Поз.
Артикул
Описание
7
RUBBER MOUNTING LEFT
8
RUBBER MOUNTING RIGHT
11
SCREW BRACKET TO TRANSMISSION
13
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
13
SPRING WASHER CAB FLOOR
14
SCREW , Replaced By: N007984008003
14
SCREW BRACKET TO INTAKE MANIFOLD
17
REPAIR KIT
28
COVERING
65
ENGINE SUPPORT
67
SCREW , Replaced By: N304017008016
67
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
69
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
70
RUBBER MOUNTING
74
REPAIR KIT
80
MOUNTING PLATE MOUNTING WITH SUPPORT TO TRANSMISSION
81
SPRING WASHER CAB FLOOR
81
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
82
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
82
NUT , Replaced By: N308673012002
84
BRACKET
90
SCREW
94
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
97
WASHER REAR FOGLAMP TO BRACKET
103
PLATE
105
NUT BATTERY CABLE
105
NUT BRACKET TO SUPPORT AND TO END PIECE
107
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
109
RUBBER RING BRACKET TO MOUNTING PLATE OR TO TRANSMISSION
110
SPACER TUBE
113
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
114
WASHER STRUT TO CROSS MEMBER
114
WASHER , Replaced By: N007349010007
117
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
118
BRACKET
120
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
121
WASHER STRUT TO CROSS MEMBER
121
WASHER , Replaced By: N007349010007
122
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
RUBBER MOUNTING , Replaced By: A1072410913, +001A1142410284
999
BASE PLATE ,W 4A 020 102,103 412010 105 NOT FOR SWEDEN 310470 105 SWEDEN A 000462 EXCEPT FOR 298984,310801 183 NOT FOR SWEDEN 028929 183 SWEDEN F 001866 EXCEPT FOR 028960 190 030465 EXCEPT FOR 030442 200 165220 280 NOT FOR SWITZERLAND 009680 EXCEPT FOR 009608,009626-009679 280 SWITZERLAND 009207 283 NOT FOR SWITZERLAND 019904 EXCEPT FOR 019489,019510,019514,019524,019528-019534,019541,019543,019548-019550,019554-019575,019587,019590, 019593,019603,019604,019613,019614,019625-019638,019646,019649-019712,019715-019814,019821,019830- 019894,019899,019901. 283 SWITZERLAND F 000422 EXCEPT FOR 021312,F 000333
999
ENGINE SUPPORT
999
SPRING WASHER , Replaced By: N000137008212
999
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW , Replaced By: N304017008034
999
SCREW BRACKET TO CROSS CONNECTION STRUT
