS 213806-280560,002,003,005,011 UP TO CHASSIS 015311
159
WINDOW REGULATOR RIGHT
163
SPRING , Replaced By: A0007680905
163
SPRING , Replaced By: A0007680734
163
SPRING
167
WINDOW REGULATOR RAIL RIGHT
171
SLIDE , Replaced By: A1155860072
176
WASHER , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
181
WASHER , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
186
GLASS PANE CRANK OPERATED WINDOW
191
RETAINING RAIL
196
RUBBER MOULDING 290 MM, 100001
205
CRANK , 000,001,004,010 UP TO CHASSIS 188465,100,101,104,110 UP TO CHASSIS 352550,002,003,005,011 UP TO CHASSIS 032300 EXCEPT FOR SEE FOOTN.25
209
PAD , Replaced By: A1087680095
214
WASHER
214
WASHER , Replaced By: A1087680113
216
SEALING SECTION , Replaced By: A1157250965
221
CLIP DOOR OUTSIDE
227
CLIP , 008309
231
PANELLING BOTTOM RIGHT, 000,001,004,010 BROWN AND GREY FINISH FROM CHASSIS 023787,BLUE FINISH FROM CHASSIS 025263 ALSO INSTALLED ON,SEE FOOTNOTE 024,A ND FOOTNOTE 027
235
CLIP
235
CLIP , Replaced By: A0029884578
238
ESCUTCHEON , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1087250070
241
INSULATION , Replaced By: A2106820008
241
INSULATION , Replaced By: A1237270090
241
INSULATION , Replaced By: A1107270390
241
INSULATION
241
INSULATION
246
WEATHERSTRIP RIGHT
250
CLIP SEAL TO REAR DOOR
256
EDGE GUARD SECTION RIGHT REAR DOOR
261
COVERING , Replaced By: A1107370288
266
SEAL , Replaced By: A1107370631
271
PANELLING RIGHT REAR DOOR
276
GARNISH MOULDING LEATHER & IMITATION LEATHER, 000,001,004,010 FROM CHASSIS 130558,100,101,104,110 FROM CHASSIS 225648
281
RAIL
281
RAIL , Replaced By: A1107370072
286
GARNISH MOULDING FRONT RIGHT,FOR WINDOW FRAME
292
SEAL
296
GARNISH MOULDING TOP RIGHT WINDOW FRAMES
303
GARNISH MOULDING REAR RIGHT,WINDOW FRAME
309
GARNISH MOULDING RIGHT
316
SCREW
321
FASTENER BUTTON
321
FASTENER BUTTON. GROMMET , Replaced By: A0019882081
321
FASTENER BUTTON , Replaced By: A0089970381
321
GROMMET , Replaced By: A0019882081
326
FASTENER BUTTON UPPER PART
331
GROMMET , 000,001,004,010 FROM CHASSIS 098313,100,101,104,110 FROM CHASSIS 160718
336
GARNISH MOULDING TOP RIGHT, 010 FROM CHASSIS 057853,012 FROM CHASSIS 126588
341
PLASTIC PAD , 000,001,004,010 FROM CHASSIS 130558,100,101,104,110 FROM CHASSIS 225648
346
PLASTIC PAD TOP GARNISH MOULDING TO LOCK SIDE, 010 FROM CHASSIS 057853,012 FROM CHASSIS 126588
999
WASHER CLEARANCE LAMP ON BRACKET
999
WASHER , FROM CHASSIS: 034089, ALSO INSTALLED ON: 033673,033706,033709,033716,033736,033765,033914,033922,033926,033930,033931,033934,033936,033938, 033939,033941-033951,033953,033955,033956,033959,033960,033962,033964,033966,033967,033969-033998, 034000-034010,034012-034022,034024-034087. 050734
999
WASHER
999
GROMMET , Replaced By: A0009881427
999
GROMMET
999
ADHESIVE TAPE , Replaced By: A0019875646
999
CLEANER
999
SCREW
999
NUT RETAINER
999
NUT RETAINER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0009908391
999
NUT RETAINER , Replaced By: A3229900091
999
NUT RETAINER , Replaced By: A0009907191
999
LOCK , Replaced By: A1155860072
999
LOCK. WASHER ELECTRIC MOTOR TO BRACKET
999
LOCK LEATHER & IMITATION LEATHER
999
LOCK. SHEET METAL NUT PLATE TO FRAME,V 202043
999
SEALING CORD PAINT RUN-OFF HOLE IN REAR WINDOW OPENING, ORDER BY THE METER
999
CLIP , Replaced By: A0029884578
999
CLIP , Replaced By: A0069886378
999
ADHESIVE TAPE , Replaced By: A0019875646
999
CLIP
999
EDGING
999
EDGING RIGHT
999
ESCUTCHEON
999
SEAL , Replaced By: A1157251298
999
CRANK , 000,001,004,010 FROM CHASSIS 188466,100,101,104,110 FROM CHASSIS 352551,002,003,005,011 FROM CHASSIS 032301 ALSO INSTALLED ON SEE FOOTN.25, Replaced By: A1237600102, +001A1237600020
999
INTERIOR HANDLE ASSEMBLY LEFT, 000,001,004,010 FROM CHASSIS 188150,100,101,104,110 FROM CHASSIS 352119,002,003,005,011 FROM CHASSIS 031990
999
INTERIOR HANDLE ASSEMBLY RIGHT
999
INSERT LEFT
999
INSERT RIGHT
999
ESCUTCHEON LEFT
999
ESCUTCHEON RIGHT
999
LOCKING EYE LEFT
999
PLATE 2.6 MM
999
EDGING , Replaced By: A1087230124
999
EDGING
999
WINDOW REGULATOR RAIL LEFT
999
GARNISH MOULDING FRONT LEFT,FOR WINDOW FRAME
999
PULL ROD LEFT, ON SPECIAL REQUEST,PULL ROD WITH ADDITIONAL LOCKING MECHANISM
999
DOOR LOCKING DEVICE , Replaced By: A1107300393
999
EDGE GUARD SECTION LEFT REAR DOOR
999
PULL ROD RIGHT REAR DOOR
999
WINDOW STAYBAR LEFT
999
DOOR LOCKING DEVICE LEFT
999
DOOR LOCKING DEVICE RIGHT
999
WINDOW RUN ON SIDE OF LOCK,LEFT
999
DOOR CHECK , Replaced By: A1107301016
999
WEATHERSTRIP LEFT
999
DOOR CHECK
999
DOOR LOCK LEFT
999
DOOR SHELL LEFT
999
PANELLING RIGHT REAR DOOR
999
PANELLING LEFT, 000,001,004,010 FROM CHASSIS 130558,100,101,104,110 FROM CHASSIS 225648 WHEN ORDERING,STATE COLOR CODE NO.AND CHASSIS NO. ON SPECIAL REQUEST,LEATHER TRIM
999
PANELLING RIGHT, 000,001,004,010 FROM CHASSIS 130558,100,101,104,110 FROM CHASSIS 225648 WHEN ORDERING,STATE COLOR CODE NO.AND CHASSIS NO. ON SPECIAL REQUEST,LEATHER TRIM
999
PANELLING LEFT, 000,001,004,010 FROM CHASSIS 188150,100,101,104,110 FROM CHASSIS 352119,002,003,005,011 FROM CHASSIS 031990 WHEN ORDERING,STATE COLOR CODE NO.AND CHASSIS NO.
999
PANELLING RIGHT, 000,001,004,010 FROM CHASSIS 188150,100,101,104,110 FROM CHASSIS 352119,002,003,005,011 FROM CHASSIS 031990 WHEN ORDERING,STATE COLOR CODE NO.AND CHASSIS NO.
999
WINDOW REGULATOR LEFT
999
SEAL LEFT
999
GLASS PANE REAR DOOR CRANK OPERATED WINDOW
999
GLASS PANE FIXED REAR DOOR
999
SEAL , Replaced By: A1107370531
999
COVERING REAR END PILLAR,TOP
999
SEAL LEFT,CENTRAL PILLAR
999
SEAL RIGHT,CENTRAL PILLAR
999
GARNISH MOULDING LEFT
999
GARNISH MOULDING TOP LEFT WINDOW FRAME
999
GARNISH MOULDING REAR LEFT,WINDOW FRAME
999
INTERIOR HANDLE ASSEMBLY LEFT FRONT DOOR, 000,001,004,010 FROM CHASSIS 130558-188149,100,101,104,110 FROM CHASSIS 225648-352118,002,003,005,011 UP TO CHASSIS 031989
999
ESCUTCHEON LEFT, 000,001,004,010 FROM CHASSIS 130558-188149,100,101,104,110 FROM CHASSIS 225648-352118,002,003,005,011 UP TO CHASSIS 031989
999
PANELLING , 000,001,004,010 BROWN AND GREY FINISH FROM CHASSIS 023787,BLUE FINISH FROM CHASSIS 025263 ALSO INSTALLED ON,SEE FOOTNOTE 024,A ND FOOTNOTE 027
999
GARNISH MOULDING TOP LEFT, 010 FROM CHASSIS 057853,012 FROM CHASSIS 126588
999
REPAIR KIT , Replaced By: A1237200114
999
SEALING RAIL 2200 MM
999
SEAL , Replaced By: A1167250198
999
SEAL , FROM CHASSIS: 010 076074 110 193042 017,117 000001
999
MOLDED PIECE , Replaced By: A0029888378
999
SEAL INSIDE 4000 MM
999
REPAIR KIT
999
CRANK
999
SCREW
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
SCREW
999
SCREW COVER PLATE TO BRACKET
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
NUT BALL PIVOT TO LEVER
999
SCREW INTERMEDIATE BEARING TO CAB FLOOR
999
SCREW
999
TOOTHED WASHER CABLE TO FUSE BOX
999
TOOTHED WASHER MASKED STOP LAMP
999
SHEET METAL SCREW , Replaced By: N000000002062
999
SHEET METAL SCREW ANTENNA CABLE TO REAR INSIDE PILLAR
999
SHEET METAL SCREW
999
SCREW
999
SCREW ,K 062140, Replaced By: N007985006580
999
SCREW APPARATUS PLATE TO CAB,K 062140
999
SCREW
999
SCREW , 000,001,004,010 UP TO CHASSIS 123344,100,101,104,110 UP TO CHASSIS 204483
999
SCREW
999
SCREW
999
SCREW
999
SCREW
999
WASHER , Replaced By: N009021004207
999
WASHER COVERING TO CYCLONE AIR TRAP
999
WASHER , Replaced By: N009021006208
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
SCREW PUMP TO BRACKET
999
LOCK DOOR CHECK TO FRONT PANEL PILLAR
999
LOCK , Replaced By: A1155860072
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
