Поз.
Артикул
Описание
166
TRANSMISSION CASE COVER TOP, ON SPECIAL REQUEST, FLOOR SHIFT
168
TRANSMISSION CASE COVER , ON SPECIAL REQUEST, FLOOR SHIFT
170
INTERLOCK PLUG , Replaced By: A3442657044
172
BUSHING INTERLOCK PIN, 184087, 309.030-035,051-059 192298, 309.050 182066, 309.1
174
INTERLOCK PIN REVERSE SPEED, 184087, 309.030-035,051-059 192298, 309.050 182066, 309.1556499
176
PRESSURE SPRING INTERLOCK PIN, 184087, 309.030-035,051-059 192298, 309.050 182066, 309.1556499
178
SCREW PLUG
180
SHAFT , ON SPECIAL REQUEST, FLOOR SHIFT
180
SHIFTING SHAFT , Replaced By: A1132600038
182
SEAL RING , ON SPECIAL REQUEST, FLOOR SHIFT
184
SHIFTING FINGER , ON SPECIAL REQUEST, FLOOR SHIFT
186
SCREW , ON SPECIAL REQUEST, FLOOR SHIFT
188
LOCK WASHER
188
LOCK WASHER , ON SPECIAL REQUEST, FLOOR SHIFT
190
YOKE , ON SPECIAL REQUEST, FLOOR SHIFT
192
SEAL , ON SPECIAL REQUEST, FLOOR SHIFT
192
SEAL , Replaced By: A1112670083
194
PIN , ON SPECIAL REQUEST, FLOOR SHIFT
196
NUT
196
NUT , Replaced By: A0019900151
198
GUIDE PLATE , ON SPECIAL REQUEST, FLOOR SHIFT
200
PIN , ON SPECIAL REQUEST, FLOOR SHIFT
202
PRESSURE SPRING , ON SPECIAL REQUEST, FLOOR SHIFT
204
RIVET
206
WASHER DETENT PLATE TO COVER, UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
208
SPRING WASHER SHIFTING CYLINDER TO YOKE
208
SPRING WASHER , ON SPECIAL REQUEST, FLOOR SHIFT
210
NUT , FROM TRANSMISSION
212
SHIFTING FORK 1ST AND 2ND SPEED
214
SHIFTING FORK 3RD AND 4TH SPEED
214
SHIFTING FORK , Replaced By: A3092650102
216
LEVER REVERSE SPEED
218
SPRING
219
BALL
220
SPACER TUBE
222
SPACER TUBE
224
WASHER 0.30 MM
224
WASHER0.5 MM, 10/50,12/52 UP TO CHASSIS 096085, 20/60,22/62 UP TO CHASSIS 095140
224
WASHER1.0 MM, 10/50,12/52 UP TO CHASSIS 096085, 20/60,22/62 UP TO CHASSIS 095140
224
SPACER RING , Replaced By: A1119903440
224
SPACER RING , Replaced By: A1119900940
224
SPACER RING , Replaced By: A1119900840
226
SHIFTING ROD 1ST AND 2ND SPEED
228
SHIFTING ROD 3RD AND 4TH SPEED
230
SHIFTING ROD REVERSE SPEED
232
SPACER TUBE
234
KEY
236
BREATHER TRANSFER CASE
238
SWITCH BACK-UP LIGHT, 040899
240
PLUG HOUSING
240
PLUG , Replaced By: A0025452428
240
PLUG , Replaced By: A0095454028, +002A0015453826, +001A0095454128
242
SEAL RING SOLENOID VALVE A 18X24
244
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
244
SCREW LEVER TO SHAFT
244
SCREW , Replaced By: N304017008027
246
PIN , ON SPECIAL REQUEST, FLOOR SHIFT
248
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
248
SPRING WASHER BRAKE SHOE WITH LINING
248
SPRING WASHER , Replaced By: N000137008212
250
BRACKET
252
CLIP HOSE TO CAB,4 238841
254
SHIFTING TUBE
254
SHIFTING TUBE , Replaced By: A1112603182
256
BEARING COVER , Replaced By: A1112680834
256
BEARING COVER BOTTOM
258
RUBBER RING
258
RUBBER RING , Replaced By: A1112670086
260
WASHER
262
LOCK
264
BEARING
268
BUSHING
270
BEARING COVER TOP
270
BEARING COVER , Replaced By: A1112680834
272
COVER PLATE
274
BOOT
276
BOOT BOTTOM
278
SCREW MANUAL PUMP TO BRACKET,D 031246
278
SCREW COVER PLATE TO BRACKET
280
SPRING WASHER CABLE TO ALTERNATOR
280
SPRING WASHER LICENSE PLATE TO BRACKET
282
WASHER EXHAUST MUFFLER TO STRAP
282
WASHER , Replaced By: N000125007408
282
WASHER COVER PLATE TO COVER PLATE
286
SHIFT LEVER
288
SCREW
290
BUSHING
292
WASHER
292
SCREW ,042 004925, Replaced By: A1119901001, +001A0019900151
292
WASHER , Replaced By: A1119903540
294
NUT , Replaced By: A0019900151
294
NUT
296
KNOB
296
KNOB , Replaced By: A1112680942
296
KNOB ,042 004925, Replaced By: A1112680242
298
PULL ROD ,042 004925, Replaced By: A1132600589, +001N000985006000
298
PULL ROD ,042 004926 - 014258
298
PULL ROD ,042 014259
300
END PIECE
302
BUSHING
302
BUSHING
304
NUT
306
WASHER
306
WASHER , UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
306
WASHER COVER PLATE TO COVER PLATE
308
NUT
310
NUT OIL TANK TO BRACKET
310
NUT , Replaced By: N000985006000
310
NUT
310
NUT , Replaced By: N913002006009
999
SEALING CORD , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
SEAL RING , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
GASKET , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
GASKET
999
GASKET , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
GASKET
999
WASHER 0.20 MM, ON SPECIAL REQUEST, FLOOR SHIFT
999
WASHER 0.30 MM, ON SPECIAL REQUEST, FLOOR SHIFT
999
TRANSMISSION WITH BELL HOUSING, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
SEAL RING , Replaced By: A0119976447
999
SEAL RING
999
SHIFTING FORK 1ST AND 2ND SPEED
999
LOCK WASHER TAIL LAMP TO BRACKET
999
HEADLESS SETSCREW , Replaced By: A1109900110, +001N000137010101
999
SCREW YOKE TO SHIFTING TUBE
999
SCREW
999
SCREW DISTRIBUTOR TO FRAME
999
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
999
SCREW , Replaced By: N304017008043
999
SCREW FITTING TO TRANSMISSION M8X32
999
NUT
999
SEAL RING OIL FILLING AND OIL DRAIN
999
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
999
SCREW VALVE TO BRACKET M 8X55
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
