Поз.
Артикул
Описание
3
ENGINE SUPPORT LEFT, 981 10/50,20/60000537 981 12/52,22/62000005
4
ENGINE SUPPORT RIGHT, 981 10/50,20/60000537 981 12/52,22/62000005
5
WASHER , Replaced By: N000125010532
5
WASHER RADIATOR TO RUBBER MOUNTING
6
NUT BRACKET TO SUPPORT AND TO END PIECE
7
PLATE
8
SCREW , 042012865
9
SCREW
10
SPRING WASHER CAB FLOOR
10
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
12
COMBINATION BOLT
13
REPAIR KIT ENGINE FRONT SUSPENSION, 000,001,004,010,016 FROM CHASSIS 116469, 100,101,104,110,116 FROM CHASSIS 196147 FOR EXPORT, ON SPECIAL REQUEST
14
ENGINE SUPPORT REAR, 130558-187306
15
SPACER RING SUPPORT TO OIL PAN
16
SPRING WASHER , Replaced By: N000137008212
16
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
17
NUT POWER CYLINDER TO THROTTLE VALVE LEVER
21
SCREW , Replaced By: N304017008016
21
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
22
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
23
NUT
24
ADJUSTING WASHER TIGHTENER PULLEY TO SUPPORT
25
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
25
SPRING WASHER CAB FLOOR
26
ADJUSTING WASHER CLAMPING LEVER TO SUPPORT,6 900042
27
ADJUSTING WASHER SPARE WHEEL HOIST TO FRAME
28
ADJUSTING WASHER SPARE WHEEL HOIST TO FRAME
29
SCREW , Replaced By: N304017012020
29
SCREW END PIECE TO EXHAUST PIPE M 12X30
30
REPAIR KIT
999
BOOT , NO LONGER AVAILABLE INDIVIDUALLY
999
RUBBER MOUNTING , NO LONGER AVAILABLE INDIVIDUALLY
999
RUBBER MOUNTING , NO LONGER AVAILABLE
999
RETAINER , NO LONGER AVAILABLE INDIVIDUALLY
999
RUBBER BUFFER ENGINE SUSPENSION,184086 309.0 EXCEPT FOR 050192297 050, 182065 309.1
999
RUBBER MOUNTING , NO LONGER AVAILABLE INDIVIDUALLY
999
RUBBER MOUNTING , NO LONGER AVAILABLE
999
RUBBER MOUNTING LEFT, NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
