Поз.
Артикул
Описание
3
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
4
SPRING
5
RELEASE LEVER , ON SPECIAL REQUEST, H.D. CLUTCH
6
PIN
7
CLAMPING SLEEVE
8
SPACER RING
9
NUTTO 001 250 03 04
9
NUT , Replaced By: A0002522772
10
PRESSURE SPRING CLUTCH PRESSURE PLATE
11
SLEEVE
12
THRUST WASHER
16
CLUTCH DISC SPLINE-SHAFT SECTION, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
24
REPAIR KIT ON CLUTCH END, NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
25
SCREW , Replaced By: N304017008021
25
SCREW PIPE CLAMP
26
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
27
HYDRAULIC CLUTCH , 000,001,004,010,016 FROM CHASSIS 130558, 100,101,104,110,116 FROM CHASSIS 225648
30
SCREW PLUG
31
SEAL RING
32
HOUSING
33
STUD TAIL-, BRAKE-, AND TURN SIGNAL LIGHTS
34
HOUSING HYDRAULIC CLUTCH
35
COVER PLATE
37
BOOT
38
SEAL HOLDER
39
SCREW COVER PLATE TO COVER PLATE M 6 X 12
39
SCREW , Replaced By: N304017006018
40
SCREW , Replaced By: N304017012002
40
SCREW CONNECTOR TO EXHAUST MANIFOLD
40
SCREW RELEASE LEVER TO SHAFT, 024,026,027,028,121,122 5 095724 065,131,132 5 104252
41
WASHER
42
LOCK WASHER FITTING TO BRACKET
43
SPRING WASHER CAB FLOOR
43
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
44
NUT STRAP TO SUPPORT,5 149419
46
SCREW PIPE CLAMP
46
SCREW , Replaced By: N304017008021
47
SPRING WASHER , Replaced By: N000137008212
47
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
52
SCREW HORN TO STRUT
52
SCREWM 8X18
53
SPRING WASHER , Replaced By: N000137008212
53
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
54
WASHER , Replaced By: N000125010532
54
WASHER RADIATOR TO RUBBER MOUNTING
55
SCREW , Replaced By: N304017010050
55
SCREW , Replaced By: N304017010055
56
SPRING WASHER STEERING COLUMN BRACKET TO CAB
57
NUT BRACKET TO SUPPORT AND TO END PIECE
58
RELEASE BEARING
58
RELEASE BEARING , ON SPECIAL REQUEST, H.D. CLUTCH
58
RELEASE BEARING , Replaced By: A1112500115
59
BALL BEARING , 000,001,004,010,016 FROM CHASSIS 081441, 100,101,104,110,116 FROM CHASSIS 128634
59
BALL BEARING , 000,001,004,010,016 FROM CHASSIS 081441, 100,101,104,110,116 FROM CHASSIS 128634
61
RELEASE YOKE
62
SPRING
63
SNAP RING
64
SLAVE CYLINDER , 010 FROM CHASSIS 048977,012 FROM CHASSIS 108750 NOT FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH
65
PIN
66
BOOT
66
BOOT ,027649
67
BLEEDER VALVE
68
PROTECTIVE CAP , Replaced By: A0004217187
68
PROTECTIVE CAP ,5 962906
72
REPAIR KIT , 014 FROM CHASSIS 049462,021 FROM CHASSIS 049449,023 FROM CHASSIS 049723
72
REPAIR KIT ,027649
73
ROD
74
NUT , Replaced By: N304035008001
74
NUT
75
SPRING
76
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
77
NUT
999
RIVET , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
CLUTCH LINING , Replaced By: A1085860025
999
CLUTCH LINING ON FLYWHEEL END, NOT FOR USE WITH MERCEDES-BENZ HYDRAULIC-AUTOMATIC CLUTCH NO LONGER AVAILABLE INDIVIDUALLY
999
CLUTCH LINING , NO LONGER AVAILABLE INDIVIDUALLY
999
CLUTCH LINING , NO LONGER AVAILABLE INDIVIDUALLY
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
SCREW COVER PLATE TO BRACKET
999
SEAL RINGTO 001 431 72 14
999
SCREW PUMP TO BRACKET
