Поз.
Артикул
Описание
6
AXLE HOUSING
7
SCREW PLUG , Replaced By: A0009972632
8
DIFFERENTIAL GEAR
9
RING
10
THRUST WASHER AS REQUIRED 1.30 MM
14
SIDE GEAR , Replaced By: A1083500140
14
DIFFERENTIAL PINION LEFT
16
DIFFERENTIAL PINION
18
SPHERICAL WASHER
19
PIN
20
SPRING
21
RING GEAR AND PINION
22
REPAIR KIT
23
SCREW
24
TAPERED ROLLER BEARING RING GEAR BEARING
27
SPACER WASHER 1.8 MM AS REQUIRED
31
SCREW COLLAR
32
LOCK
36
LOCK
37
SCREW COVER PLATE TO COVER PLATE M 6 X 12
37
SCREW , Replaced By: N304017006018
38
SPACER WASHER AS REQUIRED 1.5 MM
41
TAPERED ROLLER BEARING
43
SPACER BUSHING
44
TAPERED ROLLER BEARING
46
COVER , 000,001,100,101 FROM REAR AXLE 000287, 010 FROM REAR AXLE 129303, 110 FROM REAR AXLE 087840
47
SCREW
48
LOCK WASHER COMPRESSED AIR LINE TO BRACKET
50
SEAL RING
51
SCREW CABLE HARNESS MOUNTING
52
LOCK WASHER PARKING BRAKE VALVE TO INSTRUMENT PANEL
54
GROOVED NUT
55
LOCK
62
JOINT
63
SPACER WASHER
64
LOCK
65
SLEEVE STEERING COLUMN BEARING, NOT FOR USE WITH MERCEDES-BENZ CAB4 375508
66
ROLLERTO 387 460 14 09
67
SPACER WASHER
68
LOCK RING AS REQUIRED 1.75 MM
69
BUSHING
70
UNIVERSAL JOINT , 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
71
SNAP RING 2.15 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
75
SCREW
76
LOCK WASHER COMPRESSED AIR LINE TO BRACKET
81
AXLE SHAFT LEFT
83
AXLE SHAFT RIGHT
84
DOWEL PIN
86
CYLINDR. ROLLER BEARING ,10/20879179, 50/60880935, Replaced By: A0029819001
86
BALL BEARING , Replaced By: A0029812301
87
LOCK
88
GROOVED NUT
90
REPAIR KIT
999
TAPERED ROLLER BEARING
999
TAPERED ROLLER BEARING
999
BARREL-TYPE BEARING
999
SEAL RING
999
AXLE HOUSING , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
RING REPAIR SIZE
999
BRACKET RIGHT
999
FLANGE
999
THRUST ARM RIGHT
999
RUBBER MOUNTING
999
LOCK
999
SCREW
999
SPACER WASHER 1.9 MM AS REQUIRED
999
SPACER WASHER 2.0 MM AS REQUIRED
999
SPACER WASHER AS REQUIRED 2.1 MM
999
SPACER WASHER , Replaced By: A1123531152
999
SPACER WASHER AS REQUIRED 1.6 MM
999
SPACER WASHER AS REQUIRED 1.7 MM
999
SPACER WASHER AS REQUIRED 1.8 MM
999
REAR AXLE
999
DIFFERENTIAL PINION , Replaced By: A1403530514
999
SPACER WASHER 2.0 MM
999
SPACER TUBE AS REQUIRED 25.0 MM
999
SPACER WASHER 2.1 MM
999
SPACER TUBE , Replaced By: A1803511653
999
SPACER WASHER 2.2 MM
999
SPACER TUBE AS REQUIRED 25.4 MM
999
SPACER WASHER 2.3 MM
999
SPACER TUBE AS REQUIRED 25.6 MM
999
SPACER WASHER 2.4 MM
999
SPACER TUBE AS REQUIRED 25.8 MM
999
SPACER WASHER 2.5 MM
999
SPACER WASHER 3.0 MM
999
SPACER WASHER AS REQUIRED 2.6 MM
999
SPACER WASHER AS REQUIRED 2.7 MM
999
SPACER WASHER , Replaced By: A1803513052
999
SPACER WASHER AS REQUIRED 2.8 MM
999
SPACER WASHER AS REQUIRED 3.1 MM
999
SPACER WASHER , Replaced By: A1803513152
999
LOCK
999
LOCK
999
LOCK
999
LOCK
999
THRUST WASHER AS REQUIRED 1.40 MM
999
THRUST WASHER AS REQUIRED 1.50 MM
999
THRUST WASHER AS REQUIRED 1.60 MM
999
THRUST WASHER AS REQUIRED 1.70 MM
999
SNAP RING 2.25 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
999
SNAP RING 2.35 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
999
SNAP RING 2.45 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
999
SNAP RING 2.55 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
999
SCREW INTERMEDIATE BEARING TO BRACKET M 8X20
999
NUT , Replaced By: N304032008006
999
NUT
999
CLAMP REAR AXLE TUBE
999
CLAMP REAR AXLE HOUSING
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
