Поз.
Артикул
Описание
8
AXLE HOUSING
8
AXLE HOUSING
8
REAR AXLE , Replaced By: A1113500003
10
SCREW PLUG , Replaced By: A0009972632
12
DIFFERENTIAL GEAR
14
RING REPAIR SIZE
14
RING
16
THRUST WASHER AS REQUIRED 1.60 MM
16
THRUST WASHER AS REQUIRED 1.50 MM
16
THRUST WASHER AS REQUIRED 1.30 MM
16
THRUST WASHER AS REQUIRED 1.40 MM
16
THRUST WASHER AS REQUIRED 1.70 MM
20
SIDE GEAR , Replaced By: A1083500140
20
DIFFERENTIAL PINION LEFT
22
DIFFERENTIAL PINION
22
DIFFERENTIAL PINION , Replaced By: A1403530514
24
SPHERICAL WASHER
26
PIN
28
SPRING
30
RING GEAR AND PINION
32
REPAIR KIT
34
SCREW
36
TAPERED ROLLER BEARING RING GEAR BEARING
38
SPACER WASHER AS REQUIRED 2.1 MM
38
SPACER WASHER 2.0 MM AS REQUIRED
38
SPACER WASHER 1.9 MM AS REQUIRED
38
SPACER WASHER 1.8 MM AS REQUIRED
38
SPACER WASHER , Replaced By: A1123531152
42
SCREW COLLAR
44
LOCK
44
LOCK
44
LOCK
44
LOCK
44
LOCK
48
LOCK
50
SCREW COVER PLATE TO COVER PLATE M 6 X 12
50
SCREW , Replaced By: N304017006018
50
SCREW HOSE TO BRACKET
52
SPACER WASHER AS REQUIRED 1.8 MM
52
SPACER WASHER AS REQUIRED 1.7 MM
52
SPACER WASHER AS REQUIRED 1.6 MM
52
SPACER WASHER AS REQUIRED 1.5 MM
56
TAPERED ROLLER BEARING
56
TAPERED ROLLER BEARING , Replaced By: A0009800002
56
TAPERED ROLLER BEARING , Replaced By: A0009800202
56
TAPERED ROLLER BEARING , Replaced By: A0009801002
56
TAPERED ROLLER BEARING , Replaced By: A0009801002
58
SPACER BUSHING
60
TAPERED ROLLER BEARING
60
TAPERED ROLLER BEARING
60
TAPERED ROLLER BEARING
62
COVER , 000,001,100,101 FROM REAR AXLE 000287, 010 FROM REAR AXLE 129303, 110 FROM REAR AXLE 087840
64
SCREW , 000,001,100,101 FROM REAR AXLE 000287, 010 FROM REAR AXLE 129303, 110 FROM REAR AXLE 087840
64
SCREW
66
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
66
LOCK WASHER COMPRESSED AIR LINE TO BRACKET
68
SEAL RING , Replaced By: A0049975646
68
SEAL RING , Replaced By: A0049972546
68
SEAL RING
68
SEAL RING
69
SCREW
70
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
70
LOCK WASHER
72
FLANGE , Replaced By: A1103500145
72
FLANGE
74
GROOVED NUT
76
LOCK
76
LOCK , Replaced By: A1119940244
90
JOINT
92
SPACER WASHER
94
LOCK
96
SLEEVE STEERING COLUMN BEARING, NOT FOR USE WITH MERCEDES-BENZ CAB4 375508
98
ROLLERTO 387 460 14 09
100
SPACER WASHER
102
LOCK RING AS REQUIRED 1.75 MM
104
BUSHING
106
UNIVERSAL JOINT , 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640, Replaced By: A1123500128, +001A1109970032
106
UNIVERSAL JOINT , 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
108
SNAP RING 2.35 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
108
SNAP RING 2.45 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
108
SNAP RING 2.55 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
108
SNAP RING 2.15 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
108
SNAP RING 2.25 MM, 000,001,100,101 FROM REAR AXLE 001287, 010 FROM REAR AXLE 190028, 110 FROM REAR AXLE 201640
112
SCREW
114
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
114
LOCK WASHER COMPRESSED AIR LINE TO BRACKET
122
AXLE SHAFT LEFT
124
AXLE SHAFT RIGHT
126
DOWEL PIN
130
BALL BEARING , Replaced By: A0019811525
130
BALL BEARING , Replaced By: A0029812301
130
CYLINDR. ROLLER BEARING ,10/20879179, 50/60880935, Replaced By: A0029819001
131
BARREL-TYPE BEARING
132
LOCK
134
GROOVED NUT
138
REPAIR KIT
999
CLAMP REAR AXLE HOUSING
999
CLAMP REAR AXLE TUBE
999
RUBBER MOUNTING
999
THRUST ARM RIGHT
999
BRACKET RIGHT
