Поз.
Артикул
Описание
78
REAR AXLE TUBE LEFT
80
REAR AXLE TUBE RIGHT
82
BUSHING
84
VALVE
87
JOINT
90
SPACER WASHER
91
LOCK
93
JOINT , ON TYPE 200 UP TO CHASSIS 146361, ON TYPE 200 D UP TO CHASSIS 254145, ON TYPE 230 UP TO CHASSIS 007969
95
LOCK RING SHACKLE TO BEARING BRACKET,965965
97
ROLLERTO 387 460 14 09
99
SPACER WASHER
101
LOCK RING AS REQUIRED 1.75 MM
103
UNIVERSAL JOINT , 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640, Replaced By: A1123500128, +001A1109970032
107
SNAP RING 2.15 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
110
SCREW PLUG
112
LOCK WASHER COMPRESSED AIR LINE TO BRACKET
114
SPACER WASHER 1.0 MM
119
BOOT
121
BOOT SPLIT
123
CLIPTO 343 357 00 22
126
REAR AXLE SHAFT LEFT, 000,001,100,101 FROM REAR AXLE, 010 FROM REAR AXLE 169909, 110 FROM REAR AXLE 165459
127
REAR AXLE SHAFT RIGHT, 000,001,010 UP TO CHASSIS 064105, 100,101,110 UP TO CHASSIS 099641,0N SPECIAL REQUEST,FOR 186 400 17 02 15-IN. DISC WHEELS LES S MID-CENTERING
129
CYLINDR. ROLLER BEARING ,10/20879179, 50/60880935, Replaced By: A0029819001
129
BALL BEARING , Replaced By: A0029812301
131
LOCK
133
GROOVED NUT
135
SCREW BRACKET TO SIDE MEMBER
137
SCREW , Replaced By: N304017008021
137
SCREW PIPE CLAMP
140
BRAKE DRUM
142
PIN , 000,001,100,101 FROM REAR AXLE 000287, 010 FROM REAR AXLE 129303, 110 FROM REAR AXLE 087840
145
SPACER TUBE
148
SPACER WASHER 2.0 MM
149
SPACER WASHER 2.0 MM
149
SPACER WASHER , Replaced By: A1803511452
156
SPACER RING
159
RUBBER RING
161
PIN
162
LOCK WASHER
164
NUT
164
NUT , Replaced By: N304032008006
166
LOCK
168
WASHER IN CONNECTING PIN
171
SCREW PLUG
172
LOCK
173
GREASE NIPPLE LOCK ANGLE SENSOR
175
GREASE NIPPLE
177
RUBBER MOUNTING , 000,001,100,101 FROM REAR AXLE 000287, 010 FROM REAR AXLE 129303, 110 FROM REAR AXLE 087840
179
SUPPORT
181
GROOVED PIN
183
SCREW
185
LOCK WASHER COMPRESSED AIR LINE TO BRACKET
187
THRUST ARM LEFT
189
RUBBER MOUNTING
191
PIVOT PIN
193
WASHER
195
SNAP RING
197
SPACER RING
199
SCREW
200
LOCK
202
RUBBER MOUNTING REAR SUBFRAME MOUNTING
204
THRUST WASHER REAR SUBFRAME MOUNTING
206
SCREW PISTON ON TRAILING AXLE
208
LOCK WASHER
211
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
213
LOCK WASHER COMPRESSED AIR LINE TO BRACKET
215
ROD
217
NUT BRACKET TO SIDE MEMBER,K 035196
217
NUT , Replaced By: N308673014001
219
BRACKET
221
RUBBER MOUNTING
223
BRACKET
225
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
225
SCREW , Replaced By: N304017010028
227
SPRING WASHER STEERING COLUMN BRACKET TO CAB
229
SCREW
231
SPRING WASHER CAB FLOOR
231
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
233
CUP
235
RUBBER BUFFER
238
CUP
240
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
240
NUT , Replaced By: N308673012002
242
NUT
244
RUBBER MOUNTING
246
MOUNTING PLATE
248
WASHER PROTECTIVE PLATE TO BRACKET,5 502998
251
LOCK WASHER TAIL LAMP TO BRACKET
253
NUT
253
NUT , Replaced By: N304032008006
255
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
257
NUT BRACKET TO SIDE MEMBER,K 035196
257
NUT , Replaced By: N308673014001
999
MOLDED PIECE , ONLY FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
999
REPAIR KIT
999
BRACKET LEFT
999
BRACKET RIGHT
999
AXLE HOUSING , 010 UP TO REAR AXLE 009905,012 UP TO REAR AXLE 026069, Replaced By: A1103500220, +001A1103530208, +006N000127008200, +006N070614008002
999
REAR AXLE , Replaced By: A1103500203
999
JOINT , Replaced By: A1103500413, +001A1109970032
999
AXLE HOUSING , 000,001,010 UP TO CHASSIS 016331, 100,101,110 UP TO CHASSIS 022883, Replaced By: A1103500220, +001A1103530208
999
AXLE HOUSING , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
JOINT , Replaced By: A1103500413, +001A1109970032
999
AXLE SHAFT , 000,001,100,101 UP TO REAR AXLE 000961, 010 UP TO REAR AXLE 169908, 110 UP TO REAR AXLE 165458, Replaced By: A1103571101, +001A1103571201, +001A2014010270
999
AXLE SHAFT , 000,001,100,101 UP TO REAR AXLE 000961, 010 UP TO REAR AXLE 169908, 110 UP TO REAR AXLE 165458, Replaced By: A1103571201, +001A1103571101, +001A2014010270
999
AXLE SHAFT , Replaced By: A1103571101, +005A2014010270
999
AXLE SHAFT , Replaced By: A1103571201, +005A2014010270
999
REAR AXLE , 010 UP TO CHASSIS 064105 EXCEPT FOR, SEE FOOTN.2
999
THRUST ARM RIGHT
999
REPAIR KIT
999
PAD BOTTOM SUPPORT TO FRAME FLOOR UNIT, 010 UP TO CHASSIS 010239,012 UP TO CHASSIS 020877
999
RETAINER THRUST ARM TO FRAME FLOOR UNIT, 010 UP TO CHASSIS 018282,012 UP TO CHASSIS 008703
999
COVER , 010 UP TO REAR AXLE 009905,012 UP TO REAR AXLE 026069
999
COVER , 000,001,100,101 UP TO REAR AXLE 000286, 010 UP TO REAR AXLE 129302, 110 UP TO REAR AXLE 087839
999
REAR AXLE SHAFT RIGHT, 000,001,100,101 FROM REAR AXLE 002173, 010 FROM REAR AXLE 216044, 110 FROM REAR AXLE 252542
999
JOINT , Replaced By: A1103500413, +001A1109970032
999
UNIVERSAL JOINT , 000,001,100,101 UP TO REAR AXLE 001286, 010 UP TO REAR AXLE 190027, 110 UP TO REAR AXLE 201639
999
REPAIR KIT
999
RUBBER MOUNTING , 000,001,100,101 UP TO REAR AXLE 000286, 010 UP TO REAR AXLE 129302, 110 UP TO REAR AXLE 087839
999
RING GEAR AND PINION WITH RING GEAR FOR SPECIAL PURPOSES RATIO 1:4.56
999
REAR AXLE , Replaced By: A1103500203
999
SCREW
999
UNIVERSAL JOINT , 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
999
RUBBER MOUNTING
999
PAD
999
THRUST WASHER 1.7 MM
999
THRUST WASHER AS REQUIRED 1.6 MM
999
THRUST WASHER AS REQUIRED 1,5 MM
999
THRUST WASHER AS REQUIRED 1,4 MM
999
WHEEL MOUNTING BOLT
999
SNAP RING 2.25 MM, 000,001,100,101 UP TO REAR AXLE 001286, 010 UP TO REAR AXLE 190027, 110 UP TO REAR AXLE 201639
999
SNAP RING 2.35 MM, 000,001,100,101 UP TO REAR AXLE 001286, 010 UP TO REAR AXLE 190027, 110 UP TO REAR AXLE 201639
999
SNAP RING 2.40 MM, 000,001,100,101 UP TO REAR AXLE 001286, 010 UP TO REAR AXLE 190027, 110 UP TO REAR AXLE 201639
999
SNAP RING 2.45 MM, 000,001,100,101 UP TO REAR AXLE 001286, 010 UP TO REAR AXLE 190027, 110 UP TO REAR AXLE 201639
999
SNAP RING 2.55 MM, 000,001,100,101 UP TO REAR AXLE 001286, 010 UP TO REAR AXLE 190027, 110 UP TO REAR AXLE 201639
999
SPACER WASHER 1.9 MM
999
SPACER WASHER 2.0 MM
999
SPACER WASHER 2.1 MM
999
SPACER WASHER 2.2 MM
999
SPACER WASHER 0.90 MM
999
SPACER WASHER 1.00 MM
999
SPACER WASHER 1.10 MM
999
SPACER WASHER 1.20 MM
999
SPACER WASHER 1.30 MM
999
SPACER WASHER 1.40 MM
999
SPACER WASHER 1.50 MM
999
PIN , 000,001,100,101 UP TO REAR AXLE 000286, 010 UP TO REAR AXLE 129302, 110 UP TO REAR AXLE 087839
999
SPACER TUBE , 000,001,100,101 UP TO REAR AXLE 000286, 010 UP TO REAR AXLE 129302, 110 UP TO REAR AXLE 087839
999
SPACER TUBE AS REQUIRED 25.0 MM
999
SPACER WASHER 2.1 MM
999
SPACER TUBE , Replaced By: A1803511653
999
SPACER WASHER 2.2 MM
999
SPACER TUBE AS REQUIRED 25.4 MM
999
SPACER WASHER 2.3 MM
999
SPACER TUBE AS REQUIRED 25.6 MM
999
SPACER WASHER 2.4 MM
999
SPACER TUBE AS REQUIRED 25.8 MM
999
SPACER WASHER 2.5 MM
999
SPACER WASHER 3.0 MM
999
SPACER WASHER AS REQUIRED 2.6 MM
999
SPACER WASHER AS REQUIRED 2.7 MM
999
SPACER WASHER , Replaced By: A1803513052
999
SPACER WASHER AS REQUIRED 2.8 MM
999
SPACER WASHER AS REQUIRED 3.1 MM
999
SPACER WASHER , Replaced By: A1803513152
999
NUT THRUST ARM TO FRAME FLOOR UNIT, 010 UP TO CHASSIS 030863,012 UP TO CHASSIS 063372
999
LOCK
999
LOCK
999
DIFFERENTIAL CASE , 000,001,010 UP TO REAR AXLE 088702, 100,101,110 UP TO REAR AXLE 037327, Replaced By: A1103530101, +001A1103530048
999
LOCK
999
LOCK
999
THRUST WASHER , Replaced By: A1153531062
999
THRUST WASHER , Replaced By: A1153530962
999
THRUST WASHER , Replaced By: A1153530862
999
SPACER WASHER 1.1 MM
999
SPACER WASHER 1.2 MM
999
SPACER WASHER 1.3 MM
999
SPACER WASHER 1.4 MM
999
SPACER WASHER 1.5 MM
999
SPACER WASHER 1.6 MM
999
SPACER WASHER 1.7 MM
999
SPACER WASHER 1.8 MM
999
SPACER WASHER 1.9 MM
999
SPACER WASHER 2.0 MM
999
SNAP RING 2.25 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
999
SNAP RING 2.35 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
999
SNAP RING 2.45 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
999
SNAP RING 2.55 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
999
COTTER PIN , ON OM 352 126-PS ENGINE,UP TO ENGINE 041863
999
WASHER MOUNTING PLATE TO BODY FLOOR
999
LOCK WASHER , 010 UP TO REAR AXLE 009905,012 UP TO REAR AXLE 026069
999
SCREW , 010 UP TO REAR AXLE 009905,012 UP TO REAR AXLE 026069
999
SCREW , Replaced By: N304017008021
999
CLAMP REAR AXLE TUBE
999
CLAMP REAR AXLE HOUSING
