Поз.
Артикул
Описание
3
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
3
CLUTCH PRESSURE PLATE , Replaced By: A0002509604
3
CLUTCH PRESSURE PLATE , Replaced By: A0002509604
4
SPRING
5
RELEASE LEVER , ON SPECIAL REQUEST, H.D. CLUTCH
5
RELEASE LEVER , Replaced By: A0002524213
6
PIN
7
CLAMPING SLEEVE
8
SPACER RING
9
NUTTO 001 250 03 04
9
NUT , Replaced By: A0002522772
10
PRESSURE SPRING CLUTCH PRESSURE PLATE
11
SLEEVE
12
THRUST WASHER
12
CLUTCH PRESSURE PLATE , Replaced By: A0002522106
16
CLUTCH DISC , Replaced By: A0042501703
16
CLUTCH DISC , Replaced By: A0012501103
16
CLUTCH DISC , Replaced By: A0012501103
16
CLUTCH DISC , Replaced By: A0012501103
16
CLUTCH DISC , Replaced By: A0102502603, +001A0042501904, +006N000912008012
25
SCREW PIPE CLAMP
25
SCREW , Replaced By: N304017008021
25
SCREW COMPRESSED AIR ELBOW
26
LOCK WASHER
26
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
27
HYDRAULIC CLUTCH , 000,001,004,010,016 FROM CHASSIS 130558, 100,101,104,110,116 FROM CHASSIS 225648
27
HYDRAULIC CLUTCH , 000,001,010 UP TO CHASSIS 130557, 100,101,110 UP TO CHASSIS 225647
27
HYDRAULIC CLUTCH , Replaced By: A1112501602
30
SCREW PLUG
31
SEAL RING
32
HOUSING
32
HOUSING , 261361, Replaced By: A1112502005, +001A1112600821, +001A1112610379, +001A1119910015, +001N000137010200
32
HOUSING , 261361, Replaced By: A1112502005, +001A1112600821, +001A1112610379, +001A1119910015, +001N000137010200
33
STUD TAIL-, BRAKE-, AND TURN SIGNAL LIGHTS
34
HOUSING HYDRAULIC CLUTCH
34
HOUSING , Replaced By: A1112502205
35
COVER PLATE , Replaced By: A1122500590
35
COVER PLATE
37
BOOT
38
SEAL HOLDER
39
SCREW COVER PLATE TO COVER PLATE M 6 X 12
39
SCREW , Replaced By: N304017006018
39
SCREW BRACKET TO BRACKET
40
SCREW , Replaced By: N304017012002
40
SCREW CONNECTOR TO EXHAUST MANIFOLD
40
SCREW RELEASE LEVER TO SHAFT, 024,026,027,028,121,122 5 095724 065,131,132 5 104252
41
WASHER
41
WASHER BRACKET TO REAR CROSS MEMBER
42
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
42
LOCK WASHER FITTING TO BRACKET
43
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
43
SPRING WASHER CAB FLOOR
43
SPRING WASHER , Replaced By: N000137012203
44
NUT HUB CAP TO BRACKET
44
NUT STRAP TO SUPPORT,5 149419
46
SCREW PIPE CLAMP
46
SCREW , Replaced By: N304017008021
46
SCREW PRESSURE REGULATOR WITH TIRE INFLATOR CONNECTION TO SUBSTRUCTURE
47
SPRING WASHER , Replaced By: N000137008212
47
SPRING WASHER BRAKE SHOE WITH LINING
47
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
58
RELEASE BEARING , ON SPECIAL REQUEST, H.D. CLUTCH
58
RELEASE BEARING
58
RELEASE BEARING , Replaced By: A1112500115
59
RELEASE BEARING , Replaced By: A1112500115
59
BALL BEARING , 000,001,004,010,016 FROM CHASSIS 081441, 100,101,104,110,116 FROM CHASSIS 128634
59
BALL BEARING , 000,001,004,010,016 FROM CHASSIS 081441, 100,101,104,110,116 FROM CHASSIS 128634
61
RELEASE YOKE
62
SPRING
62
SPRING , Replaced By: A3199930025
63
SNAP RING
64
SLAVE CYLINDER , 010 FROM CHASSIS 048977,012 FROM CHASSIS 108750 NOT FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
64
SLAVE CYLINDER , Replaced By: A0002951907
64
SLAVE CYLINDER , FROM ENGINE 002205 014 UP TO CHASSIS 049461,021 UP TO CHASSIS 049448,023 UP TO CHASSIS 049722
65
PIN
66
BOOT
67
VALVE
67
BLEEDER VALVE
68
PROTECTIVE CAP , Replaced By: A0004217187
72
REPAIR KIT , 014 FROM CHASSIS 049462,021 FROM CHASSIS 049449,023 FROM CHASSIS 049723
73
ROD
74
NUT
74
NUT , Replaced By: N304035008001
74
NUT ,B 884219
75
SPRING
75
SPRING
76
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
76
LOCK WASHER TAIL LAMP TO BRACKET
77
NUT BATTERY CASE
77
NUT
999
SCREW PUMP TO BRACKET
999
SCREW COVER PLATE TO BRACKET
999
SCREW BRACKET TO AIR INTAKE PIPE
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
SPRING WASHER CABLE TO ALTERNATOR
999
BALL PIVOT , 261361
999
REPAIR KIT ON CLUTCH END, NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
CLUTCH LINING , NO LONGER AVAILABLE INDIVIDUALLY
999
RIVET LINING WITH INTERMEDIATE SPRING,5 563495
999
CLUTCH LINING ON FLYWHEEL END, NOT FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH NO LONGER AVAILABLE INDIVIDUALLY
999
CLUTCH LINING , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
RIVET LINING WITH INTERMEDIATE SPRING
999
RIVET , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
RIVET , Replaced By: A0002521275
