Поз.
Артикул
Описание
4
HEAT EXCHANGER
6
SEAL OUTSIDE
6
SEAL , Replaced By: A0008351298
6
SEAL
6
SEAL , Replaced By: A0008355898
10
DISTRIBUTOR
12
FRAME
16
GROMMET
16
GROMMET , Replaced By: A0009971881
18
BLOWER
20
MOTOR
22
CARBON BRUSH SET
22
CARBON BRUSH SET , Replaced By: A0008352575
24
FAN
26
INTERMEDIATE LAYER ,044 017154 EXHAUST STOCK OF OLD PART NUMBER FIRST
34
DEFROSTER NOZZLE RIGHT
34
DEFROSTER NOZZLE LEFT
36
MOUNTING , Replaced By: A1108310020
36
MOUNTING MOSS TYPE RUBBER
38
AIR DISTRIBUTOR FIRE WALL, TOP
40
BUSHING
42
BUSHING
44
FLAP RIGHT
44
FLAP LEFT
48
BUSHING
50
FRAME LEFT
50
FRAME RIGHT
52
FOAM PLASTICS 10 MM, ORDER BY THE METER
52
FOAM PLASTICS , Replaced By: A0009831298
52
RUBBER STRIP , Replaced By: A0009830898
54
SEAL
56
GRILLE
58
OPERATING UNIT WITH WIRE CABLES
58
OPERATING UNIT ,043 002979 EXHAUST STOCK OF OLD PART NUMBER FIRST, Replaced By: A1138300285
58
OPERATING UNIT , Replaced By: A1138300385
60
PLUG
62
OPERATING HANDLE RED,043 002980
62
OPERATING HANDLE TINTED,043 002980
62
OPERATING HANDLE BLUE,043 002979
62
OPERATING HANDLE , Replaced By: A0008331340
62
OPERATING HANDLE , Replaced By: A0008331440
70
CLIP
72
WIRE CABLE 485 MM SHORTEN TO 232 MM DURING ASSEMBLY
74
SPIRAL 396 MM
74
SPIRAL , Replaced By: A1138330530
78
GROMMET
80
PROTECTIVE CAP WIRE CABLE TO AIR FLAP
80
GROMMET , Replaced By: A1093270059
82
ESCUTCHEON LEFT
84
ESCUTCHEON CENTER FOR CONTROL OF HEATING AND VENTILATION, FROM DATE OF INSTALLATION OF SAFETY STEERING (COLLAPSIBLE COLLAR)
84
ESCUTCHEON , Replaced By: A1138300889
84
ESCUTCHEON ,043 002979 EXHAUST STOCK OF OLD PART NUMBER FIRST, Replaced By: A1138300889
86
ESCUTCHEON ,043 002979 EXHAUST STOCK OF OLD PART NUMBER FIRST, Replaced By: A1138301289
86
ESCUTCHEON ,043 002979 EXHAUST STOCK OF OLD PART NUMBER FIRST, Replaced By: A1138301089
86
ESCUTCHEON RIGHT
86
ESCUTCHEON RIGHT
90
AIR DUCT LEFT
90
AIR DUCT RIGHT
92
RUBBER SECTION , ORDER BY THE METER
94
OPERATING HANDLE AIR FLAP
96
SEAL
118
GROMMET EXPANSION PLUG
120
GROMMET FEED LINE
122
VALVE , 000,001,004,010 UP TO CHASSIS 152805,002,003,005,011 UP TO CHASSIS 012119,100,101,104,110 UP TO CHASSIS 267732
122
VALVE DRAIN
124
HOSE SIDE PANE DEFROSTER NOZZLES
126
PIPE LINE TO HEAT EXCHANGER
140
CAP
144
GRILLE
999
OPERATING HANDLE , Replaced By: A0008331240
999
NUT
999
WASHER
999
LOCK , Replaced By: A1409941045
999
LOCK , Replaced By: A1409941045
999
CLIP , ALSO APPLICABLE TO VERSION 55705/11-/62
999
HOSE CLAMP LINE MOUNTING
999
HOSE , 000,001,004,010 FROM CHASSIS 064106 ALSO INSTALLED ON,SEE FOOTNOTE 27,100,101,104,110 FROM CHASSIS 099642 ALSO INSTALLED ON,SE E FOOTNOTE 38 AND FOOTNOTE 40
999
PIPE LINE ,042 000935
999
PIPE LINE ,042 000935
999
ESCUTCHEON ,043 002979 EXHAUST STOCK OF OLD PART NUMBER FIRST, Replaced By: A1138300989
999
HOSE 360 MM FEED LINE FROM ENGINE TO HEAT EXCHANGER,044 017153 ORDER BY THE METER
999
LOCK FUEL LINE
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
999
NUT , Replaced By: N000439006204
999
NUT BATTERY CABLE TO CABLE CONNECTOR,5 193595
999
THREADED PIN
999
SCREW BRACKET TO BRACKET
999
SCREW BRACKET TO AIR INTAKE PIPE
999
SCREW FAN SHROUD TO RADIATOR
999
SCREW CONNECTOR TO CAB M6X8
999
SCREW BRACKET TO EXHAUST PIPE BRACKET
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017006018
999
SCREW , Replaced By: N304017006020
999
SCREW , Replaced By: N304017006034
999
NUT
999
NUT TACHOGRAPH TO BRACKET
999
NUT
999
NUT WIRE CABLES TO MOUNTING PINS
999
LOCK PLATE
999
SHEET METAL SCREW BRACKET TO WINDOW SILL
999
SHEET METAL SCREW BRACKET TO CAB
999
SHEET METAL SCREW INTERIOR LAMP B 3.5X13
999
SHEET METAL SCREW RELAY TO APPARATUS SUPPORT,K 182153K 239549
999
SHEET METAL SCREW BRACKET TO CAB 4,2X13
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
SHEET METAL SCREW WINDOW SILL GIRDER LOWER PART,4 273689
999
SHEET METAL SCREW APPARATUS PLATE TO BRACKET,776251
999
SHEET METAL SCREW
999
SHEET METAL SCREW BRACKET TO CAB
999
WASHER PLUG MOUNTING, FOR VEHICLES HAVING HIGH CAB 344
999
WASHER , Replaced By: N009021004207
999
WASHER COVERING TO CYCLONE AIR TRAP
999
WASHER , Replaced By: N009021006208
999
WASHER MODULATOR TO ENGINE CONTROL SHAFT
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
BALL SOCKET
999
BULB2W
999
HOSE WATER DRAIN, ORDER BY THE METER
999
SCREW PUMP TO BRACKET
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
SCREW LICENSE PLATE TO BRACKET
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
NUT SPRING-LOADED PUSH ROD
999
NUT BATTERY CABLE MOUNTING,5 193595
999
LOOM TIE HAND PUMP
999
STRAP165 MM, UP TO CHASSIS 772045 EXCEPT FOR:500000-599999 ORDER BY THE METER
999
HOSE FROM HEATING PIPE AT ENGINE TO HEATING PIPE AT RADIATOR, ORDER BY THE METER
999
PULL ROD
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
