Поз.
Артикул
Описание
1
FUEL TANK 82 L.
3
REINFORCEMENT
4
GASKET
5
SPRING WASHER ALTERNATOR CONNECTION D+
6
NUT TACHOGRAPH TO BRACKET
7
FUEL STRAINER
8
SEAL RING
9
GAUGE SENDER UNIT
10
BASE FRONT
11
BRACKET
12
RUBBER BUFFER
15
BRACKET TANK FRONT BRACING
17
CLAMP , 000,001,010 FROM CHASSIS 130558, 100,101,110 FROM CHASSIS 225648
21
WASHER COMPRESSED AIR LINE TO BRACKET
21
WASHER , Replaced By: N009021006208
22
WASHER PROTECTIVE PLATE TO BRACKET,5 502998
23
LOCK WASHER TAIL LAMP TO BRACKET
24
NUT , Replaced By: N304032008006
24
NUT
27
GASKET
28
BOOT
29
LOCKING CAP
32
TANK
34
CLIP
35
HOSE4.5X10X900MM
36
GROMMET
37
BOOT
38
CLAMP , 012 FROM CHASSIS 058521, 014 FROM CHASSIS 045548, 015 FROM CHASSIS 002627
126
LINE RETURN,042 013015
127
HOSE DE-AERATION B8X12,5 218304 ORDER BY THE METER
999
FILLER CAP MAKE YMOS YMOS, STATE LOCK NUMBER WHEN ORDERING UP TO CHASSIS:012 058944,014 045196,015 002591
999
FUEL PUMP , Replaced By: A0010915201, +001A1084700281, +003A1269880011, +001N000127005203, +003N000127006203, +003N000933006016, +003N000934005004
999
CLAMP FORKED SUPPORT,TOP
999
CLAMP , 116.020 071390 ALSO INSTALLED ON 071392,071396,071400,071402,071416. 116.024,025 068051 ALSO INSTALLED ON 068099,068265 EXCEPT FOR 055714,055888,057629,058694,066624,066628,066632,066803,067088,067089,067410,067542,067578-067580, 067860-067862,067865,067924,067928-067943,067945,067948,067952,067953,067955-067969,067971-068001, 068005,068007-068019,068024,068026-068029,068031-068033,068035-068048,068050.
999
DAMPING STRIP FUEL AND BRAKE LINES TO FRAME FLOOR UNIT, 016 UP TO CHASSIS 035213 EXCEPT FOR, SEE FOOTNOTE 29, 018,019 UP TO CHASSIS 036080 EXCEPT FOR, SEE FOOTNOTE 30
999
TANK , Replaced By: A1154710268, +001A0029884678
999
BUFFER
999
SCREW
999
SCREW FUEL AND BRAKE LINES TO FRAME FLOOR UNIT
999
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
LOCK WASHER. SPRING LOCK WASHER ELECTRIC CABLE TO HORN TO 004 542 44 20 /45 20
999
SCREW BRACKET TO ELECTRICAL APPARATUS COMPARTMENT
999
SCREW , Replaced By: N304017006034
999
SCREW COVER PLATE TO BRACKET
999
NUT AIR INTAKE PIPE TO AIR INTAKE PIPE,937184
999
NUT BALL PIVOT TO LEVER
999
SHEET METAL SCREW BRACKET TO CAB FLOOR, EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 5 180559
999
SHEET METAL SCREW , Replaced By: N000000002062
999
CLAMP
999
SCREW COVER PLATE TO COVER PLATE M 6 X 10
999
CLAMP
999
CLAMP , 018 FROM CHASSIS 030632, 019 FROM CHASSIS 030489
999
CLAMP
999
LOCK WASHER T-FITTING TO BRACKET
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
CLAMP
