Поз.
Артикул
Описание
4
ACCELERATOR PEDAL , NOT USED
4
ACCELERATOR PEDAL
6
PIN
8
GROMMET
10
PLATE ,014,10/50,12,52 FROM CHASSIS 049462 INSTALLED ON,SEE FOOTN.15,014,20/60,22/62 FROM CHASSIS 049391 INSTALLED ON,SEE FOOTN.16 A ND 20
10
PEDAL PLATE , Replaced By: A1103000002
12
PLATE ,014,10/50,12,52 FROM CHASSIS 049462 INSTALLED ON,SEE FOOTN.15,014,20/60,22/62 FROM CHASSIS 049391 INSTALLED ON,SEE FOOTN.16 A ND 20
14
SHAFT , Replaced By: A1133000520
14
SHAFT
16
SHAFT , Replaced By: A1133000420
16
SHAFT
18
BEARING
18
BEARING , Replaced By: A1213010018
20
BEARING CONTROL SHAFT
20
BEARING RIGHT CONTROL SHAFT
22
LOCK RING
24
SPACER TUBE CONTROL SHAFT, 043 FROM CHASSIS 002067
26
SCREW CLAMP MOUNTING M 6X16
26
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
26
SCREW LINE TO CROSS MEMBER
26
SCREW HOSE TO RADIATOR BASE FRAME
26
SCREW , Replaced By: N000000001146
28
NUT RETAINER , Replaced By: A0019906791
28
NUT RETAINER REGULATOR AND CUT-OUT, FOR VEHICLES HAVING LOW CAB 344 ON CAB 344
28
NUT RETAINER LICENSE PLATE TO BRACKET
32
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
32
SCREW , Replaced By: N304017008016
34
SPRING WASHER BRAKE SHOE WITH LINING
34
SPRING WASHER , Replaced By: N000137008212
34
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
36
WASHER EXHAUST MUFFLER TO STRAP
36
WASHER MOUNTING PLATE TO BODY FLOOR
36
WASHER , Replaced By: N000125008443
38
SPRING
40
ROD
42
NUT TACHOGRAPH TO BRACKET
42
NUT
46
BALL PIVOT
46
BALL SOCKET , Replaced By: A0009918922
46
BALL SOCKETTO 102 070 09 75, Replaced By: A0009930461
46
CONICAL CUPTO 102 070 09 75
48
BOOT
48
BOOT
50
SCREW
52
NUT
52
NUT
52
NUT BATTERY CASE
54
STOP
54
STOP
56
SWITCH , UP TO CHASSIS: 011: 12/52 100000 007,008,015,017: 12/52 200000
58
NUT
60
HOUSING
62
LEVER
64
PIN
66
SPRING
999
ACCELERATOR PEDAL
999
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
999
SPRING WASHER CABLE TO ALTERNATOR
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
SCREW SELECTOR LEVER TO SELECTOR FINGER
999
SCREW , Replaced By: N000931006118
999
SCREW CONNECTOR
999
SCREW CAB FLOOR COVERING M 6X25
999
SCREW LINE TO CROSS MEMBER
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
